Simple tower defense tutorial, part 6: Refactoring

I believe some readers may have eagerly awaited this step in the tutorial: Refactoring. Our single main file has grown or maybe better said sprouted into a 1500 line long messy flowerbed of code: Lot's of nice things but also unorganized and no longer easy to understand.

So this part is mostly about splitting the code into multiple files and explaining the thoughts behind it. There won't be any game features added in this part, instead this part will also give some background information about how the C compiler works.

Splitting up the code

There are many opinions on how and when to split functions into files. In this case, I would like to keep the number of files a bit smaller, as the web interface showing the files might become a bit more difficult to follow the changes.

In general, what is more important than the number of lines in a code file is how entangled the cross references within the code are. So our task is to identify code parts that belong together and have few other dependencies and move them into distinct files.

In our case, it should be fairly simple to split the code: We have a some parts that are quite isolated: Enemies, towers, projectiles and particles.

Backgrounds

I will try to keep this short and cut some corners here and there, but I think it's important to understand a few things about how the C compiler works:

When working with multiple files in C, it's helpful to understand how the compiler handles the files. This makes it easier to understand error messages better, so I want to elaborate on this part a bit more, even if this is much more theoretical.

We'll begin with looking at the commandline arguments to build the project. Using GCC, it looks roughly like this:

gcc -o td-tut-32-main td-tut-32-main.c preferred_size.c -lraylib -Iraylib/src

Let's take this apart:

gcc gets the instruction to output a file called "td-tut-32-main", specified via -o
The two files called "td-tut-32-main.c" "preferred_size.c" are provided as input source files. This is our program code.
-lraylib tells the compiler to link against the raylib library. This library provides the functions we use to draw graphics and handle input and window handling.
-Iraylib/src tells the compiler where to find the raylib header files. When we include raylib.h in our code, the compiler needs to know where to find this file. Any file that is included with #include is searched in the directories specified with -I in the provided order.

What happens upon execution of this command is that the compiler takes the two .c files and compiles them into so called object files. If there's a syntax error in the code or a header that can't be found, the compiler will throw an error in this step.

There are a few steps in between, but in the last step, a linker takes these results to produce the final executable. In the example above, the call to gcc executes the linking step as well, but it's possible to split the compilation and linking steps into two separate calls. This is usually done to avoid recompiling all files when only one file has changed.

To compare this with the makefiles provided by raylib, the coresponding line to the command above would look like this:

$(CC) -o $(PROJECT_NAME)$(EXT) $(OBJS) $(CFLAGS) $(INCLUDE_PATHS) $(LDFLAGS) $(LDLIBS) -D$(PLATFORM)

This looks a little intimidating at first, but let's break it down:

The $(...) elements are variables that are defined in the makefile. The $(CC) variable contains the compiler command, which is usually gcc. The $(PROJECT_NAME) variable contains the name of the project and $(EXT) is the file extension of the executable. The $(CFLAGS) variable contains the compiler flags that are used to compile the code. The $(INCLUDE_PATHS) variable contains the -I flags that tell the compiler where to find the header files. The $(LDFLAGS) variable contains the linker flags and the $(LDLIBS) The -D$(PLATFORM) flag is used to define a preprocessor macro that is used in the code. For raylib, this is something like PLATFORM_DESKTOP, which is used to include the correct platform specific code.

The $(OBJS) variable contains the c file names and is often just looking like this:

OBJS = main.c file1.c file2.c

As said, the compiler compiles each of these files into an object file first. In this step, the source code is checked for syntax errors and is compiled into a binary representation that the later steps can work with. It is not yet in any executable form.

During this step, the compiler takes the header files and includes them in the source code. Naturally, the compiler doesn't know what the functions in the other files are doing, but it registers the functions that the input file is implementing; which leads to this small detail: you probably have noticed that a function can have a "static" in front of its declaration.

It looks like this:

  1 static void my_function() { ... }
  2 void my_other_function() { ...

The static keyword tells the compiler that this function is only called from within this file. In an object oriented language, you'd probably say that this function is a private method. Variables can also be declared static, which makes them also only visible in this file, or, if they are declared in a function, only within the scope of that function.

When the compiler is compiling the source code, static functions are a bit special: The compiler can do some optimizations based on the knowledge that this function (or variable) is only used within the scope of this file. It is difficult to put a number on how effective this kind of optimization is, but in certain scenarios, it can be significant while in most cases, it doesn't have much of an effect (it should be mentioned that static variables within function scopes are quite different and can have a negative impact on performance, depending on various factors).

Micro optimizations like declaring functions and variables static are often declared to be 'premature optimization'. There are 2 things to consider about this argument:

Limiting the scope of functions or variables is usually a good trait, as it reduces the potential dependencies to be considered when reading the code. The potential performance gain could be seen as a side effect.
If a program is full of performance degrading code, implementing a single optimization like this will result in a significant improvement. For example, if some code runs 10 seconds and a micro optimization like this one reduces its duration by 0.01ms, it is hardly considered to be a worthwhile improvement. Let's say now, we take the code and heavily optimize its runtime so it runs in total for only 0.1ms, a 0.01ms reduction represents suddenly a significant improvement.

Without the static keyword, the function could be also called from other files. In any case, the right signature must be used in order to be able to call a function. What is a signature?

Let's look at this function declaration:

void my_other_function();

It tells the compiler that there is a function with the name "my_other_function", somewhere. Somewhere means, it could be in another object file or it could be part of a library (like raylib). But the signature of a function is not just its name, its also its return type and function arguments. In this case, it's a function that returns nothing and takes no arguments. All this information forms the signature that is used to identify the function so it can be called.

Connecting function calls to the actual function implementation is the job of the linker. During the linking phase, the linker resolves the symbols into actual memory addresses that the program can call. If the linker can't find a function, it will throw an error, which could look like this:

undefined reference to `my_other_function'

This means that the linker couldn't find the function and therefore couldn't resolve the call to this function. It can also happen, that the linker discovers that there are multiple functions with the same name. Since there is no namespace in C, it's up to the programmer to make sure that the function signatures are unique.

When multiple libraries are used, it can happen that two libraries provide a function with the same name and the same signature. This is called a "symbol collision" and the linker will throw an error in this case.

Notice that I say "signature" and not "name". The signature is the function name and the argument types it takes. While I would not recommend to have two functions with the same name in a project, it's possible to have two functions with the same name:

compiler_unit_1.c
compiler_unit_2.c
💾

  1 #include <stdlib.h>
  2 #include <stdio.h>
  3
  4 void Bar();
  5
  6 void Foo()
  7 {
  8   printf("Foo of unit_1\n");
  9 }
 10
 11 int main()
 12 {
 13   Foo();
 14   Bar();
 15   return 0;
 16 }

  1 #include <stdlib.h>
  2 #include <stdio.h>
  3
  4 void Foo(const char *str) {
  5   printf("Foo: %s of unit 2\n", str);
  6 }
  7
  8 void Bar() {
  9   Foo("Bar");
 10 }

The compiler is also throwing a warning, because in general, this is typically a bad idea:

wasm-ld: warning: function signature mismatch: Foo

This is a warning that the linker throws when it discovers that there are two functions with the same name but different signatures. The code however runs just fine. But don't do this.

So enough of the theory, let's split up the code - but I won't do all everything in one go. The first step is to extract the struct and function declarations into the main header:

td-tut-37/td_main.c
td-tut-37/td_main.h
td-tut-37/preferred_size.c
td-tut-37/preferred_size.h
💾

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 //# Declarations
  7
  8 Level levels[] = {
  9   [0] = {
 10     .state = LEVEL_STATE_BUILDING,
 11     .initialGold = 10,
 12     .waves[0] = {
 13       .enemyType = ENEMY_TYPE_MINION,
 14       .wave = 0,
 15       .count = 10,
 16       .interval = 1.0f,
 17       .delay = 1.0f,
 18       .spawnPosition = {0, 6},
 19     },
 20     .waves[1] = {
 21       .enemyType = ENEMY_TYPE_MINION,
 22       .wave = 1,
 23       .count = 20,
 24       .interval = 0.5f,
 25       .delay = 1.0f,
 26       .spawnPosition = {0, 6},
 27     },
 28     .waves[2] = {
 29       .enemyType = ENEMY_TYPE_MINION,
 30       .wave = 2,
 31       .count = 30,
 32       .interval = 0.25f,
 33       .delay = 1.0f,
 34       .spawnPosition = {0, 6},
 35     }
 36   },
 37 };
 38
 39 Level *currentLevel = levels;
 40
 41 Particle particles[PARTICLE_MAX_COUNT];
 42 int particleCount = 0;
 43
 44 //# Particle system
 45
 46 void ParticleInit()
 47 {
 48   for (int i = 0; i < PARTICLE_MAX_COUNT; i++)
 49   {
 50     particles[i] = (Particle){0};
 51   }
 52   particleCount = 0;
 53 }
 54
 55 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime)
 56 {
 57   if (particleCount >= PARTICLE_MAX_COUNT)
 58   {
 59     return;
 60   }
 61
 62   int index = -1;
 63   for (int i = 0; i < particleCount; i++)
 64   {
 65     if (particles[i].particleType == PARTICLE_TYPE_NONE)
 66     {
 67       index = i;
 68       break;
 69     }
 70   }
 71
 72   if (index == -1)
 73   {
 74     index = particleCount++;
 75   }
 76
 77   Particle *particle = &particles[index];
 78   particle->particleType = particleType;
 79   particle->spawnTime = gameTime.time;
 80   particle->lifetime = lifetime;
 81   particle->position = position;
 82   particle->velocity = velocity;
 83 }
 84
 85 void ParticleUpdate()
 86 {
 87   for (int i = 0; i < particleCount; i++)
 88   {
 89     Particle *particle = &particles[i];
 90     if (particle->particleType == PARTICLE_TYPE_NONE)
 91     {
 92       continue;
 93     }
 94
 95     float age = gameTime.time - particle->spawnTime;
 96
 97     if (particle->lifetime > age)
 98     {
 99       particle->position = Vector3Add(particle->position, Vector3Scale(particle->velocity, gameTime.deltaTime));
100     }
101     else {
102       particle->particleType = PARTICLE_TYPE_NONE;
103     }
104   }
105 }
106
107 void DrawExplosionParticle(Particle *particle, float transition)
108 {
109   float size = 1.2f * (1.0f - transition);
110   Color startColor = WHITE;
111   Color endColor = RED;
112   Color color = ColorLerp(startColor, endColor, transition);
113   DrawCube(particle->position, size, size, size, color);
114 }
115
116 void ParticleDraw()
117 {
118   for (int i = 0; i < particleCount; i++)
119   {
120     Particle particle = particles[i];
121     if (particle.particleType == PARTICLE_TYPE_NONE)
122     {
123       continue;
124     }
125
126     float age = gameTime.time - particle.spawnTime;
127     float transition = age / particle.lifetime;
128     switch (particle.particleType)
129     {
130     case PARTICLE_TYPE_EXPLOSION:
131       DrawExplosionParticle(&particle, transition);
132       break;
133     default:
134       DrawCube(particle.position, 0.3f, 0.5f, 0.3f, RED);
135       break;
136     }
137   }
138 }
139
140 //# Pathfinding map
141
142 // The queue is a simple array of nodes, we add nodes to the end and remove
143 // nodes from the front. We keep the array around to avoid unnecessary allocations
144 static PathfindingNode *pathfindingNodeQueue = 0;
145 static int pathfindingNodeQueueCount = 0;
146 static int pathfindingNodeQueueCapacity = 0;
147
148 // The pathfinding map stores the distances from the castle to each cell in the map.
149 PathfindingMap pathfindingMap = {0};
150
151 void PathfindingMapInit(int width, int height, Vector3 translate, float scale)
152 {
153   // transforming between map space and world space allows us to adapt
154   // position and scale of the map without changing the pathfinding data
155   pathfindingMap.toWorldSpace = MatrixTranslate(translate.x, translate.y, translate.z);
156   pathfindingMap.toWorldSpace = MatrixMultiply(pathfindingMap.toWorldSpace, MatrixScale(scale, scale, scale));
157   pathfindingMap.toMapSpace = MatrixInvert(pathfindingMap.toWorldSpace);
158   pathfindingMap.width = width;
159   pathfindingMap.height = height;
160   pathfindingMap.scale = scale;
161   pathfindingMap.distances = (float *)MemAlloc(width * height * sizeof(float));
162   for (int i = 0; i < width * height; i++)
163   {
164     pathfindingMap.distances[i] = -1.0f;
165   }
166
167   pathfindingMap.towerIndex = (long *)MemAlloc(width * height * sizeof(long));
168   pathfindingMap.deltaSrc = (DeltaSrc *)MemAlloc(width * height * sizeof(DeltaSrc));
169 }
170
171 float PathFindingGetDistance(int mapX, int mapY)
172 {
173   if (mapX < 0 || mapX >= pathfindingMap.width || mapY < 0 || mapY >= pathfindingMap.height)
174   {
175     // when outside the map, we return the manhattan distance to the castle (0,0)
176     return fabsf((float)mapX) + fabsf((float)mapY);
177   }
178
179   return pathfindingMap.distances[mapY * pathfindingMap.width + mapX];
180 }
181
182 void PathFindingNodePush(int16_t x, int16_t y, int16_t fromX, int16_t fromY, float distance)
183 {
184   if (pathfindingNodeQueueCount >= pathfindingNodeQueueCapacity)
185   {
186     pathfindingNodeQueueCapacity = pathfindingNodeQueueCapacity == 0 ? 256 : pathfindingNodeQueueCapacity * 2;
187     // we use MemAlloc/MemRealloc to allocate memory for the queue
188     // I am not entirely sure if MemRealloc allows passing a null pointer
189     // so we check if the pointer is null and use MemAlloc in that case
190     if (pathfindingNodeQueue == 0)
191     {
192       pathfindingNodeQueue = (PathfindingNode *)MemAlloc(pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
193     }
194     else
195     {
196       pathfindingNodeQueue = (PathfindingNode *)MemRealloc(pathfindingNodeQueue, pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
197     }
198   }
199
200   PathfindingNode *node = &pathfindingNodeQueue[pathfindingNodeQueueCount++];
201   node->x = x;
202   node->y = y;
203   node->fromX = fromX;
204   node->fromY = fromY;
205   node->distance = distance;
206 }
207
208 PathfindingNode *PathFindingNodePop()
209 {
210   if (pathfindingNodeQueueCount == 0)
211   {
212     return 0;
213   }
214   // we return the first node in the queue; we want to return a pointer to the node
215   // so we can return 0 if the queue is empty.
216   // We should _not_ return a pointer to the element in the list, because the list
217   // may be reallocated and the pointer would become invalid. Or the
218   // popped element is overwritten by the next push operation.
219   // Using static here means that the variable is permanently allocated.
220   static PathfindingNode node;
221   node = pathfindingNodeQueue[0];
222   // we shift all nodes one position to the front
223   for (int i = 1; i < pathfindingNodeQueueCount; i++)
224   {
225     pathfindingNodeQueue[i - 1] = pathfindingNodeQueue[i];
226   }
227   --pathfindingNodeQueueCount;
228   return &node;
229 }
230
231 // transform a world position to a map position in the array;
232 // returns true if the position is inside the map
233 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY)
234 {
235   Vector3 mapPosition = Vector3Transform(worldPosition, pathfindingMap.toMapSpace);
236   *mapX = (int16_t)mapPosition.x;
237   *mapY = (int16_t)mapPosition.z;
238   return *mapX >= 0 && *mapX < pathfindingMap.width && *mapY >= 0 && *mapY < pathfindingMap.height;
239 }
240
241 void PathFindingMapUpdate()
242 {
243   const int castleX = 0, castleY = 0;
244   int16_t castleMapX, castleMapY;
245   if (!PathFindingFromWorldToMapPosition((Vector3){castleX, 0.0f, castleY}, &castleMapX, &castleMapY))
246   {
247     return;
248   }
249   int width = pathfindingMap.width, height = pathfindingMap.height;
250
251   // reset the distances to -1
252   for (int i = 0; i < width * height; i++)
253   {
254     pathfindingMap.distances[i] = -1.0f;
255   }
256   // reset the tower indices
257   for (int i = 0; i < width * height; i++)
258   {
259     pathfindingMap.towerIndex[i] = -1;
260   }
261   // reset the delta src
262   for (int i = 0; i < width * height; i++)
263   {
264     pathfindingMap.deltaSrc[i].x = 0;
265     pathfindingMap.deltaSrc[i].y = 0;
266   }
267
268   for (int i = 0; i < towerCount; i++)
269   {
270     Tower *tower = &towers[i];
271     if (tower->towerType == TOWER_TYPE_NONE || tower->towerType == TOWER_TYPE_BASE)
272     {
273       continue;
274     }
275     int16_t mapX, mapY;
276     // technically, if the tower cell scale is not in sync with the pathfinding map scale,
277     // this would not work correctly and needs to be refined to allow towers covering multiple cells
278     // or having multiple towers in one cell; for simplicity, we assume that the tower covers exactly
279     // one cell. For now.
280     if (!PathFindingFromWorldToMapPosition((Vector3){tower->x, 0.0f, tower->y}, &mapX, &mapY))
281     {
282       continue;
283     }
284     int index = mapY * width + mapX;
285     pathfindingMap.towerIndex[index] = i;
286   }
287
288   // we start at the castle and add the castle to the queue
289   pathfindingMap.maxDistance = 0.0f;
290   pathfindingNodeQueueCount = 0;
291   PathFindingNodePush(castleMapX, castleMapY, castleMapX, castleMapY, 0.0f);
292   PathfindingNode *node = 0;
293   while ((node = PathFindingNodePop()))
294   {
295     if (node->x < 0 || node->x >= width || node->y < 0 || node->y >= height)
296     {
297       continue;
298     }
299     int index = node->y * width + node->x;
300     if (pathfindingMap.distances[index] >= 0 && pathfindingMap.distances[index] <= node->distance)
301     {
302       continue;
303     }
304
305     int deltaX = node->x - node->fromX;
306     int deltaY = node->y - node->fromY;
307     // even if the cell is blocked by a tower, we still may want to store the direction
308     // (though this might not be needed, IDK right now)
309     pathfindingMap.deltaSrc[index].x = (char) deltaX;
310     pathfindingMap.deltaSrc[index].y = (char) deltaY;
311
312     // we skip nodes that are blocked by towers
313     if (pathfindingMap.towerIndex[index] >= 0)
314     {
315       node->distance += 8.0f;
316     }
317     pathfindingMap.distances[index] = node->distance;
318     pathfindingMap.maxDistance = fmaxf(pathfindingMap.maxDistance, node->distance);
319     PathFindingNodePush(node->x, node->y + 1, node->x, node->y, node->distance + 1.0f);
320     PathFindingNodePush(node->x, node->y - 1, node->x, node->y, node->distance + 1.0f);
321     PathFindingNodePush(node->x + 1, node->y, node->x, node->y, node->distance + 1.0f);
322     PathFindingNodePush(node->x - 1, node->y, node->x, node->y, node->distance + 1.0f);
323   }
324 }
325
326 void PathFindingMapDraw()
327 {
328   float cellSize = pathfindingMap.scale * 0.9f;
329   float highlightDistance = fmodf(GetTime() * 4.0f, pathfindingMap.maxDistance);
330   for (int x = 0; x < pathfindingMap.width; x++)
331   {
332     for (int y = 0; y < pathfindingMap.height; y++)
333     {
334       float distance = pathfindingMap.distances[y * pathfindingMap.width + x];
335       float colorV = distance < 0 ? 0 : fminf(distance / pathfindingMap.maxDistance, 1.0f);
336       Color color = distance < 0 ? BLUE : (Color){fminf(colorV, 1.0f) * 255, 0, 0, 255};
337       Vector3 position = Vector3Transform((Vector3){x, -0.25f, y}, pathfindingMap.toWorldSpace);
338       // animate the distance "wave" to show how the pathfinding algorithm expands
339       // from the castle
340       if (distance + 0.5f > highlightDistance && distance - 0.5f < highlightDistance)
341       {
342         color = BLACK;
343       }
344       DrawCube(position, cellSize, 0.1f, cellSize, color);
345     }
346   }
347 }
348
349 Vector2 PathFindingGetGradient(Vector3 world)
350 {
351   int16_t mapX, mapY;
352   if (PathFindingFromWorldToMapPosition(world, &mapX, &mapY))
353   {
354     DeltaSrc delta = pathfindingMap.deltaSrc[mapY * pathfindingMap.width + mapX];
355     return (Vector2){(float)-delta.x, (float)-delta.y};
356   }
357   // fallback to a simple gradient calculation
358   float n = PathFindingGetDistance(mapX, mapY - 1);
359   float s = PathFindingGetDistance(mapX, mapY + 1);
360   float w = PathFindingGetDistance(mapX - 1, mapY);
361   float e = PathFindingGetDistance(mapX + 1, mapY);
362   return (Vector2){w - e + 0.25f, n - s + 0.125f};
363 }
364
365 //# Enemies
366 void EnemyInit()
367 {
368   for (int i = 0; i < ENEMY_MAX_COUNT; i++)
369   {
370     enemies[i] = (Enemy){0};
371   }
372   enemyCount = 0;
373 }
374
375 float EnemyGetCurrentMaxSpeed(Enemy *enemy)
376 {
377   return enemyClassConfigs[enemy->enemyType].speed;
378 }
379
380 float EnemyGetMaxHealth(Enemy *enemy)
381 {
382   return enemyClassConfigs[enemy->enemyType].health;
383 }
384
385 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY)
386 {
387   int16_t castleX = 0;
388   int16_t castleY = 0;
389   int16_t dx = castleX - currentX;
390   int16_t dy = castleY - currentY;
391   if (dx == 0 && dy == 0)
392   {
393     *nextX = currentX;
394     *nextY = currentY;
395     return 1;
396   }
397   Vector2 gradient = PathFindingGetGradient((Vector3){currentX, 0, currentY});
398
399   if (gradient.x == 0 && gradient.y == 0)
400   {
401     *nextX = currentX;
402     *nextY = currentY;
403     return 1;
404   }
405
406   if (fabsf(gradient.x) > fabsf(gradient.y))
407   {
408     *nextX = currentX + (int16_t)(gradient.x > 0.0f ? 1 : -1);
409     *nextY = currentY;
410     return 0;
411   }
412   *nextX = currentX;
413   *nextY = currentY + (int16_t)(gradient.y > 0.0f ? 1 : -1);
414   return 0;
415 }
416
417
418 // this function predicts the movement of the unit for the next deltaT seconds
419 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount)
420 {
421   const float pointReachedDistance = 0.25f;
422   const float pointReachedDistance2 = pointReachedDistance * pointReachedDistance;
423   const float maxSimStepTime = 0.015625f;
424
425   float maxAcceleration = enemyClassConfigs[enemy->enemyType].maxAcceleration;
426   float maxSpeed = EnemyGetCurrentMaxSpeed(enemy);
427   int16_t nextX = enemy->nextX;
428   int16_t nextY = enemy->nextY;
429   Vector2 position = enemy->simPosition;
430   int passedCount = 0;
431   for (float t = 0.0f; t < deltaT; t += maxSimStepTime)
432   {
433     float stepTime = fminf(deltaT - t, maxSimStepTime);
434     Vector2 target = (Vector2){nextX, nextY};
435     float speed = Vector2Length(*velocity);
436     // draw the target position for debugging
437     DrawCubeWires((Vector3){target.x, 0.2f, target.y}, 0.1f, 0.4f, 0.1f, RED);
438     Vector2 lookForwardPos = Vector2Add(position, Vector2Scale(*velocity, speed));
439     if (Vector2DistanceSqr(target, lookForwardPos) <= pointReachedDistance2)
440     {
441       // we reached the target position, let's move to the next waypoint
442       EnemyGetNextPosition(nextX, nextY, &nextX, &nextY);
443       target = (Vector2){nextX, nextY};
444       // track how many waypoints we passed
445       passedCount++;
446     }
447
448     // acceleration towards the target
449     Vector2 unitDirection = Vector2Normalize(Vector2Subtract(target, lookForwardPos));
450     Vector2 acceleration = Vector2Scale(unitDirection, maxAcceleration * stepTime);
451     *velocity = Vector2Add(*velocity, acceleration);
452
453     // limit the speed to the maximum speed
454     if (speed > maxSpeed)
455     {
456       *velocity = Vector2Scale(*velocity, maxSpeed / speed);
457     }
458
459     // move the enemy
460     position = Vector2Add(position, Vector2Scale(*velocity, stepTime));
461   }
462
463   if (waypointPassedCount)
464   {
465     (*waypointPassedCount) = passedCount;
466   }
467
468   return position;
469 }
470
471 void EnemyDraw()
472 {
473   for (int i = 0; i < enemyCount; i++)
474   {
475     Enemy enemy = enemies[i];
476     if (enemy.enemyType == ENEMY_TYPE_NONE)
477     {
478       continue;
479     }
480
481     Vector2 position = EnemyGetPosition(&enemy, gameTime.time - enemy.startMovingTime, &enemy.simVelocity, 0);
482
483     if (enemy.movePathCount > 0)
484     {
485       Vector3 p = {enemy.movePath[0].x, 0.2f, enemy.movePath[0].y};
486       DrawLine3D(p, (Vector3){position.x, 0.2f, position.y}, GREEN);
487     }
488     for (int j = 1; j < enemy.movePathCount; j++)
489     {
490       Vector3 p = {enemy.movePath[j - 1].x, 0.2f, enemy.movePath[j - 1].y};
491       Vector3 q = {enemy.movePath[j].x, 0.2f, enemy.movePath[j].y};
492       DrawLine3D(p, q, GREEN);
493     }
494
495     switch (enemy.enemyType)
496     {
497     case ENEMY_TYPE_MINION:
498       DrawCubeWires((Vector3){position.x, 0.2f, position.y}, 0.4f, 0.4f, 0.4f, GREEN);
499       break;
500     }
501   }
502 }
503
504 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource)
505 {
506   // damage the tower
507   float explosionDamge = enemyClassConfigs[enemy->enemyType].explosionDamage;
508   float explosionRange = enemyClassConfigs[enemy->enemyType].explosionRange;
509   float explosionPushbackPower = enemyClassConfigs[enemy->enemyType].explosionPushbackPower;
510   float explosionRange2 = explosionRange * explosionRange;
511   tower->damage += enemyClassConfigs[enemy->enemyType].explosionDamage;
512   // explode the enemy
513   if (tower->damage >= TowerGetMaxHealth(tower))
514   {
515     tower->towerType = TOWER_TYPE_NONE;
516   }
517
518   ParticleAdd(PARTICLE_TYPE_EXPLOSION,
519     explosionSource,
520     (Vector3){0, 0.1f, 0}, 1.0f);
521
522   enemy->enemyType = ENEMY_TYPE_NONE;
523
524   // push back enemies & dealing damage
525   for (int i = 0; i < enemyCount; i++)
526   {
527     Enemy *other = &enemies[i];
528     if (other->enemyType == ENEMY_TYPE_NONE)
529     {
530       continue;
531     }
532     float distanceSqr = Vector2DistanceSqr(enemy->simPosition, other->simPosition);
533     if (distanceSqr > 0 && distanceSqr < explosionRange2)
534     {
535       Vector2 direction = Vector2Normalize(Vector2Subtract(other->simPosition, enemy->simPosition));
536       other->simPosition = Vector2Add(other->simPosition, Vector2Scale(direction, explosionPushbackPower));
537       EnemyAddDamage(other, explosionDamge);
538     }
539   }
540 }
541
542 void EnemyUpdate()
543 {
544   const float castleX = 0;
545   const float castleY = 0;
546   const float maxPathDistance2 = 0.25f * 0.25f;
547
548   for (int i = 0; i < enemyCount; i++)
549   {
550     Enemy *enemy = &enemies[i];
551     if (enemy->enemyType == ENEMY_TYPE_NONE)
552     {
553       continue;
554     }
555
556     int waypointPassedCount = 0;
557     enemy->simPosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &enemy->simVelocity, &waypointPassedCount);
558     enemy->startMovingTime = gameTime.time;
559     // track path of unit
560     if (enemy->movePathCount == 0 || Vector2DistanceSqr(enemy->simPosition, enemy->movePath[0]) > maxPathDistance2)
561     {
562       for (int j = ENEMY_MAX_PATH_COUNT - 1; j > 0; j--)
563       {
564         enemy->movePath[j] = enemy->movePath[j - 1];
565       }
566       enemy->movePath[0] = enemy->simPosition;
567       if (++enemy->movePathCount > ENEMY_MAX_PATH_COUNT)
568       {
569         enemy->movePathCount = ENEMY_MAX_PATH_COUNT;
570       }
571     }
572
573     if (waypointPassedCount > 0)
574     {
575       enemy->currentX = enemy->nextX;
576       enemy->currentY = enemy->nextY;
577       if (EnemyGetNextPosition(enemy->currentX, enemy->currentY, &enemy->nextX, &enemy->nextY) &&
578         Vector2DistanceSqr(enemy->simPosition, (Vector2){castleX, castleY}) <= 0.25f * 0.25f)
579       {
580         // enemy reached the castle; remove it
581         enemy->enemyType = ENEMY_TYPE_NONE;
582         continue;
583       }
584     }
585   }
586
587   // handle collisions between enemies
588   for (int i = 0; i < enemyCount - 1; i++)
589   {
590     Enemy *enemyA = &enemies[i];
591     if (enemyA->enemyType == ENEMY_TYPE_NONE)
592     {
593       continue;
594     }
595     for (int j = i + 1; j < enemyCount; j++)
596     {
597       Enemy *enemyB = &enemies[j];
598       if (enemyB->enemyType == ENEMY_TYPE_NONE)
599       {
600         continue;
601       }
602       float distanceSqr = Vector2DistanceSqr(enemyA->simPosition, enemyB->simPosition);
603       float radiusA = enemyClassConfigs[enemyA->enemyType].radius;
604       float radiusB = enemyClassConfigs[enemyB->enemyType].radius;
605       float radiusSum = radiusA + radiusB;
606       if (distanceSqr < radiusSum * radiusSum && distanceSqr > 0.001f)
607       {
608         // collision
609         float distance = sqrtf(distanceSqr);
610         float overlap = radiusSum - distance;
611         // move the enemies apart, but softly; if we have a clog of enemies,
612         // moving them perfectly apart can cause them to jitter
613         float positionCorrection = overlap / 5.0f;
614         Vector2 direction = (Vector2){
615             (enemyB->simPosition.x - enemyA->simPosition.x) / distance * positionCorrection,
616             (enemyB->simPosition.y - enemyA->simPosition.y) / distance * positionCorrection};
617         enemyA->simPosition = Vector2Subtract(enemyA->simPosition, direction);
618         enemyB->simPosition = Vector2Add(enemyB->simPosition, direction);
619       }
620     }
621   }
622
623   // handle collisions between enemies and towers
624   for (int i = 0; i < enemyCount; i++)
625   {
626     Enemy *enemy = &enemies[i];
627     if (enemy->enemyType == ENEMY_TYPE_NONE)
628     {
629       continue;
630     }
631     enemy->contactTime -= gameTime.deltaTime;
632     if (enemy->contactTime < 0.0f)
633     {
634       enemy->contactTime = 0.0f;
635     }
636
637     float enemyRadius = enemyClassConfigs[enemy->enemyType].radius;
638     // linear search over towers; could be optimized by using path finding tower map,
639     // but for now, we keep it simple
640     for (int j = 0; j < towerCount; j++)
641     {
642       Tower *tower = &towers[j];
643       if (tower->towerType == TOWER_TYPE_NONE)
644       {
645         continue;
646       }
647       float distanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){tower->x, tower->y});
648       float combinedRadius = enemyRadius + 0.708; // sqrt(0.5^2 + 0.5^2), corner-center distance of square with side length 1
649       if (distanceSqr > combinedRadius * combinedRadius)
650       {
651         continue;
652       }
653       // potential collision; square / circle intersection
654       float dx = tower->x - enemy->simPosition.x;
655       float dy = tower->y - enemy->simPosition.y;
656       float absDx = fabsf(dx);
657       float absDy = fabsf(dy);
658       Vector3 contactPoint = {0};
659       if (absDx <= 0.5f && absDx <= absDy) {
660         // vertical collision; push the enemy out horizontally
661         float overlap = enemyRadius + 0.5f - absDy;
662         if (overlap < 0.0f)
663         {
664           continue;
665         }
666         float direction = dy > 0.0f ? -1.0f : 1.0f;
667         enemy->simPosition.y += direction * overlap;
668         contactPoint = (Vector3){enemy->simPosition.x, 0.2f, tower->x + direction * 0.5f};
669       }
670       else if (absDy <= 0.5f && absDy <= absDx)
671       {
672         // horizontal collision; push the enemy out vertically
673         float overlap = enemyRadius + 0.5f - absDx;
674         if (overlap < 0.0f)
675         {
676           continue;
677         }
678         float direction = dx > 0.0f ? -1.0f : 1.0f;
679         enemy->simPosition.x += direction * overlap;
680         contactPoint = (Vector3){tower->x + direction * 0.5f, 0.2f, enemy->simPosition.y};
681       }
682       else
683       {
684         // possible collision with a corner
685         float cornerDX = dx > 0.0f ? -0.5f : 0.5f;
686         float cornerDY = dy > 0.0f ? -0.5f : 0.5f;
687         float cornerX = tower->x + cornerDX;
688         float cornerY = tower->y + cornerDY;
689         float cornerDistanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){cornerX, cornerY});
690         if (cornerDistanceSqr > enemyRadius * enemyRadius)
691         {
692           continue;
693         }
694         // push the enemy out along the diagonal
695         float cornerDistance = sqrtf(cornerDistanceSqr);
696         float overlap = enemyRadius - cornerDistance;
697         float directionX = cornerDistance > 0.0f ? (cornerX - enemy->simPosition.x) / cornerDistance : -cornerDX;
698         float directionY = cornerDistance > 0.0f ? (cornerY - enemy->simPosition.y) / cornerDistance : -cornerDY;
699         enemy->simPosition.x -= directionX * overlap;
700         enemy->simPosition.y -= directionY * overlap;
701         contactPoint = (Vector3){cornerX, 0.2f, cornerY};
702       }
703
704       if (enemyClassConfigs[enemy->enemyType].explosionDamage > 0.0f)
705       {
706         enemy->contactTime += gameTime.deltaTime * 2.0f; // * 2 to undo the subtraction above
707         if (enemy->contactTime >= enemyClassConfigs[enemy->enemyType].requiredContactTime)
708         {
709           EnemyTriggerExplode(enemy, tower, contactPoint);
710         }
711       }
712     }
713   }
714 }
715
716 EnemyId EnemyGetId(Enemy *enemy)
717 {
718   return (EnemyId){enemy - enemies, enemy->generation};
719 }
720
721 Enemy *EnemyTryResolve(EnemyId enemyId)
722 {
723   if (enemyId.index >= ENEMY_MAX_COUNT)
724   {
725     return 0;
726   }
727   Enemy *enemy = &enemies[enemyId.index];
728   if (enemy->generation != enemyId.generation || enemy->enemyType == ENEMY_TYPE_NONE)
729   {
730     return 0;
731   }
732   return enemy;
733 }
734
735 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY)
736 {
737   Enemy *spawn = 0;
738   for (int i = 0; i < enemyCount; i++)
739   {
740     Enemy *enemy = &enemies[i];
741     if (enemy->enemyType == ENEMY_TYPE_NONE)
742     {
743       spawn = enemy;
744       break;
745     }
746   }
747
748   if (enemyCount < ENEMY_MAX_COUNT && !spawn)
749   {
750     spawn = &enemies[enemyCount++];
751   }
752
753   if (spawn)
754   {
755     spawn->currentX = currentX;
756     spawn->currentY = currentY;
757     spawn->nextX = currentX;
758     spawn->nextY = currentY;
759     spawn->simPosition = (Vector2){currentX, currentY};
760     spawn->simVelocity = (Vector2){0, 0};
761     spawn->enemyType = enemyType;
762     spawn->startMovingTime = gameTime.time;
763     spawn->damage = 0.0f;
764     spawn->futureDamage = 0.0f;
765     spawn->generation++;
766     spawn->movePathCount = 0;
767   }
768
769   return spawn;
770 }
771
772 int EnemyAddDamage(Enemy *enemy, float damage)
773 {
774   enemy->damage += damage;
775   if (enemy->damage >= EnemyGetMaxHealth(enemy))
776   {
777     currentLevel->playerGold += enemyClassConfigs[enemy->enemyType].goldValue;
778     enemy->enemyType = ENEMY_TYPE_NONE;
779     return 1;
780   }
781
782   return 0;
783 }
784
785 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range)
786 {
787   int16_t castleX = 0;
788   int16_t castleY = 0;
789   Enemy* closest = 0;
790   int16_t closestDistance = 0;
791   float range2 = range * range;
792   for (int i = 0; i < enemyCount; i++)
793   {
794     Enemy* enemy = &enemies[i];
795     if (enemy->enemyType == ENEMY_TYPE_NONE)
796     {
797       continue;
798     }
799     float maxHealth = EnemyGetMaxHealth(enemy);
800     if (enemy->futureDamage >= maxHealth)
801     {
802       // ignore enemies that will die soon
803       continue;
804     }
805     int16_t dx = castleX - enemy->currentX;
806     int16_t dy = castleY - enemy->currentY;
807     int16_t distance = abs(dx) + abs(dy);
808     if (!closest || distance < closestDistance)
809     {
810       float tdx = towerX - enemy->currentX;
811       float tdy = towerY - enemy->currentY;
812       float tdistance2 = tdx * tdx + tdy * tdy;
813       if (tdistance2 <= range2)
814       {
815         closest = enemy;
816         closestDistance = distance;
817       }
818     }
819   }
820   return closest;
821 }
822
823 int EnemyCount()
824 {
825   int count = 0;
826   for (int i = 0; i < enemyCount; i++)
827   {
828     if (enemies[i].enemyType != ENEMY_TYPE_NONE)
829     {
830       count++;
831     }
832   }
833   return count;
834 }
835
836 //# Projectiles
837 Projectile projectiles[PROJECTILE_MAX_COUNT];
838 int projectileCount = 0;
839
840 void ProjectileInit()
841 {
842   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
843   {
844     projectiles[i] = (Projectile){0};
845   }
846 }
847
848 void ProjectileDraw()
849 {
850   for (int i = 0; i < projectileCount; i++)
851   {
852     Projectile projectile = projectiles[i];
853     if (projectile.projectileType == PROJECTILE_TYPE_NONE)
854     {
855       continue;
856     }
857     float transition = (gameTime.time - projectile.shootTime) / (projectile.arrivalTime - projectile.shootTime);
858     if (transition >= 1.0f)
859     {
860       continue;
861     }
862     Vector2 position = Vector2Lerp(projectile.position, projectile.target, transition);
863     float x = position.x;
864     float y = position.y;
865     float dx = projectile.directionNormal.x;
866     float dy = projectile.directionNormal.y;
867     for (float d = 1.0f; d > 0.0f; d -= 0.25f)
868     {
869       x -= dx * 0.1f;
870       y -= dy * 0.1f;
871       float size = 0.1f * d;
872       DrawCube((Vector3){x, 0.2f, y}, size, size, size, RED);
873     }
874   }
875 }
876
877 void ProjectileUpdate()
878 {
879   for (int i = 0; i < projectileCount; i++)
880   {
881     Projectile *projectile = &projectiles[i];
882     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
883     {
884       continue;
885     }
886     float transition = (gameTime.time - projectile->shootTime) / (projectile->arrivalTime - projectile->shootTime);
887     if (transition >= 1.0f)
888     {
889       projectile->projectileType = PROJECTILE_TYPE_NONE;
890       Enemy *enemy = EnemyTryResolve(projectile->targetEnemy);
891       if (enemy)
892       {
893         EnemyAddDamage(enemy, projectile->damage);
894       }
895       continue;
896     }
897   }
898 }
899
900 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage)
901 {
902   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
903   {
904     Projectile *projectile = &projectiles[i];
905     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
906     {
907       projectile->projectileType = projectileType;
908       projectile->shootTime = gameTime.time;
909       projectile->arrivalTime = gameTime.time + Vector2Distance(position, target) / speed;
910       projectile->damage = damage;
911       projectile->position = position;
912       projectile->target = target;
913       projectile->directionNormal = Vector2Normalize(Vector2Subtract(target, position));
914       projectile->targetEnemy = EnemyGetId(enemy);
915       projectileCount = projectileCount <= i ? i + 1 : projectileCount;
916       return projectile;
917     }
918   }
919   return 0;
920 }
921
922 //# Towers
923
924 void TowerInit()
925 {
926   for (int i = 0; i < TOWER_MAX_COUNT; i++)
927   {
928     towers[i] = (Tower){0};
929   }
930   towerCount = 0;
931 }
932
933 Tower *TowerGetAt(int16_t x, int16_t y)
934 {
935   for (int i = 0; i < towerCount; i++)
936   {
937     if (towers[i].x == x && towers[i].y == y)
938     {
939       return &towers[i];
940     }
941   }
942   return 0;
943 }
944
945 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y)
946 {
947   if (towerCount >= TOWER_MAX_COUNT)
948   {
949     return 0;
950   }
951
952   Tower *tower = TowerGetAt(x, y);
953   if (tower)
954   {
955     return 0;
956   }
957
958   tower = &towers[towerCount++];
959   tower->x = x;
960   tower->y = y;
961   tower->towerType = towerType;
962   tower->cooldown = 0.0f;
963   tower->damage = 0.0f;
964   return tower;
965 }
966
967 Tower *GetTowerByType(uint8_t towerType)
968 {
969   for (int i = 0; i < towerCount; i++)
970   {
971     if (towers[i].towerType == towerType)
972     {
973       return &towers[i];
974     }
975   }
976   return 0;
977 }
978
979 int GetTowerCosts(uint8_t towerType)
980 {
981   switch (towerType)
982   {
983   case TOWER_TYPE_BASE:
984     return 0;
985   case TOWER_TYPE_GUN:
986     return 6;
987   case TOWER_TYPE_WALL:
988     return 2;
989   }
990   return 0;
991 }
992
993 float TowerGetMaxHealth(Tower *tower)
994 {
995   switch (tower->towerType)
996   {
997   case TOWER_TYPE_BASE:
998     return 10.0f;
999   case TOWER_TYPE_GUN:
1000     return 3.0f;
1001   case TOWER_TYPE_WALL:
1002     return 5.0f;
1003   }
1004   return 0.0f;
1005 }
1006
1007 void TowerDraw()
1008 {
1009   for (int i = 0; i < towerCount; i++)
1010   {
1011     Tower tower = towers[i];
1012     DrawCube((Vector3){tower.x, 0.125f, tower.y}, 1.0f, 0.25f, 1.0f, GRAY);
1013     switch (tower.towerType)
1014     {
1015     case TOWER_TYPE_BASE:
1016       DrawCube((Vector3){tower.x, 0.4f, tower.y}, 0.8f, 0.8f, 0.8f, MAROON);
1017       break;
1018     case TOWER_TYPE_GUN:
1019       DrawCube((Vector3){tower.x, 0.2f, tower.y}, 0.8f, 0.4f, 0.8f, DARKPURPLE);
1020       break;
1021     case TOWER_TYPE_WALL:
1022       DrawCube((Vector3){tower.x, 0.5f, tower.y}, 1.0f, 1.0f, 1.0f, LIGHTGRAY);
1023       break;
1024     }
1025   }
1026 }
1027
1028 void TowerGunUpdate(Tower *tower)
1029 {
1030   if (tower->cooldown <= 0)
1031   {
1032     Enemy *enemy = EnemyGetClosestToCastle(tower->x, tower->y, 3.0f);
1033     if (enemy)
1034     {
1035       tower->cooldown = 0.125f;
1036       // shoot the enemy; determine future position of the enemy
1037       float bulletSpeed = 1.0f;
1038       float bulletDamage = 3.0f;
1039       Vector2 velocity = enemy->simVelocity;
1040       Vector2 futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &velocity, 0);
1041       Vector2 towerPosition = {tower->x, tower->y};
1042       float eta = Vector2Distance(towerPosition, futurePosition) / bulletSpeed;
1043       for (int i = 0; i < 8; i++) {
1044         velocity = enemy->simVelocity;
1045         futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime + eta, &velocity, 0);
1046         float distance = Vector2Distance(towerPosition, futurePosition);
1047         float eta2 = distance / bulletSpeed;
1048         if (fabs(eta - eta2) < 0.01f) {
1049           break;
1050         }
1051         eta = (eta2 + eta) * 0.5f;
1052       }
1053       ProjectileTryAdd(PROJECTILE_TYPE_BULLET, enemy, towerPosition, futurePosition,
1054         bulletSpeed, bulletDamage);
1055       enemy->futureDamage += bulletDamage;
1056     }
1057   }
1058   else
1059   {
1060     tower->cooldown -= gameTime.deltaTime;
1061   }
1062 }
1063
1064 void TowerUpdate()
1065 {
1066   for (int i = 0; i < towerCount; i++)
1067   {
1068     Tower *tower = &towers[i];
1069     switch (tower->towerType)
1070     {
1071     case TOWER_TYPE_GUN:
1072       TowerGunUpdate(tower);
1073       break;
1074     }
1075   }
1076 }
1077
1078 //# Game
1079
1080 void InitLevel(Level *level)
1081 {
1082   TowerInit();
1083   EnemyInit();
1084   ProjectileInit();
1085   ParticleInit();
1086   TowerTryAdd(TOWER_TYPE_BASE, 0, 0);
1087
1088   level->placementMode = 0;
1089   level->state = LEVEL_STATE_BUILDING;
1090   level->nextState = LEVEL_STATE_NONE;
1091   level->playerGold = level->initialGold;
1092
1093   Camera *camera = &level->camera;
1094   camera->position = (Vector3){1.0f, 12.0f, 6.5f};
1095   camera->target = (Vector3){0.0f, 0.5f, 1.0f};
1096   camera->up = (Vector3){0.0f, 1.0f, 0.0f};
1097   camera->fovy = 45.0f;
1098   camera->projection = CAMERA_PERSPECTIVE;
1099 }
1100
1101 void DrawLevelHud(Level *level)
1102 {
1103   const char *text = TextFormat("Gold: %d", level->playerGold);
1104   Font font = GetFontDefault();
1105   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 120, 10}, font.baseSize * 2.0f, 2.0f, BLACK);
1106   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 122, 8}, font.baseSize * 2.0f, 2.0f, YELLOW);
1107 }
1108
1109 void DrawLevelReportLostWave(Level *level)
1110 {
1111   BeginMode3D(level->camera);
1112   DrawGrid(10, 1.0f);
1113   TowerDraw();
1114   EnemyDraw();
1115   ProjectileDraw();
1116   ParticleDraw();
1117   guiState.isBlocked = 0;
1118   EndMode3D();
1119
1120   const char *text = "Wave lost";
1121   int textWidth = MeasureText(text, 20);
1122   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
1123
1124   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
1125   {
1126     level->nextState = LEVEL_STATE_RESET;
1127   }
1128 }
1129
1130 int HasLevelNextWave(Level *level)
1131 {
1132   for (int i = 0; i < 10; i++)
1133   {
1134     EnemyWave *wave = &level->waves[i];
1135     if (wave->wave == level->currentWave)
1136     {
1137       return 1;
1138     }
1139   }
1140   return 0;
1141 }
1142
1143 void DrawLevelReportWonWave(Level *level)
1144 {
1145   BeginMode3D(level->camera);
1146   DrawGrid(10, 1.0f);
1147   TowerDraw();
1148   EnemyDraw();
1149   ProjectileDraw();
1150   ParticleDraw();
1151   guiState.isBlocked = 0;
1152   EndMode3D();
1153
1154   const char *text = "Wave won";
1155   int textWidth = MeasureText(text, 20);
1156   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
1157
1158
1159   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
1160   {
1161     level->nextState = LEVEL_STATE_RESET;
1162   }
1163
1164   if (HasLevelNextWave(level))
1165   {
1166     if (Button("Prepare for next wave", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
1167     {
1168       level->nextState = LEVEL_STATE_BUILDING;
1169     }
1170   }
1171   else {
1172     if (Button("Level won", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
1173     {
1174       level->nextState = LEVEL_STATE_WON_LEVEL;
1175     }
1176   }
1177 }
1178
1179 void DrawBuildingBuildButton(Level *level, int x, int y, int width, int height, uint8_t towerType, const char *name)
1180 {
1181   static ButtonState buttonStates[8] = {0};
1182   int cost = GetTowerCosts(towerType);
1183   const char *text = TextFormat("%s: %d", name, cost);
1184   buttonStates[towerType].isSelected = level->placementMode == towerType;
1185   buttonStates[towerType].isDisabled = level->playerGold < cost;
1186   if (Button(text, x, y, width, height, &buttonStates[towerType]))
1187   {
1188     level->placementMode = buttonStates[towerType].isSelected ? 0 : towerType;
1189   }
1190 }
1191
1192 void DrawLevelBuildingState(Level *level)
1193 {
1194   BeginMode3D(level->camera);
1195   DrawGrid(10, 1.0f);
1196   TowerDraw();
1197   EnemyDraw();
1198   ProjectileDraw();
1199   ParticleDraw();
1200
1201   Ray ray = GetScreenToWorldRay(GetMousePosition(), level->camera);
1202   float planeDistance = ray.position.y / -ray.direction.y;
1203   float planeX = ray.direction.x * planeDistance + ray.position.x;
1204   float planeY = ray.direction.z * planeDistance + ray.position.z;
1205   int16_t mapX = (int16_t)floorf(planeX + 0.5f);
1206   int16_t mapY = (int16_t)floorf(planeY + 0.5f);
1207   if (level->placementMode && !guiState.isBlocked)
1208   {
1209     DrawCubeWires((Vector3){mapX, 0.2f, mapY}, 1.0f, 0.4f, 1.0f, RED);
1210     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
1211     {
1212       if (TowerTryAdd(level->placementMode, mapX, mapY))
1213       {
1214         level->playerGold -= GetTowerCosts(level->placementMode);
1215         level->placementMode = TOWER_TYPE_NONE;
1216       }
1217     }
1218   }
1219
1220   guiState.isBlocked = 0;
1221
1222   EndMode3D();
1223
1224   static ButtonState buildWallButtonState = {0};
1225   static ButtonState buildGunButtonState = {0};
1226   buildWallButtonState.isSelected = level->placementMode == TOWER_TYPE_WALL;
1227   buildGunButtonState.isSelected = level->placementMode == TOWER_TYPE_GUN;
1228
1229   DrawBuildingBuildButton(level, 10, 10, 80, 30, TOWER_TYPE_WALL, "Wall");
1230   DrawBuildingBuildButton(level, 10, 50, 80, 30, TOWER_TYPE_GUN, "Gun");
1231
1232   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
1233   {
1234     level->nextState = LEVEL_STATE_RESET;
1235   }
1236
1237   if (Button("Begin waves", GetScreenWidth() - 160, GetScreenHeight() - 40, 160, 30, 0))
1238   {
1239     level->nextState = LEVEL_STATE_BATTLE;
1240   }
1241
1242   const char *text = "Building phase";
1243   int textWidth = MeasureText(text, 20);
1244   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
1245 }
1246
1247 void InitBattleStateConditions(Level *level)
1248 {
1249   level->state = LEVEL_STATE_BATTLE;
1250   level->nextState = LEVEL_STATE_NONE;
1251   level->waveEndTimer = 0.0f;
1252   for (int i = 0; i < 10; i++)
1253   {
1254     EnemyWave *wave = &level->waves[i];
1255     wave->spawned = 0;
1256     wave->timeToSpawnNext = wave->delay;
1257   }
1258 }
1259
1260 void DrawLevelBattleState(Level *level)
1261 {
1262   BeginMode3D(level->camera);
1263   DrawGrid(10, 1.0f);
1264   TowerDraw();
1265   EnemyDraw();
1266   ProjectileDraw();
1267   ParticleDraw();
1268   guiState.isBlocked = 0;
1269   EndMode3D();
1270
1271   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
1272   {
1273     level->nextState = LEVEL_STATE_RESET;
1274   }
1275
1276   int maxCount = 0;
1277   int remainingCount = 0;
1278   for (int i = 0; i < 10; i++)
1279   {
1280     EnemyWave *wave = &level->waves[i];
1281     if (wave->wave != level->currentWave)
1282     {
1283       continue;
1284     }
1285     maxCount += wave->count;
1286     remainingCount += wave->count - wave->spawned;
1287   }
1288   int aliveCount = EnemyCount();
1289   remainingCount += aliveCount;
1290
1291   const char *text = TextFormat("Battle phase: %03d%%", 100 - remainingCount * 100 / maxCount);
1292   int textWidth = MeasureText(text, 20);
1293   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
1294 }
1295
1296 void DrawLevel(Level *level)
1297 {
1298   switch (level->state)
1299   {
1300     case LEVEL_STATE_BUILDING: DrawLevelBuildingState(level); break;
1301     case LEVEL_STATE_BATTLE: DrawLevelBattleState(level); break;
1302     case LEVEL_STATE_WON_WAVE: DrawLevelReportWonWave(level); break;
1303     case LEVEL_STATE_LOST_WAVE: DrawLevelReportLostWave(level); break;
1304     default: break;
1305   }
1306
1307   DrawLevelHud(level);
1308 }
1309
1310 void UpdateLevel(Level *level)
1311 {
1312   if (level->state == LEVEL_STATE_BATTLE)
1313   {
1314     int activeWaves = 0;
1315     for (int i = 0; i < 10; i++)
1316     {
1317       EnemyWave *wave = &level->waves[i];
1318       if (wave->spawned >= wave->count || wave->wave != level->currentWave)
1319       {
1320         continue;
1321       }
1322       activeWaves++;
1323       wave->timeToSpawnNext -= gameTime.deltaTime;
1324       if (wave->timeToSpawnNext <= 0.0f)
1325       {
1326         Enemy *enemy = EnemyTryAdd(wave->enemyType, wave->spawnPosition.x, wave->spawnPosition.y);
1327         if (enemy)
1328         {
1329           wave->timeToSpawnNext = wave->interval;
1330           wave->spawned++;
1331         }
1332       }
1333     }
1334     if (GetTowerByType(TOWER_TYPE_BASE) == 0) {
1335       level->waveEndTimer += gameTime.deltaTime;
1336       if (level->waveEndTimer >= 2.0f)
1337       {
1338         level->nextState = LEVEL_STATE_LOST_WAVE;
1339       }
1340     }
1341     else if (activeWaves == 0 && EnemyCount() == 0)
1342     {
1343       level->waveEndTimer += gameTime.deltaTime;
1344       if (level->waveEndTimer >= 2.0f)
1345       {
1346         level->nextState = LEVEL_STATE_WON_WAVE;
1347       }
1348     }
1349   }
1350
1351   PathFindingMapUpdate();
1352   EnemyUpdate();
1353   TowerUpdate();
1354   ProjectileUpdate();
1355   ParticleUpdate();
1356
1357   if (level->nextState == LEVEL_STATE_RESET)
1358   {
1359     InitLevel(level);
1360   }
1361
1362   if (level->nextState == LEVEL_STATE_BATTLE)
1363   {
1364     InitBattleStateConditions(level);
1365   }
1366
1367   if (level->nextState == LEVEL_STATE_WON_WAVE)
1368   {
1369     level->currentWave++;
1370     level->state = LEVEL_STATE_WON_WAVE;
1371   }
1372
1373   if (level->nextState == LEVEL_STATE_LOST_WAVE)
1374   {
1375     level->state = LEVEL_STATE_LOST_WAVE;
1376   }
1377
1378   if (level->nextState == LEVEL_STATE_BUILDING)
1379   {
1380     level->state = LEVEL_STATE_BUILDING;
1381   }
1382
1383   if (level->nextState == LEVEL_STATE_WON_LEVEL)
1384   {
1385     // make something of this later
1386     InitLevel(level);
1387   }
1388
1389   level->nextState = LEVEL_STATE_NONE;
1390 }
1391
1392 float nextSpawnTime = 0.0f;
1393
1394 void ResetGame()
1395 {
1396   InitLevel(currentLevel);
1397 }
1398
1399 void InitGame()
1400 {
1401   TowerInit();
1402   EnemyInit();
1403   ProjectileInit();
1404   ParticleInit();
1405   PathfindingMapInit(20, 20, (Vector3){-10.0f, 0.0f, -10.0f}, 1.0f);
1406
1407   currentLevel = levels;
1408   InitLevel(currentLevel);
1409 }
1410
1411 //# Immediate GUI functions
1412
1413 int Button(const char *text, int x, int y, int width, int height, ButtonState *state)
1414 {
1415   Rectangle bounds = {x, y, width, height};
1416   int isPressed = 0;
1417   int isSelected = state && state->isSelected;
1418   if (CheckCollisionPointRec(GetMousePosition(), bounds) && !guiState.isBlocked && !state->isDisabled)
1419   {
1420     Color color = isSelected ? DARKGRAY : GRAY;
1421     DrawRectangle(x, y, width, height, color);
1422     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
1423     {
1424       isPressed = 1;
1425     }
1426     guiState.isBlocked = 1;
1427   }
1428   else
1429   {
1430     Color color = isSelected ? WHITE : LIGHTGRAY;
1431     DrawRectangle(x, y, width, height, color);
1432   }
1433   Font font = GetFontDefault();
1434   Vector2 textSize = MeasureTextEx(font, text, font.baseSize * 2.0f, 1);
1435   Color textColor = state->isDisabled ? GRAY : BLACK;
1436   DrawTextEx(font, text, (Vector2){x + width / 2 - textSize.x / 2, y + height / 2 - textSize.y / 2}, font.baseSize * 2.0f, 1, textColor);
1437   return isPressed;
1438 }
1439
1440 //# Main game loop
1441
1442 void GameUpdate()
1443 {
1444   float dt = GetFrameTime();
1445   // cap maximum delta time to 0.1 seconds to prevent large time steps
1446   if (dt > 0.1f) dt = 0.1f;
1447   gameTime.time += dt;
1448   gameTime.deltaTime = dt;
1449
1450   UpdateLevel(currentLevel);
1451 }
1452
1453 int main(void)
1454 {
1455   int screenWidth, screenHeight;
1456   GetPreferredSize(&screenWidth, &screenHeight);
1457   InitWindow(screenWidth, screenHeight, "Tower defense");
1458   SetTargetFPS(30);
1459
1460   InitGame();
1461
1462   while (!WindowShouldClose())
1463   {
1464     if (IsPaused()) {
1465       // canvas is not visible in browser - do nothing
1466       continue;
1467     }
1468
1469     BeginDrawing();
1470     ClearBackground(DARKBLUE);
1471
1472     GameUpdate();
1473     DrawLevel(currentLevel);
1474
1475     EndDrawing();
1476   }
1477
1478   CloseWindow();
1479
1480   return 0;
1481 }

  1 #ifndef TD_TUT_2_MAIN_H
  2 #define TD_TUT_2_MAIN_H
  3
  4 #include <inttypes.h>
  5
  6 #include "raylib.h"
  7 #include "preferred_size.h"
  8
  9 //# Declarations
 10
 11 #define ENEMY_MAX_PATH_COUNT 8
 12 #define ENEMY_MAX_COUNT 400
 13 #define ENEMY_TYPE_NONE 0
 14 #define ENEMY_TYPE_MINION 1
 15
 16 #define PARTICLE_MAX_COUNT 400
 17 #define PARTICLE_TYPE_NONE 0
 18 #define PARTICLE_TYPE_EXPLOSION 1
 19
 20 typedef struct Particle
 21 {
 22   uint8_t particleType;
 23   float spawnTime;
 24   float lifetime;
 25   Vector3 position;
 26   Vector3 velocity;
 27 } Particle;
 28
 29 #define TOWER_MAX_COUNT 400
 30 #define TOWER_TYPE_NONE 0
 31 #define TOWER_TYPE_BASE 1
 32 #define TOWER_TYPE_GUN 2
 33 #define TOWER_TYPE_WALL 3
 34
 35 typedef struct Tower
 36 {
 37   int16_t x, y;
 38   uint8_t towerType;
 39   float cooldown;
 40   float damage;
 41 } Tower;
 42
 43 typedef struct GameTime
 44 {
 45   float time;
 46   float deltaTime;
 47 } GameTime;
 48
 49 typedef struct ButtonState {
 50   char isSelected;
 51   char isDisabled;
 52 } ButtonState;
 53
 54 typedef struct GUIState {
 55   int isBlocked;
 56 } GUIState;
 57
 58 GUIState guiState = {0};
 59 GameTime gameTime = {0};
 60 Tower towers[TOWER_MAX_COUNT];
 61 int towerCount = 0;
 62
 63 typedef enum LevelState
 64 {
 65   LEVEL_STATE_NONE,
 66   LEVEL_STATE_BUILDING,
 67   LEVEL_STATE_BATTLE,
 68   LEVEL_STATE_WON_WAVE,
 69   LEVEL_STATE_LOST_WAVE,
 70   LEVEL_STATE_WON_LEVEL,
 71   LEVEL_STATE_RESET,
 72 } LevelState;
 73
 74 typedef struct EnemyWave {
 75   uint8_t enemyType;
 76   uint8_t wave;
 77   uint16_t count;
 78   float interval;
 79   float delay;
 80   Vector2 spawnPosition;
 81
 82   uint16_t spawned;
 83   float timeToSpawnNext;
 84 } EnemyWave;
 85
 86 typedef struct Level
 87 {
 88   LevelState state;
 89   LevelState nextState;
 90   Camera3D camera;
 91   int placementMode;
 92
 93   int initialGold;
 94   int playerGold;
 95
 96   EnemyWave waves[10];
 97   int currentWave;
 98   float waveEndTimer;
 99 } Level;
100
101 typedef struct DeltaSrc
102 {
103   char x, y;
104 } DeltaSrc;
105
106 typedef struct PathfindingMap
107 {
108   int width, height;
109   float scale;
110   float *distances;
111   long *towerIndex;
112   DeltaSrc *deltaSrc;
113   float maxDistance;
114   Matrix toMapSpace;
115   Matrix toWorldSpace;
116 } PathfindingMap;
117
118 // when we execute the pathfinding algorithm, we need to store the active nodes
119 // in a queue. Each node has a position, a distance from the start, and the
120 // position of the node that we came from.
121 typedef struct PathfindingNode
122 {
123   int16_t x, y, fromX, fromY;
124   float distance;
125 } PathfindingNode;
126
127 typedef struct EnemyId
128 {
129   uint16_t index;
130   uint16_t generation;
131 } EnemyId;
132
133 typedef struct EnemyClassConfig
134 {
135   float speed;
136   float health;
137   float radius;
138   float maxAcceleration;
139   float requiredContactTime;
140   float explosionDamage;
141   float explosionRange;
142   float explosionPushbackPower;
143   int goldValue;
144 } EnemyClassConfig;
145
146 typedef struct Enemy
147 {
148   int16_t currentX, currentY;
149   int16_t nextX, nextY;
150   Vector2 simPosition;
151   Vector2 simVelocity;
152   uint16_t generation;
153   float startMovingTime;
154   float damage, futureDamage;
155   float contactTime;
156   uint8_t enemyType;
157   uint8_t movePathCount;
158   Vector2 movePath[ENEMY_MAX_PATH_COUNT];
159 } Enemy;
160
161 Enemy enemies[ENEMY_MAX_COUNT];
162 int enemyCount = 0;
163
164 EnemyClassConfig enemyClassConfigs[] = {
165     [ENEMY_TYPE_MINION] = {
166       .health = 3.0f,
167       .speed = 1.0f,
168       .radius = 0.25f,
169       .maxAcceleration = 1.0f,
170       .explosionDamage = 1.0f,
171       .requiredContactTime = 0.5f,
172       .explosionRange = 1.0f,
173       .explosionPushbackPower = 0.25f,
174       .goldValue = 1,
175     },
176 };
177
178 #define PROJECTILE_MAX_COUNT 1200
179 #define PROJECTILE_TYPE_NONE 0
180 #define PROJECTILE_TYPE_BULLET 1
181
182 typedef struct Projectile
183 {
184   uint8_t projectileType;
185   float shootTime;
186   float arrivalTime;
187   float damage;
188   Vector2 position;
189   Vector2 target;
190   Vector2 directionNormal;
191   EnemyId targetEnemy;
192 } Projectile;
193
194 //# Function declarations
195 float TowerGetMaxHealth(Tower *tower);
196 int Button(const char *text, int x, int y, int width, int height, ButtonState *state);
197 int EnemyAddDamage(Enemy *enemy, float damage);
198
199 #endif

  1 #include "raylib.h"
  2 #include "preferred_size.h"
  3
  4 // Since the canvas size is not known at compile time, we need to query it at runtime;
  5 // the following platform specific code obtains the canvas size and we will use this
  6 // size as the preferred size for the window at init time. We're ignoring here the
  7 // possibility of the canvas size changing during runtime - this would require to
  8 // poll the canvas size in the game loop or establishing a callback to be notified
  9
 10 #ifdef PLATFORM_WEB
 11 #include <emscripten.h>
 12 EMSCRIPTEN_RESULT emscripten_get_element_css_size(const char *target, double *width, double *height);
 13
 14 void GetPreferredSize(int *screenWidth, int *screenHeight)
 15 {
 16   double canvasWidth, canvasHeight;
 17   emscripten_get_element_css_size("#" CANVAS_NAME, &canvasWidth, &canvasHeight);
 18   *screenWidth = (int)canvasWidth;
 19   *screenHeight = (int)canvasHeight;
 20   TraceLog(LOG_INFO, "preferred size for %s: %d %d", CANVAS_NAME, *screenWidth, *screenHeight);
 21 }
 22
 23 int IsPaused()
 24 {
 25   const char *js = "(function(){\n"
 26   "  var canvas = document.getElementById(\"" CANVAS_NAME "\");\n"
 27   "  var rect = canvas.getBoundingClientRect();\n"
 28   "  var isVisible = (\n"
 29   "    rect.top >= 0 &&\n"
 30   "    rect.left >= 0 &&\n"
 31   "    rect.bottom <= (window.innerHeight || document.documentElement.clientHeight) &&\n"
 32   "    rect.right <= (window.innerWidth || document.documentElement.clientWidth)\n"
 33   "  );\n"
 34   "  return isVisible ? 0 : 1;\n"
 35   "})()";
 36   return emscripten_run_script_int(js);
 37 }
 38
 39 #else
 40 void GetPreferredSize(int *screenWidth, int *screenHeight)
 41 {
 42   *screenWidth = 600;
 43   *screenHeight = 240;
 44 }
 45 int IsPaused()
 46 {
 47   return 0;
 48 }
 49 #endif

  1 #ifndef PREFERRED_SIZE_H
  2 #define PREFERRED_SIZE_H
  3
  4 void GetPreferredSize(int *screenWidth, int *screenHeight);
  5 int IsPaused();
  6
  7 #endif

Another change you may notice is, that the code files are now in a subdirectory instead of a flat file like it was before - this reflects how I am organizing the code files for the tutorial steps here. In a real project, this would probably be called "src". If a project grows bigger, it's good practice to introduce subdirectories for different parts of the application, but I don't think this tutorial will get that far.

Anyway, when refactoring, it's always good to be able to do smaller steps while still being able to compile the application to test if everything is still working. Since we are only moving code around and don't do much else, this should be save, but nothing is more annoying than having changed 2000 lines of code and then having to find out what went wrong.

After moving the struct and function declarations into the header file, let's start extracting the enemy parts:

td-tut-38/td_main.c
td-tut-38/td_main.h
td-tut-38/enemy.c
td-tut-38/preferred_size.c
td-tut-38/preferred_size.h
💾

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 //# Variables
  7 GUIState guiState = {0};
  8 GameTime gameTime = {0};
  9 Tower towers[TOWER_MAX_COUNT];
 10 int towerCount = 0;
 11
 12 Level levels[] = {
 13   [0] = {
 14     .state = LEVEL_STATE_BUILDING,
 15     .initialGold = 10,
 16     .waves[0] = {
 17       .enemyType = ENEMY_TYPE_MINION,
 18       .wave = 0,
 19       .count = 10,
 20       .interval = 1.0f,
 21       .delay = 1.0f,
 22       .spawnPosition = {0, 6},
 23     },
 24     .waves[1] = {
 25       .enemyType = ENEMY_TYPE_MINION,
 26       .wave = 1,
 27       .count = 20,
 28       .interval = 0.5f,
 29       .delay = 1.0f,
 30       .spawnPosition = {0, 6},
 31     },
 32     .waves[2] = {
 33       .enemyType = ENEMY_TYPE_MINION,
 34       .wave = 2,
 35       .count = 30,
 36       .interval = 0.25f,
 37       .delay = 1.0f,
 38       .spawnPosition = {0, 6},
 39     }
 40   },
 41 };
 42
 43 Level *currentLevel = levels;
 44
 45 Particle particles[PARTICLE_MAX_COUNT];
 46 int particleCount = 0;
 47
 48 //# Particle system
 49
 50 void ParticleInit()
 51 {
 52   for (int i = 0; i < PARTICLE_MAX_COUNT; i++)
 53   {
 54     particles[i] = (Particle){0};
 55   }
 56   particleCount = 0;
 57 }
 58
 59 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime)
 60 {
 61   if (particleCount >= PARTICLE_MAX_COUNT)
 62   {
 63     return;
 64   }
 65
 66   int index = -1;
 67   for (int i = 0; i < particleCount; i++)
 68   {
 69     if (particles[i].particleType == PARTICLE_TYPE_NONE)
 70     {
 71       index = i;
 72       break;
 73     }
 74   }
 75
 76   if (index == -1)
 77   {
 78     index = particleCount++;
 79   }
 80
 81   Particle *particle = &particles[index];
 82   particle->particleType = particleType;
 83   particle->spawnTime = gameTime.time;
 84   particle->lifetime = lifetime;
 85   particle->position = position;
 86   particle->velocity = velocity;
 87 }
 88
 89 void ParticleUpdate()
 90 {
 91   for (int i = 0; i < particleCount; i++)
 92   {
 93     Particle *particle = &particles[i];
 94     if (particle->particleType == PARTICLE_TYPE_NONE)
 95     {
 96       continue;
 97     }
 98
 99     float age = gameTime.time - particle->spawnTime;
100
101     if (particle->lifetime > age)
102     {
103       particle->position = Vector3Add(particle->position, Vector3Scale(particle->velocity, gameTime.deltaTime));
104     }
105     else {
106       particle->particleType = PARTICLE_TYPE_NONE;
107     }
108   }
109 }
110
111 void DrawExplosionParticle(Particle *particle, float transition)
112 {
113   float size = 1.2f * (1.0f - transition);
114   Color startColor = WHITE;
115   Color endColor = RED;
116   Color color = ColorLerp(startColor, endColor, transition);
117   DrawCube(particle->position, size, size, size, color);
118 }
119
120 void ParticleDraw()
121 {
122   for (int i = 0; i < particleCount; i++)
123   {
124     Particle particle = particles[i];
125     if (particle.particleType == PARTICLE_TYPE_NONE)
126     {
127       continue;
128     }
129
130     float age = gameTime.time - particle.spawnTime;
131     float transition = age / particle.lifetime;
132     switch (particle.particleType)
133     {
134     case PARTICLE_TYPE_EXPLOSION:
135       DrawExplosionParticle(&particle, transition);
136       break;
137     default:
138       DrawCube(particle.position, 0.3f, 0.5f, 0.3f, RED);
139       break;
140     }
141   }
142 }
143
144 //# Pathfinding map
145
146 // The queue is a simple array of nodes, we add nodes to the end and remove
147 // nodes from the front. We keep the array around to avoid unnecessary allocations
148 static PathfindingNode *pathfindingNodeQueue = 0;
149 static int pathfindingNodeQueueCount = 0;
150 static int pathfindingNodeQueueCapacity = 0;
151
152 // The pathfinding map stores the distances from the castle to each cell in the map.
153 PathfindingMap pathfindingMap = {0};
154
155 void PathfindingMapInit(int width, int height, Vector3 translate, float scale)
156 {
157   // transforming between map space and world space allows us to adapt
158   // position and scale of the map without changing the pathfinding data
159   pathfindingMap.toWorldSpace = MatrixTranslate(translate.x, translate.y, translate.z);
160   pathfindingMap.toWorldSpace = MatrixMultiply(pathfindingMap.toWorldSpace, MatrixScale(scale, scale, scale));
161   pathfindingMap.toMapSpace = MatrixInvert(pathfindingMap.toWorldSpace);
162   pathfindingMap.width = width;
163   pathfindingMap.height = height;
164   pathfindingMap.scale = scale;
165   pathfindingMap.distances = (float *)MemAlloc(width * height * sizeof(float));
166   for (int i = 0; i < width * height; i++)
167   {
168     pathfindingMap.distances[i] = -1.0f;
169   }
170
171   pathfindingMap.towerIndex = (long *)MemAlloc(width * height * sizeof(long));
172   pathfindingMap.deltaSrc = (DeltaSrc *)MemAlloc(width * height * sizeof(DeltaSrc));
173 }
174
175 float PathFindingGetDistance(int mapX, int mapY)
176 {
177   if (mapX < 0 || mapX >= pathfindingMap.width || mapY < 0 || mapY >= pathfindingMap.height)
178   {
179     // when outside the map, we return the manhattan distance to the castle (0,0)
180     return fabsf((float)mapX) + fabsf((float)mapY);
181   }
182
183   return pathfindingMap.distances[mapY * pathfindingMap.width + mapX];
184 }
185
186 void PathFindingNodePush(int16_t x, int16_t y, int16_t fromX, int16_t fromY, float distance)
187 {
188   if (pathfindingNodeQueueCount >= pathfindingNodeQueueCapacity)
189   {
190     pathfindingNodeQueueCapacity = pathfindingNodeQueueCapacity == 0 ? 256 : pathfindingNodeQueueCapacity * 2;
191     // we use MemAlloc/MemRealloc to allocate memory for the queue
192     // I am not entirely sure if MemRealloc allows passing a null pointer
193     // so we check if the pointer is null and use MemAlloc in that case
194     if (pathfindingNodeQueue == 0)
195     {
196       pathfindingNodeQueue = (PathfindingNode *)MemAlloc(pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
197     }
198     else
199     {
200       pathfindingNodeQueue = (PathfindingNode *)MemRealloc(pathfindingNodeQueue, pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
201     }
202   }
203
204   PathfindingNode *node = &pathfindingNodeQueue[pathfindingNodeQueueCount++];
205   node->x = x;
206   node->y = y;
207   node->fromX = fromX;
208   node->fromY = fromY;
209   node->distance = distance;
210 }
211
212 PathfindingNode *PathFindingNodePop()
213 {
214   if (pathfindingNodeQueueCount == 0)
215   {
216     return 0;
217   }
218   // we return the first node in the queue; we want to return a pointer to the node
219   // so we can return 0 if the queue is empty.
220   // We should _not_ return a pointer to the element in the list, because the list
221   // may be reallocated and the pointer would become invalid. Or the
222   // popped element is overwritten by the next push operation.
223   // Using static here means that the variable is permanently allocated.
224   static PathfindingNode node;
225   node = pathfindingNodeQueue[0];
226   // we shift all nodes one position to the front
227   for (int i = 1; i < pathfindingNodeQueueCount; i++)
228   {
229     pathfindingNodeQueue[i - 1] = pathfindingNodeQueue[i];
230   }
231   --pathfindingNodeQueueCount;
232   return &node;
233 }
234
235 // transform a world position to a map position in the array;
236 // returns true if the position is inside the map
237 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY)
238 {
239   Vector3 mapPosition = Vector3Transform(worldPosition, pathfindingMap.toMapSpace);
240   *mapX = (int16_t)mapPosition.x;
241   *mapY = (int16_t)mapPosition.z;
242   return *mapX >= 0 && *mapX < pathfindingMap.width && *mapY >= 0 && *mapY < pathfindingMap.height;
243 }
244
245 void PathFindingMapUpdate()
246 {
247   const int castleX = 0, castleY = 0;
248   int16_t castleMapX, castleMapY;
249   if (!PathFindingFromWorldToMapPosition((Vector3){castleX, 0.0f, castleY}, &castleMapX, &castleMapY))
250   {
251     return;
252   }
253   int width = pathfindingMap.width, height = pathfindingMap.height;
254
255   // reset the distances to -1
256   for (int i = 0; i < width * height; i++)
257   {
258     pathfindingMap.distances[i] = -1.0f;
259   }
260   // reset the tower indices
261   for (int i = 0; i < width * height; i++)
262   {
263     pathfindingMap.towerIndex[i] = -1;
264   }
265   // reset the delta src
266   for (int i = 0; i < width * height; i++)
267   {
268     pathfindingMap.deltaSrc[i].x = 0;
269     pathfindingMap.deltaSrc[i].y = 0;
270   }
271
272   for (int i = 0; i < towerCount; i++)
273   {
274     Tower *tower = &towers[i];
275     if (tower->towerType == TOWER_TYPE_NONE || tower->towerType == TOWER_TYPE_BASE)
276     {
277       continue;
278     }
279     int16_t mapX, mapY;
280     // technically, if the tower cell scale is not in sync with the pathfinding map scale,
281     // this would not work correctly and needs to be refined to allow towers covering multiple cells
282     // or having multiple towers in one cell; for simplicity, we assume that the tower covers exactly
283     // one cell. For now.
284     if (!PathFindingFromWorldToMapPosition((Vector3){tower->x, 0.0f, tower->y}, &mapX, &mapY))
285     {
286       continue;
287     }
288     int index = mapY * width + mapX;
289     pathfindingMap.towerIndex[index] = i;
290   }
291
292   // we start at the castle and add the castle to the queue
293   pathfindingMap.maxDistance = 0.0f;
294   pathfindingNodeQueueCount = 0;
295   PathFindingNodePush(castleMapX, castleMapY, castleMapX, castleMapY, 0.0f);
296   PathfindingNode *node = 0;
297   while ((node = PathFindingNodePop()))
298   {
299     if (node->x < 0 || node->x >= width || node->y < 0 || node->y >= height)
300     {
301       continue;
302     }
303     int index = node->y * width + node->x;
304     if (pathfindingMap.distances[index] >= 0 && pathfindingMap.distances[index] <= node->distance)
305     {
306       continue;
307     }
308
309     int deltaX = node->x - node->fromX;
310     int deltaY = node->y - node->fromY;
311     // even if the cell is blocked by a tower, we still may want to store the direction
312     // (though this might not be needed, IDK right now)
313     pathfindingMap.deltaSrc[index].x = (char) deltaX;
314     pathfindingMap.deltaSrc[index].y = (char) deltaY;
315
316     // we skip nodes that are blocked by towers
317     if (pathfindingMap.towerIndex[index] >= 0)
318     {
319       node->distance += 8.0f;
320     }
321     pathfindingMap.distances[index] = node->distance;
322     pathfindingMap.maxDistance = fmaxf(pathfindingMap.maxDistance, node->distance);
323     PathFindingNodePush(node->x, node->y + 1, node->x, node->y, node->distance + 1.0f);
324     PathFindingNodePush(node->x, node->y - 1, node->x, node->y, node->distance + 1.0f);
325     PathFindingNodePush(node->x + 1, node->y, node->x, node->y, node->distance + 1.0f);
326     PathFindingNodePush(node->x - 1, node->y, node->x, node->y, node->distance + 1.0f);
327   }
328 }
329
330 void PathFindingMapDraw()
331 {
332   float cellSize = pathfindingMap.scale * 0.9f;
333   float highlightDistance = fmodf(GetTime() * 4.0f, pathfindingMap.maxDistance);
334   for (int x = 0; x < pathfindingMap.width; x++)
335   {
336     for (int y = 0; y < pathfindingMap.height; y++)
337     {
338       float distance = pathfindingMap.distances[y * pathfindingMap.width + x];
339       float colorV = distance < 0 ? 0 : fminf(distance / pathfindingMap.maxDistance, 1.0f);
340       Color color = distance < 0 ? BLUE : (Color){fminf(colorV, 1.0f) * 255, 0, 0, 255};
341       Vector3 position = Vector3Transform((Vector3){x, -0.25f, y}, pathfindingMap.toWorldSpace);
342       // animate the distance "wave" to show how the pathfinding algorithm expands
343       // from the castle
344       if (distance + 0.5f > highlightDistance && distance - 0.5f < highlightDistance)
345       {
346         color = BLACK;
347       }
348       DrawCube(position, cellSize, 0.1f, cellSize, color);
349     }
350   }
351 }
352
353 Vector2 PathFindingGetGradient(Vector3 world)
354 {
355   int16_t mapX, mapY;
356   if (PathFindingFromWorldToMapPosition(world, &mapX, &mapY))
357   {
358     DeltaSrc delta = pathfindingMap.deltaSrc[mapY * pathfindingMap.width + mapX];
359     return (Vector2){(float)-delta.x, (float)-delta.y};
360   }
361   // fallback to a simple gradient calculation
362   float n = PathFindingGetDistance(mapX, mapY - 1);
363   float s = PathFindingGetDistance(mapX, mapY + 1);
364   float w = PathFindingGetDistance(mapX - 1, mapY);
365   float e = PathFindingGetDistance(mapX + 1, mapY);
366   return (Vector2){w - e + 0.25f, n - s + 0.125f};
367 }
368
369 //# Projectiles
370 Projectile projectiles[PROJECTILE_MAX_COUNT];
371 int projectileCount = 0;
372
373 void ProjectileInit()
374 {
375   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
376   {
377     projectiles[i] = (Projectile){0};
378   }
379 }
380
381 void ProjectileDraw()
382 {
383   for (int i = 0; i < projectileCount; i++)
384   {
385     Projectile projectile = projectiles[i];
386     if (projectile.projectileType == PROJECTILE_TYPE_NONE)
387     {
388       continue;
389     }
390     float transition = (gameTime.time - projectile.shootTime) / (projectile.arrivalTime - projectile.shootTime);
391     if (transition >= 1.0f)
392     {
393       continue;
394     }
395     Vector2 position = Vector2Lerp(projectile.position, projectile.target, transition);
396     float x = position.x;
397     float y = position.y;
398     float dx = projectile.directionNormal.x;
399     float dy = projectile.directionNormal.y;
400     for (float d = 1.0f; d > 0.0f; d -= 0.25f)
401     {
402       x -= dx * 0.1f;
403       y -= dy * 0.1f;
404       float size = 0.1f * d;
405       DrawCube((Vector3){x, 0.2f, y}, size, size, size, RED);
406     }
407   }
408 }
409
410 void ProjectileUpdate()
411 {
412   for (int i = 0; i < projectileCount; i++)
413   {
414     Projectile *projectile = &projectiles[i];
415     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
416     {
417       continue;
418     }
419     float transition = (gameTime.time - projectile->shootTime) / (projectile->arrivalTime - projectile->shootTime);
420     if (transition >= 1.0f)
421     {
422       projectile->projectileType = PROJECTILE_TYPE_NONE;
423       Enemy *enemy = EnemyTryResolve(projectile->targetEnemy);
424       if (enemy)
425       {
426         EnemyAddDamage(enemy, projectile->damage);
427       }
428       continue;
429     }
430   }
431 }
432
433 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage)
434 {
435   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
436   {
437     Projectile *projectile = &projectiles[i];
438     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
439     {
440       projectile->projectileType = projectileType;
441       projectile->shootTime = gameTime.time;
442       projectile->arrivalTime = gameTime.time + Vector2Distance(position, target) / speed;
443       projectile->damage = damage;
444       projectile->position = position;
445       projectile->target = target;
446       projectile->directionNormal = Vector2Normalize(Vector2Subtract(target, position));
447       projectile->targetEnemy = EnemyGetId(enemy);
448       projectileCount = projectileCount <= i ? i + 1 : projectileCount;
449       return projectile;
450     }
451   }
452   return 0;
453 }
454
455 //# Towers
456
457 void TowerInit()
458 {
459   for (int i = 0; i < TOWER_MAX_COUNT; i++)
460   {
461     towers[i] = (Tower){0};
462   }
463   towerCount = 0;
464 }
465
466 Tower *TowerGetAt(int16_t x, int16_t y)
467 {
468   for (int i = 0; i < towerCount; i++)
469   {
470     if (towers[i].x == x && towers[i].y == y)
471     {
472       return &towers[i];
473     }
474   }
475   return 0;
476 }
477
478 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y)
479 {
480   if (towerCount >= TOWER_MAX_COUNT)
481   {
482     return 0;
483   }
484
485   Tower *tower = TowerGetAt(x, y);
486   if (tower)
487   {
488     return 0;
489   }
490
491   tower = &towers[towerCount++];
492   tower->x = x;
493   tower->y = y;
494   tower->towerType = towerType;
495   tower->cooldown = 0.0f;
496   tower->damage = 0.0f;
497   return tower;
498 }
499
500 Tower *GetTowerByType(uint8_t towerType)
501 {
502   for (int i = 0; i < towerCount; i++)
503   {
504     if (towers[i].towerType == towerType)
505     {
506       return &towers[i];
507     }
508   }
509   return 0;
510 }
511
512 int GetTowerCosts(uint8_t towerType)
513 {
514   switch (towerType)
515   {
516   case TOWER_TYPE_BASE:
517     return 0;
518   case TOWER_TYPE_GUN:
519     return 6;
520   case TOWER_TYPE_WALL:
521     return 2;
522   }
523   return 0;
524 }
525
526 float TowerGetMaxHealth(Tower *tower)
527 {
528   switch (tower->towerType)
529   {
530   case TOWER_TYPE_BASE:
531     return 10.0f;
532   case TOWER_TYPE_GUN:
533     return 3.0f;
534   case TOWER_TYPE_WALL:
535     return 5.0f;
536   }
537   return 0.0f;
538 }
539
540 void TowerDraw()
541 {
542   for (int i = 0; i < towerCount; i++)
543   {
544     Tower tower = towers[i];
545     DrawCube((Vector3){tower.x, 0.125f, tower.y}, 1.0f, 0.25f, 1.0f, GRAY);
546     switch (tower.towerType)
547     {
548     case TOWER_TYPE_BASE:
549       DrawCube((Vector3){tower.x, 0.4f, tower.y}, 0.8f, 0.8f, 0.8f, MAROON);
550       break;
551     case TOWER_TYPE_GUN:
552       DrawCube((Vector3){tower.x, 0.2f, tower.y}, 0.8f, 0.4f, 0.8f, DARKPURPLE);
553       break;
554     case TOWER_TYPE_WALL:
555       DrawCube((Vector3){tower.x, 0.5f, tower.y}, 1.0f, 1.0f, 1.0f, LIGHTGRAY);
556       break;
557     }
558   }
559 }
560
561 void TowerGunUpdate(Tower *tower)
562 {
563   if (tower->cooldown <= 0)
564   {
565     Enemy *enemy = EnemyGetClosestToCastle(tower->x, tower->y, 3.0f);
566     if (enemy)
567     {
568       tower->cooldown = 0.125f;
569       // shoot the enemy; determine future position of the enemy
570       float bulletSpeed = 1.0f;
571       float bulletDamage = 3.0f;
572       Vector2 velocity = enemy->simVelocity;
573       Vector2 futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &velocity, 0);
574       Vector2 towerPosition = {tower->x, tower->y};
575       float eta = Vector2Distance(towerPosition, futurePosition) / bulletSpeed;
576       for (int i = 0; i < 8; i++) {
577         velocity = enemy->simVelocity;
578         futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime + eta, &velocity, 0);
579         float distance = Vector2Distance(towerPosition, futurePosition);
580         float eta2 = distance / bulletSpeed;
581         if (fabs(eta - eta2) < 0.01f) {
582           break;
583         }
584         eta = (eta2 + eta) * 0.5f;
585       }
586       ProjectileTryAdd(PROJECTILE_TYPE_BULLET, enemy, towerPosition, futurePosition,
587         bulletSpeed, bulletDamage);
588       enemy->futureDamage += bulletDamage;
589     }
590   }
591   else
592   {
593     tower->cooldown -= gameTime.deltaTime;
594   }
595 }
596
597 void TowerUpdate()
598 {
599   for (int i = 0; i < towerCount; i++)
600   {
601     Tower *tower = &towers[i];
602     switch (tower->towerType)
603     {
604     case TOWER_TYPE_GUN:
605       TowerGunUpdate(tower);
606       break;
607     }
608   }
609 }
610
611 //# Game
612
613 void InitLevel(Level *level)
614 {
615   TowerInit();
616   EnemyInit();
617   ProjectileInit();
618   ParticleInit();
619   TowerTryAdd(TOWER_TYPE_BASE, 0, 0);
620
621   level->placementMode = 0;
622   level->state = LEVEL_STATE_BUILDING;
623   level->nextState = LEVEL_STATE_NONE;
624   level->playerGold = level->initialGold;
625
626   Camera *camera = &level->camera;
627   camera->position = (Vector3){1.0f, 12.0f, 6.5f};
628   camera->target = (Vector3){0.0f, 0.5f, 1.0f};
629   camera->up = (Vector3){0.0f, 1.0f, 0.0f};
630   camera->fovy = 45.0f;
631   camera->projection = CAMERA_PERSPECTIVE;
632 }
633
634 void DrawLevelHud(Level *level)
635 {
636   const char *text = TextFormat("Gold: %d", level->playerGold);
637   Font font = GetFontDefault();
638   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 120, 10}, font.baseSize * 2.0f, 2.0f, BLACK);
639   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 122, 8}, font.baseSize * 2.0f, 2.0f, YELLOW);
640 }
641
642 void DrawLevelReportLostWave(Level *level)
643 {
644   BeginMode3D(level->camera);
645   DrawGrid(10, 1.0f);
646   TowerDraw();
647   EnemyDraw();
648   ProjectileDraw();
649   ParticleDraw();
650   guiState.isBlocked = 0;
651   EndMode3D();
652
653   const char *text = "Wave lost";
654   int textWidth = MeasureText(text, 20);
655   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
656
657   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
658   {
659     level->nextState = LEVEL_STATE_RESET;
660   }
661 }
662
663 int HasLevelNextWave(Level *level)
664 {
665   for (int i = 0; i < 10; i++)
666   {
667     EnemyWave *wave = &level->waves[i];
668     if (wave->wave == level->currentWave)
669     {
670       return 1;
671     }
672   }
673   return 0;
674 }
675
676 void DrawLevelReportWonWave(Level *level)
677 {
678   BeginMode3D(level->camera);
679   DrawGrid(10, 1.0f);
680   TowerDraw();
681   EnemyDraw();
682   ProjectileDraw();
683   ParticleDraw();
684   guiState.isBlocked = 0;
685   EndMode3D();
686
687   const char *text = "Wave won";
688   int textWidth = MeasureText(text, 20);
689   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
690
691
692   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
693   {
694     level->nextState = LEVEL_STATE_RESET;
695   }
696
697   if (HasLevelNextWave(level))
698   {
699     if (Button("Prepare for next wave", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
700     {
701       level->nextState = LEVEL_STATE_BUILDING;
702     }
703   }
704   else {
705     if (Button("Level won", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
706     {
707       level->nextState = LEVEL_STATE_WON_LEVEL;
708     }
709   }
710 }
711
712 void DrawBuildingBuildButton(Level *level, int x, int y, int width, int height, uint8_t towerType, const char *name)
713 {
714   static ButtonState buttonStates[8] = {0};
715   int cost = GetTowerCosts(towerType);
716   const char *text = TextFormat("%s: %d", name, cost);
717   buttonStates[towerType].isSelected = level->placementMode == towerType;
718   buttonStates[towerType].isDisabled = level->playerGold < cost;
719   if (Button(text, x, y, width, height, &buttonStates[towerType]))
720   {
721     level->placementMode = buttonStates[towerType].isSelected ? 0 : towerType;
722   }
723 }
724
725 void DrawLevelBuildingState(Level *level)
726 {
727   BeginMode3D(level->camera);
728   DrawGrid(10, 1.0f);
729   TowerDraw();
730   EnemyDraw();
731   ProjectileDraw();
732   ParticleDraw();
733
734   Ray ray = GetScreenToWorldRay(GetMousePosition(), level->camera);
735   float planeDistance = ray.position.y / -ray.direction.y;
736   float planeX = ray.direction.x * planeDistance + ray.position.x;
737   float planeY = ray.direction.z * planeDistance + ray.position.z;
738   int16_t mapX = (int16_t)floorf(planeX + 0.5f);
739   int16_t mapY = (int16_t)floorf(planeY + 0.5f);
740   if (level->placementMode && !guiState.isBlocked)
741   {
742     DrawCubeWires((Vector3){mapX, 0.2f, mapY}, 1.0f, 0.4f, 1.0f, RED);
743     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
744     {
745       if (TowerTryAdd(level->placementMode, mapX, mapY))
746       {
747         level->playerGold -= GetTowerCosts(level->placementMode);
748         level->placementMode = TOWER_TYPE_NONE;
749       }
750     }
751   }
752
753   guiState.isBlocked = 0;
754
755   EndMode3D();
756
757   static ButtonState buildWallButtonState = {0};
758   static ButtonState buildGunButtonState = {0};
759   buildWallButtonState.isSelected = level->placementMode == TOWER_TYPE_WALL;
760   buildGunButtonState.isSelected = level->placementMode == TOWER_TYPE_GUN;
761
762   DrawBuildingBuildButton(level, 10, 10, 80, 30, TOWER_TYPE_WALL, "Wall");
763   DrawBuildingBuildButton(level, 10, 50, 80, 30, TOWER_TYPE_GUN, "Gun");
764
765   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
766   {
767     level->nextState = LEVEL_STATE_RESET;
768   }
769
770   if (Button("Begin waves", GetScreenWidth() - 160, GetScreenHeight() - 40, 160, 30, 0))
771   {
772     level->nextState = LEVEL_STATE_BATTLE;
773   }
774
775   const char *text = "Building phase";
776   int textWidth = MeasureText(text, 20);
777   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
778 }
779
780 void InitBattleStateConditions(Level *level)
781 {
782   level->state = LEVEL_STATE_BATTLE;
783   level->nextState = LEVEL_STATE_NONE;
784   level->waveEndTimer = 0.0f;
785   for (int i = 0; i < 10; i++)
786   {
787     EnemyWave *wave = &level->waves[i];
788     wave->spawned = 0;
789     wave->timeToSpawnNext = wave->delay;
790   }
791 }
792
793 void DrawLevelBattleState(Level *level)
794 {
795   BeginMode3D(level->camera);
796   DrawGrid(10, 1.0f);
797   TowerDraw();
798   EnemyDraw();
799   ProjectileDraw();
800   ParticleDraw();
801   guiState.isBlocked = 0;
802   EndMode3D();
803
804   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
805   {
806     level->nextState = LEVEL_STATE_RESET;
807   }
808
809   int maxCount = 0;
810   int remainingCount = 0;
811   for (int i = 0; i < 10; i++)
812   {
813     EnemyWave *wave = &level->waves[i];
814     if (wave->wave != level->currentWave)
815     {
816       continue;
817     }
818     maxCount += wave->count;
819     remainingCount += wave->count - wave->spawned;
820   }
821   int aliveCount = EnemyCount();
822   remainingCount += aliveCount;
823
824   const char *text = TextFormat("Battle phase: %03d%%", 100 - remainingCount * 100 / maxCount);
825   int textWidth = MeasureText(text, 20);
826   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
827 }
828
829 void DrawLevel(Level *level)
830 {
831   switch (level->state)
832   {
833     case LEVEL_STATE_BUILDING: DrawLevelBuildingState(level); break;
834     case LEVEL_STATE_BATTLE: DrawLevelBattleState(level); break;
835     case LEVEL_STATE_WON_WAVE: DrawLevelReportWonWave(level); break;
836     case LEVEL_STATE_LOST_WAVE: DrawLevelReportLostWave(level); break;
837     default: break;
838   }
839
840   DrawLevelHud(level);
841 }
842
843 void UpdateLevel(Level *level)
844 {
845   if (level->state == LEVEL_STATE_BATTLE)
846   {
847     int activeWaves = 0;
848     for (int i = 0; i < 10; i++)
849     {
850       EnemyWave *wave = &level->waves[i];
851       if (wave->spawned >= wave->count || wave->wave != level->currentWave)
852       {
853         continue;
854       }
855       activeWaves++;
856       wave->timeToSpawnNext -= gameTime.deltaTime;
857       if (wave->timeToSpawnNext <= 0.0f)
858       {
859         Enemy *enemy = EnemyTryAdd(wave->enemyType, wave->spawnPosition.x, wave->spawnPosition.y);
860         if (enemy)
861         {
862           wave->timeToSpawnNext = wave->interval;
863           wave->spawned++;
864         }
865       }
866     }
867     if (GetTowerByType(TOWER_TYPE_BASE) == 0) {
868       level->waveEndTimer += gameTime.deltaTime;
869       if (level->waveEndTimer >= 2.0f)
870       {
871         level->nextState = LEVEL_STATE_LOST_WAVE;
872       }
873     }
874     else if (activeWaves == 0 && EnemyCount() == 0)
875     {
876       level->waveEndTimer += gameTime.deltaTime;
877       if (level->waveEndTimer >= 2.0f)
878       {
879         level->nextState = LEVEL_STATE_WON_WAVE;
880       }
881     }
882   }
883
884   PathFindingMapUpdate();
885   EnemyUpdate();
886   TowerUpdate();
887   ProjectileUpdate();
888   ParticleUpdate();
889
890   if (level->nextState == LEVEL_STATE_RESET)
891   {
892     InitLevel(level);
893   }
894
895   if (level->nextState == LEVEL_STATE_BATTLE)
896   {
897     InitBattleStateConditions(level);
898   }
899
900   if (level->nextState == LEVEL_STATE_WON_WAVE)
901   {
902     level->currentWave++;
903     level->state = LEVEL_STATE_WON_WAVE;
904   }
905
906   if (level->nextState == LEVEL_STATE_LOST_WAVE)
907   {
908     level->state = LEVEL_STATE_LOST_WAVE;
909   }
910
911   if (level->nextState == LEVEL_STATE_BUILDING)
912   {
913     level->state = LEVEL_STATE_BUILDING;
914   }
915
916   if (level->nextState == LEVEL_STATE_WON_LEVEL)
917   {
918     // make something of this later
919     InitLevel(level);
920   }
921
922   level->nextState = LEVEL_STATE_NONE;
923 }
924
925 float nextSpawnTime = 0.0f;
926
927 void ResetGame()
928 {
929   InitLevel(currentLevel);
930 }
931
932 void InitGame()
933 {
934   TowerInit();
935   EnemyInit();
936   ProjectileInit();
937   ParticleInit();
938   PathfindingMapInit(20, 20, (Vector3){-10.0f, 0.0f, -10.0f}, 1.0f);
939
940   currentLevel = levels;
941   InitLevel(currentLevel);
942 }
943
944 //# Immediate GUI functions
945
946 int Button(const char *text, int x, int y, int width, int height, ButtonState *state)
947 {
948   Rectangle bounds = {x, y, width, height};
949   int isPressed = 0;
950   int isSelected = state && state->isSelected;
951   if (CheckCollisionPointRec(GetMousePosition(), bounds) && !guiState.isBlocked && !state->isDisabled)
952   {
953     Color color = isSelected ? DARKGRAY : GRAY;
954     DrawRectangle(x, y, width, height, color);
955     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
956     {
957       isPressed = 1;
958     }
959     guiState.isBlocked = 1;
960   }
961   else
962   {
963     Color color = isSelected ? WHITE : LIGHTGRAY;
964     DrawRectangle(x, y, width, height, color);
965   }
966   Font font = GetFontDefault();
967   Vector2 textSize = MeasureTextEx(font, text, font.baseSize * 2.0f, 1);
968   Color textColor = state->isDisabled ? GRAY : BLACK;
969   DrawTextEx(font, text, (Vector2){x + width / 2 - textSize.x / 2, y + height / 2 - textSize.y / 2}, font.baseSize * 2.0f, 1, textColor);
970   return isPressed;
971 }
972
973 //# Main game loop
974
975 void GameUpdate()
976 {
977   float dt = GetFrameTime();
978   // cap maximum delta time to 0.1 seconds to prevent large time steps
979   if (dt > 0.1f) dt = 0.1f;
980   gameTime.time += dt;
981   gameTime.deltaTime = dt;
982
983   UpdateLevel(currentLevel);
984 }
985
986 int main(void)
987 {
988   int screenWidth, screenHeight;
989   GetPreferredSize(&screenWidth, &screenHeight);
990   InitWindow(screenWidth, screenHeight, "Tower defense");
991   SetTargetFPS(30);
992
993   InitGame();
994
995   while (!WindowShouldClose())
996   {
997     if (IsPaused()) {
998       // canvas is not visible in browser - do nothing
999       continue;
1000     }
1001
1002     BeginDrawing();
1003     ClearBackground(DARKBLUE);
1004
1005     GameUpdate();
1006     DrawLevel(currentLevel);
1007
1008     EndDrawing();
1009   }
1010
1011   CloseWindow();
1012
1013   return 0;
1014 }

  1 #ifndef TD_TUT_2_MAIN_H
  2 #define TD_TUT_2_MAIN_H
  3
  4 #include <inttypes.h>
  5
  6 #include "raylib.h"
  7 #include "preferred_size.h"
  8
  9 //# Declarations
 10
 11 #define ENEMY_MAX_PATH_COUNT 8
 12 #define ENEMY_MAX_COUNT 400
 13 #define ENEMY_TYPE_NONE 0
 14 #define ENEMY_TYPE_MINION 1
 15
 16 #define PARTICLE_MAX_COUNT 400
 17 #define PARTICLE_TYPE_NONE 0
 18 #define PARTICLE_TYPE_EXPLOSION 1
 19
 20 typedef struct Particle
 21 {
 22   uint8_t particleType;
 23   float spawnTime;
 24   float lifetime;
 25   Vector3 position;
 26   Vector3 velocity;
 27 } Particle;
 28
 29 #define TOWER_MAX_COUNT 400
 30 #define TOWER_TYPE_NONE 0
 31 #define TOWER_TYPE_BASE 1
 32 #define TOWER_TYPE_GUN 2
 33 #define TOWER_TYPE_WALL 3
 34
 35 typedef struct Tower
 36 {
 37   int16_t x, y;
 38   uint8_t towerType;
 39   float cooldown;
 40   float damage;
 41 } Tower;
 42
 43 typedef struct GameTime
 44 {
 45   float time;
 46   float deltaTime;
 47 } GameTime;
 48
 49 typedef struct ButtonState {
 50   char isSelected;
 51   char isDisabled;
 52 } ButtonState;
 53
 54 typedef struct GUIState {
 55   int isBlocked;
 56 } GUIState;
 57
 58 typedef enum LevelState
 59 {
 60   LEVEL_STATE_NONE,
 61   LEVEL_STATE_BUILDING,
 62   LEVEL_STATE_BATTLE,
 63   LEVEL_STATE_WON_WAVE,
 64   LEVEL_STATE_LOST_WAVE,
 65   LEVEL_STATE_WON_LEVEL,
 66   LEVEL_STATE_RESET,
 67 } LevelState;
 68
 69 typedef struct EnemyWave {
 70   uint8_t enemyType;
 71   uint8_t wave;
 72   uint16_t count;
 73   float interval;
 74   float delay;
 75   Vector2 spawnPosition;
 76
 77   uint16_t spawned;
 78   float timeToSpawnNext;
 79 } EnemyWave;
 80
 81 typedef struct Level
 82 {
 83   LevelState state;
 84   LevelState nextState;
 85   Camera3D camera;
 86   int placementMode;
 87
 88   int initialGold;
 89   int playerGold;
 90
 91   EnemyWave waves[10];
 92   int currentWave;
 93   float waveEndTimer;
 94 } Level;
 95
 96 typedef struct DeltaSrc
 97 {
 98   char x, y;
 99 } DeltaSrc;
100
101 typedef struct PathfindingMap
102 {
103   int width, height;
104   float scale;
105   float *distances;
106   long *towerIndex;
107   DeltaSrc *deltaSrc;
108   float maxDistance;
109   Matrix toMapSpace;
110   Matrix toWorldSpace;
111 } PathfindingMap;
112
113 // when we execute the pathfinding algorithm, we need to store the active nodes
114 // in a queue. Each node has a position, a distance from the start, and the
115 // position of the node that we came from.
116 typedef struct PathfindingNode
117 {
118   int16_t x, y, fromX, fromY;
119   float distance;
120 } PathfindingNode;
121
122 typedef struct EnemyId
123 {
124   uint16_t index;
125   uint16_t generation;
126 } EnemyId;
127
128 typedef struct EnemyClassConfig
129 {
130   float speed;
131   float health;
132   float radius;
133   float maxAcceleration;
134   float requiredContactTime;
135   float explosionDamage;
136   float explosionRange;
137   float explosionPushbackPower;
138   int goldValue;
139 } EnemyClassConfig;
140
141 typedef struct Enemy
142 {
143   int16_t currentX, currentY;
144   int16_t nextX, nextY;
145   Vector2 simPosition;
146   Vector2 simVelocity;
147   uint16_t generation;
148   float startMovingTime;
149   float damage, futureDamage;
150   float contactTime;
151   uint8_t enemyType;
152   uint8_t movePathCount;
153   Vector2 movePath[ENEMY_MAX_PATH_COUNT];
154 } Enemy;
155
156 #define PROJECTILE_MAX_COUNT 1200
157 #define PROJECTILE_TYPE_NONE 0
158 #define PROJECTILE_TYPE_BULLET 1
159
160 typedef struct Projectile
161 {
162   uint8_t projectileType;
163   float shootTime;
164   float arrivalTime;
165   float damage;
166   Vector2 position;
167   Vector2 target;
168   Vector2 directionNormal;
169   EnemyId targetEnemy;
170 } Projectile;
171
172 //# Function declarations
173 float TowerGetMaxHealth(Tower *tower);
174 int Button(const char *text, int x, int y, int width, int height, ButtonState *state);
175 int EnemyAddDamage(Enemy *enemy, float damage);
176
177 //# Enemy functions
178 void EnemyInit();
179 void EnemyDraw();
180 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource);
181 void EnemyUpdate();
182 float EnemyGetCurrentMaxSpeed(Enemy *enemy);
183 float EnemyGetMaxHealth(Enemy *enemy);
184 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY);
185 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount);
186 EnemyId EnemyGetId(Enemy *enemy);
187 Enemy *EnemyTryResolve(EnemyId enemyId);
188 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY);
189 int EnemyAddDamage(Enemy *enemy, float damage);
190 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range);
191 int EnemyCount();
192
193 //# Particles
194 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime);
195
196 //# Path finding
197 Vector2 PathFindingGetGradient(Vector3 world);
198
199 //# variables
200 extern Level *currentLevel;
201 extern Enemy enemies[ENEMY_MAX_COUNT];
202 extern int enemyCount;
203 extern EnemyClassConfig enemyClassConfigs[];
204
205 extern GUIState guiState;
206 extern GameTime gameTime;
207 extern Tower towers[TOWER_MAX_COUNT];
208 extern int towerCount;
209
210 #endif

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 EnemyClassConfig enemyClassConfigs[] = {
  7     [ENEMY_TYPE_MINION] = {
  8       .health = 3.0f,
  9       .speed = 1.0f,
 10       .radius = 0.25f,
 11       .maxAcceleration = 1.0f,
 12       .explosionDamage = 1.0f,
 13       .requiredContactTime = 0.5f,
 14       .explosionRange = 1.0f,
 15       .explosionPushbackPower = 0.25f,
 16       .goldValue = 1,
 17     },
 18 };
 19
 20 Enemy enemies[ENEMY_MAX_COUNT];
 21 int enemyCount = 0;
 22
 23 void EnemyInit()
 24 {
 25   for (int i = 0; i < ENEMY_MAX_COUNT; i++)
 26   {
 27     enemies[i] = (Enemy){0};
 28   }
 29   enemyCount = 0;
 30 }
 31
 32 float EnemyGetCurrentMaxSpeed(Enemy *enemy)
 33 {
 34   return enemyClassConfigs[enemy->enemyType].speed;
 35 }
 36
 37 float EnemyGetMaxHealth(Enemy *enemy)
 38 {
 39   return enemyClassConfigs[enemy->enemyType].health;
 40 }
 41
 42 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY)
 43 {
 44   int16_t castleX = 0;
 45   int16_t castleY = 0;
 46   int16_t dx = castleX - currentX;
 47   int16_t dy = castleY - currentY;
 48   if (dx == 0 && dy == 0)
 49   {
 50     *nextX = currentX;
 51     *nextY = currentY;
 52     return 1;
 53   }
 54   Vector2 gradient = PathFindingGetGradient((Vector3){currentX, 0, currentY});
 55
 56   if (gradient.x == 0 && gradient.y == 0)
 57   {
 58     *nextX = currentX;
 59     *nextY = currentY;
 60     return 1;
 61   }
 62
 63   if (fabsf(gradient.x) > fabsf(gradient.y))
 64   {
 65     *nextX = currentX + (int16_t)(gradient.x > 0.0f ? 1 : -1);
 66     *nextY = currentY;
 67     return 0;
 68   }
 69   *nextX = currentX;
 70   *nextY = currentY + (int16_t)(gradient.y > 0.0f ? 1 : -1);
 71   return 0;
 72 }
 73
 74
 75 // this function predicts the movement of the unit for the next deltaT seconds
 76 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount)
 77 {
 78   const float pointReachedDistance = 0.25f;
 79   const float pointReachedDistance2 = pointReachedDistance * pointReachedDistance;
 80   const float maxSimStepTime = 0.015625f;
 81
 82   float maxAcceleration = enemyClassConfigs[enemy->enemyType].maxAcceleration;
 83   float maxSpeed = EnemyGetCurrentMaxSpeed(enemy);
 84   int16_t nextX = enemy->nextX;
 85   int16_t nextY = enemy->nextY;
 86   Vector2 position = enemy->simPosition;
 87   int passedCount = 0;
 88   for (float t = 0.0f; t < deltaT; t += maxSimStepTime)
 89   {
 90     float stepTime = fminf(deltaT - t, maxSimStepTime);
 91     Vector2 target = (Vector2){nextX, nextY};
 92     float speed = Vector2Length(*velocity);
 93     // draw the target position for debugging
 94     DrawCubeWires((Vector3){target.x, 0.2f, target.y}, 0.1f, 0.4f, 0.1f, RED);
 95     Vector2 lookForwardPos = Vector2Add(position, Vector2Scale(*velocity, speed));
 96     if (Vector2DistanceSqr(target, lookForwardPos) <= pointReachedDistance2)
 97     {
 98       // we reached the target position, let's move to the next waypoint
 99       EnemyGetNextPosition(nextX, nextY, &nextX, &nextY);
100       target = (Vector2){nextX, nextY};
101       // track how many waypoints we passed
102       passedCount++;
103     }
104
105     // acceleration towards the target
106     Vector2 unitDirection = Vector2Normalize(Vector2Subtract(target, lookForwardPos));
107     Vector2 acceleration = Vector2Scale(unitDirection, maxAcceleration * stepTime);
108     *velocity = Vector2Add(*velocity, acceleration);
109
110     // limit the speed to the maximum speed
111     if (speed > maxSpeed)
112     {
113       *velocity = Vector2Scale(*velocity, maxSpeed / speed);
114     }
115
116     // move the enemy
117     position = Vector2Add(position, Vector2Scale(*velocity, stepTime));
118   }
119
120   if (waypointPassedCount)
121   {
122     (*waypointPassedCount) = passedCount;
123   }
124
125   return position;
126 }
127
128 void EnemyDraw()
129 {
130   for (int i = 0; i < enemyCount; i++)
131   {
132     Enemy enemy = enemies[i];
133     if (enemy.enemyType == ENEMY_TYPE_NONE)
134     {
135       continue;
136     }
137
138     Vector2 position = EnemyGetPosition(&enemy, gameTime.time - enemy.startMovingTime, &enemy.simVelocity, 0);
139
140     if (enemy.movePathCount > 0)
141     {
142       Vector3 p = {enemy.movePath[0].x, 0.2f, enemy.movePath[0].y};
143       DrawLine3D(p, (Vector3){position.x, 0.2f, position.y}, GREEN);
144     }
145     for (int j = 1; j < enemy.movePathCount; j++)
146     {
147       Vector3 p = {enemy.movePath[j - 1].x, 0.2f, enemy.movePath[j - 1].y};
148       Vector3 q = {enemy.movePath[j].x, 0.2f, enemy.movePath[j].y};
149       DrawLine3D(p, q, GREEN);
150     }
151
152     switch (enemy.enemyType)
153     {
154     case ENEMY_TYPE_MINION:
155       DrawCubeWires((Vector3){position.x, 0.2f, position.y}, 0.4f, 0.4f, 0.4f, GREEN);
156       break;
157     }
158   }
159 }
160
161 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource)
162 {
163   // damage the tower
164   float explosionDamge = enemyClassConfigs[enemy->enemyType].explosionDamage;
165   float explosionRange = enemyClassConfigs[enemy->enemyType].explosionRange;
166   float explosionPushbackPower = enemyClassConfigs[enemy->enemyType].explosionPushbackPower;
167   float explosionRange2 = explosionRange * explosionRange;
168   tower->damage += enemyClassConfigs[enemy->enemyType].explosionDamage;
169   // explode the enemy
170   if (tower->damage >= TowerGetMaxHealth(tower))
171   {
172     tower->towerType = TOWER_TYPE_NONE;
173   }
174
175   ParticleAdd(PARTICLE_TYPE_EXPLOSION,
176     explosionSource,
177     (Vector3){0, 0.1f, 0}, 1.0f);
178
179   enemy->enemyType = ENEMY_TYPE_NONE;
180
181   // push back enemies & dealing damage
182   for (int i = 0; i < enemyCount; i++)
183   {
184     Enemy *other = &enemies[i];
185     if (other->enemyType == ENEMY_TYPE_NONE)
186     {
187       continue;
188     }
189     float distanceSqr = Vector2DistanceSqr(enemy->simPosition, other->simPosition);
190     if (distanceSqr > 0 && distanceSqr < explosionRange2)
191     {
192       Vector2 direction = Vector2Normalize(Vector2Subtract(other->simPosition, enemy->simPosition));
193       other->simPosition = Vector2Add(other->simPosition, Vector2Scale(direction, explosionPushbackPower));
194       EnemyAddDamage(other, explosionDamge);
195     }
196   }
197 }
198
199 void EnemyUpdate()
200 {
201   const float castleX = 0;
202   const float castleY = 0;
203   const float maxPathDistance2 = 0.25f * 0.25f;
204
205   for (int i = 0; i < enemyCount; i++)
206   {
207     Enemy *enemy = &enemies[i];
208     if (enemy->enemyType == ENEMY_TYPE_NONE)
209     {
210       continue;
211     }
212
213     int waypointPassedCount = 0;
214     enemy->simPosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &enemy->simVelocity, &waypointPassedCount);
215     enemy->startMovingTime = gameTime.time;
216     // track path of unit
217     if (enemy->movePathCount == 0 || Vector2DistanceSqr(enemy->simPosition, enemy->movePath[0]) > maxPathDistance2)
218     {
219       for (int j = ENEMY_MAX_PATH_COUNT - 1; j > 0; j--)
220       {
221         enemy->movePath[j] = enemy->movePath[j - 1];
222       }
223       enemy->movePath[0] = enemy->simPosition;
224       if (++enemy->movePathCount > ENEMY_MAX_PATH_COUNT)
225       {
226         enemy->movePathCount = ENEMY_MAX_PATH_COUNT;
227       }
228     }
229
230     if (waypointPassedCount > 0)
231     {
232       enemy->currentX = enemy->nextX;
233       enemy->currentY = enemy->nextY;
234       if (EnemyGetNextPosition(enemy->currentX, enemy->currentY, &enemy->nextX, &enemy->nextY) &&
235         Vector2DistanceSqr(enemy->simPosition, (Vector2){castleX, castleY}) <= 0.25f * 0.25f)
236       {
237         // enemy reached the castle; remove it
238         enemy->enemyType = ENEMY_TYPE_NONE;
239         continue;
240       }
241     }
242   }
243
244   // handle collisions between enemies
245   for (int i = 0; i < enemyCount - 1; i++)
246   {
247     Enemy *enemyA = &enemies[i];
248     if (enemyA->enemyType == ENEMY_TYPE_NONE)
249     {
250       continue;
251     }
252     for (int j = i + 1; j < enemyCount; j++)
253     {
254       Enemy *enemyB = &enemies[j];
255       if (enemyB->enemyType == ENEMY_TYPE_NONE)
256       {
257         continue;
258       }
259       float distanceSqr = Vector2DistanceSqr(enemyA->simPosition, enemyB->simPosition);
260       float radiusA = enemyClassConfigs[enemyA->enemyType].radius;
261       float radiusB = enemyClassConfigs[enemyB->enemyType].radius;
262       float radiusSum = radiusA + radiusB;
263       if (distanceSqr < radiusSum * radiusSum && distanceSqr > 0.001f)
264       {
265         // collision
266         float distance = sqrtf(distanceSqr);
267         float overlap = radiusSum - distance;
268         // move the enemies apart, but softly; if we have a clog of enemies,
269         // moving them perfectly apart can cause them to jitter
270         float positionCorrection = overlap / 5.0f;
271         Vector2 direction = (Vector2){
272             (enemyB->simPosition.x - enemyA->simPosition.x) / distance * positionCorrection,
273             (enemyB->simPosition.y - enemyA->simPosition.y) / distance * positionCorrection};
274         enemyA->simPosition = Vector2Subtract(enemyA->simPosition, direction);
275         enemyB->simPosition = Vector2Add(enemyB->simPosition, direction);
276       }
277     }
278   }
279
280   // handle collisions between enemies and towers
281   for (int i = 0; i < enemyCount; i++)
282   {
283     Enemy *enemy = &enemies[i];
284     if (enemy->enemyType == ENEMY_TYPE_NONE)
285     {
286       continue;
287     }
288     enemy->contactTime -= gameTime.deltaTime;
289     if (enemy->contactTime < 0.0f)
290     {
291       enemy->contactTime = 0.0f;
292     }
293
294     float enemyRadius = enemyClassConfigs[enemy->enemyType].radius;
295     // linear search over towers; could be optimized by using path finding tower map,
296     // but for now, we keep it simple
297     for (int j = 0; j < towerCount; j++)
298     {
299       Tower *tower = &towers[j];
300       if (tower->towerType == TOWER_TYPE_NONE)
301       {
302         continue;
303       }
304       float distanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){tower->x, tower->y});
305       float combinedRadius = enemyRadius + 0.708; // sqrt(0.5^2 + 0.5^2), corner-center distance of square with side length 1
306       if (distanceSqr > combinedRadius * combinedRadius)
307       {
308         continue;
309       }
310       // potential collision; square / circle intersection
311       float dx = tower->x - enemy->simPosition.x;
312       float dy = tower->y - enemy->simPosition.y;
313       float absDx = fabsf(dx);
314       float absDy = fabsf(dy);
315       Vector3 contactPoint = {0};
316       if (absDx <= 0.5f && absDx <= absDy) {
317         // vertical collision; push the enemy out horizontally
318         float overlap = enemyRadius + 0.5f - absDy;
319         if (overlap < 0.0f)
320         {
321           continue;
322         }
323         float direction = dy > 0.0f ? -1.0f : 1.0f;
324         enemy->simPosition.y += direction * overlap;
325         contactPoint = (Vector3){enemy->simPosition.x, 0.2f, tower->x + direction * 0.5f};
326       }
327       else if (absDy <= 0.5f && absDy <= absDx)
328       {
329         // horizontal collision; push the enemy out vertically
330         float overlap = enemyRadius + 0.5f - absDx;
331         if (overlap < 0.0f)
332         {
333           continue;
334         }
335         float direction = dx > 0.0f ? -1.0f : 1.0f;
336         enemy->simPosition.x += direction * overlap;
337         contactPoint = (Vector3){tower->x + direction * 0.5f, 0.2f, enemy->simPosition.y};
338       }
339       else
340       {
341         // possible collision with a corner
342         float cornerDX = dx > 0.0f ? -0.5f : 0.5f;
343         float cornerDY = dy > 0.0f ? -0.5f : 0.5f;
344         float cornerX = tower->x + cornerDX;
345         float cornerY = tower->y + cornerDY;
346         float cornerDistanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){cornerX, cornerY});
347         if (cornerDistanceSqr > enemyRadius * enemyRadius)
348         {
349           continue;
350         }
351         // push the enemy out along the diagonal
352         float cornerDistance = sqrtf(cornerDistanceSqr);
353         float overlap = enemyRadius - cornerDistance;
354         float directionX = cornerDistance > 0.0f ? (cornerX - enemy->simPosition.x) / cornerDistance : -cornerDX;
355         float directionY = cornerDistance > 0.0f ? (cornerY - enemy->simPosition.y) / cornerDistance : -cornerDY;
356         enemy->simPosition.x -= directionX * overlap;
357         enemy->simPosition.y -= directionY * overlap;
358         contactPoint = (Vector3){cornerX, 0.2f, cornerY};
359       }
360
361       if (enemyClassConfigs[enemy->enemyType].explosionDamage > 0.0f)
362       {
363         enemy->contactTime += gameTime.deltaTime * 2.0f; // * 2 to undo the subtraction above
364         if (enemy->contactTime >= enemyClassConfigs[enemy->enemyType].requiredContactTime)
365         {
366           EnemyTriggerExplode(enemy, tower, contactPoint);
367         }
368       }
369     }
370   }
371 }
372
373 EnemyId EnemyGetId(Enemy *enemy)
374 {
375   return (EnemyId){enemy - enemies, enemy->generation};
376 }
377
378 Enemy *EnemyTryResolve(EnemyId enemyId)
379 {
380   if (enemyId.index >= ENEMY_MAX_COUNT)
381   {
382     return 0;
383   }
384   Enemy *enemy = &enemies[enemyId.index];
385   if (enemy->generation != enemyId.generation || enemy->enemyType == ENEMY_TYPE_NONE)
386   {
387     return 0;
388   }
389   return enemy;
390 }
391
392 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY)
393 {
394   Enemy *spawn = 0;
395   for (int i = 0; i < enemyCount; i++)
396   {
397     Enemy *enemy = &enemies[i];
398     if (enemy->enemyType == ENEMY_TYPE_NONE)
399     {
400       spawn = enemy;
401       break;
402     }
403   }
404
405   if (enemyCount < ENEMY_MAX_COUNT && !spawn)
406   {
407     spawn = &enemies[enemyCount++];
408   }
409
410   if (spawn)
411   {
412     spawn->currentX = currentX;
413     spawn->currentY = currentY;
414     spawn->nextX = currentX;
415     spawn->nextY = currentY;
416     spawn->simPosition = (Vector2){currentX, currentY};
417     spawn->simVelocity = (Vector2){0, 0};
418     spawn->enemyType = enemyType;
419     spawn->startMovingTime = gameTime.time;
420     spawn->damage = 0.0f;
421     spawn->futureDamage = 0.0f;
422     spawn->generation++;
423     spawn->movePathCount = 0;
424   }
425
426   return spawn;
427 }
428
429 int EnemyAddDamage(Enemy *enemy, float damage)
430 {
431   enemy->damage += damage;
432   if (enemy->damage >= EnemyGetMaxHealth(enemy))
433   {
434     currentLevel->playerGold += enemyClassConfigs[enemy->enemyType].goldValue;
435     enemy->enemyType = ENEMY_TYPE_NONE;
436     return 1;
437   }
438
439   return 0;
440 }
441
442 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range)
443 {
444   int16_t castleX = 0;
445   int16_t castleY = 0;
446   Enemy* closest = 0;
447   int16_t closestDistance = 0;
448   float range2 = range * range;
449   for (int i = 0; i < enemyCount; i++)
450   {
451     Enemy* enemy = &enemies[i];
452     if (enemy->enemyType == ENEMY_TYPE_NONE)
453     {
454       continue;
455     }
456     float maxHealth = EnemyGetMaxHealth(enemy);
457     if (enemy->futureDamage >= maxHealth)
458     {
459       // ignore enemies that will die soon
460       continue;
461     }
462     int16_t dx = castleX - enemy->currentX;
463     int16_t dy = castleY - enemy->currentY;
464     int16_t distance = abs(dx) + abs(dy);
465     if (!closest || distance < closestDistance)
466     {
467       float tdx = towerX - enemy->currentX;
468       float tdy = towerY - enemy->currentY;
469       float tdistance2 = tdx * tdx + tdy * tdy;
470       if (tdistance2 <= range2)
471       {
472         closest = enemy;
473         closestDistance = distance;
474       }
475     }
476   }
477   return closest;
478 }
479
480 int EnemyCount()
481 {
482   int count = 0;
483   for (int i = 0; i < enemyCount; i++)
484   {
485     if (enemies[i].enemyType != ENEMY_TYPE_NONE)
486     {
487       count++;
488     }
489   }
490   return count;
491 }

  1 #include "raylib.h"
  2 #include "preferred_size.h"
  3
  4 // Since the canvas size is not known at compile time, we need to query it at runtime;
  5 // the following platform specific code obtains the canvas size and we will use this
  6 // size as the preferred size for the window at init time. We're ignoring here the
  7 // possibility of the canvas size changing during runtime - this would require to
  8 // poll the canvas size in the game loop or establishing a callback to be notified
  9
 10 #ifdef PLATFORM_WEB
 11 #include <emscripten.h>
 12 EMSCRIPTEN_RESULT emscripten_get_element_css_size(const char *target, double *width, double *height);
 13
 14 void GetPreferredSize(int *screenWidth, int *screenHeight)
 15 {
 16   double canvasWidth, canvasHeight;
 17   emscripten_get_element_css_size("#" CANVAS_NAME, &canvasWidth, &canvasHeight);
 18   *screenWidth = (int)canvasWidth;
 19   *screenHeight = (int)canvasHeight;
 20   TraceLog(LOG_INFO, "preferred size for %s: %d %d", CANVAS_NAME, *screenWidth, *screenHeight);
 21 }
 22
 23 int IsPaused()
 24 {
 25   const char *js = "(function(){\n"
 26   "  var canvas = document.getElementById(\"" CANVAS_NAME "\");\n"
 27   "  var rect = canvas.getBoundingClientRect();\n"
 28   "  var isVisible = (\n"
 29   "    rect.top >= 0 &&\n"
 30   "    rect.left >= 0 &&\n"
 31   "    rect.bottom <= (window.innerHeight || document.documentElement.clientHeight) &&\n"
 32   "    rect.right <= (window.innerWidth || document.documentElement.clientWidth)\n"
 33   "  );\n"
 34   "  return isVisible ? 0 : 1;\n"
 35   "})()";
 36   return emscripten_run_script_int(js);
 37 }
 38
 39 #else
 40 void GetPreferredSize(int *screenWidth, int *screenHeight)
 41 {
 42   *screenWidth = 600;
 43   *screenHeight = 240;
 44 }
 45 int IsPaused()
 46 {
 47   return 0;
 48 }
 49 #endif

  1 #ifndef PREFERRED_SIZE_H
  2 #define PREFERRED_SIZE_H
  3
  4 void GetPreferredSize(int *screenWidth, int *screenHeight);
  5 int IsPaused();
  6
  7 #endif

During the first step, I did a few errors that I had to fix. I want to go over these to illustrate common problems you may encounter too:

wasm-ld: error: duplicate symbol: towerCount
>>> defined in C:\(...)\Local\Temp\emscripten_temp_vt9xjlri\td_main_0.o
>>> defined in C:\(...)\Local\Temp\emscripten_temp_vt9xjlri\enemy_1.o

This error message tells me that there is a variable called "towerCount" that is defined in two object files. It happened, because the variable was declared in the header file:

  1 int towerCount = 0

When there was only a single file that included the header, this was no problem. But when having two .c files the include the same header, the variable is defined in both files, causing this error. The solution is to declare the variable as "extern" in the header file:

  1 extern int towerCount

... and to declare it in one of the .c files:

  1 int towerCount = 0

This way, the variable is only defined in one file and the other files know that this variable is defined somewhere else. While I only extracted the enemy functions and global variable declarations to the enemy.c file, I already had to declare a couple of functions in the header file that were previously only provided due to the order of functions in the main file. Let's proceed and extract the path finding:

td-tut-39/td_main.c
td-tut-39/td_main.h
td-tut-39/enemy.c
td-tut-39/path_finding.c
td-tut-39/preferred_size.c
td-tut-39/preferred_size.h
💾

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 //# Variables
  7 GUIState guiState = {0};
  8 GameTime gameTime = {0};
  9 Tower towers[TOWER_MAX_COUNT];
 10 int towerCount = 0;
 11
 12 Level levels[] = {
 13   [0] = {
 14     .state = LEVEL_STATE_BUILDING,
 15     .initialGold = 10,
 16     .waves[0] = {
 17       .enemyType = ENEMY_TYPE_MINION,
 18       .wave = 0,
 19       .count = 10,
 20       .interval = 1.0f,
 21       .delay = 1.0f,
 22       .spawnPosition = {0, 6},
 23     },
 24     .waves[1] = {
 25       .enemyType = ENEMY_TYPE_MINION,
 26       .wave = 1,
 27       .count = 20,
 28       .interval = 0.5f,
 29       .delay = 1.0f,
 30       .spawnPosition = {0, 6},
 31     },
 32     .waves[2] = {
 33       .enemyType = ENEMY_TYPE_MINION,
 34       .wave = 2,
 35       .count = 30,
 36       .interval = 0.25f,
 37       .delay = 1.0f,
 38       .spawnPosition = {0, 6},
 39     }
 40   },
 41 };
 42
 43 Level *currentLevel = levels;
 44
 45 Particle particles[PARTICLE_MAX_COUNT];
 46 int particleCount = 0;
 47
 48 //# Particle system
 49
 50 void ParticleInit()
 51 {
 52   for (int i = 0; i < PARTICLE_MAX_COUNT; i++)
 53   {
 54     particles[i] = (Particle){0};
 55   }
 56   particleCount = 0;
 57 }
 58
 59 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime)
 60 {
 61   if (particleCount >= PARTICLE_MAX_COUNT)
 62   {
 63     return;
 64   }
 65
 66   int index = -1;
 67   for (int i = 0; i < particleCount; i++)
 68   {
 69     if (particles[i].particleType == PARTICLE_TYPE_NONE)
 70     {
 71       index = i;
 72       break;
 73     }
 74   }
 75
 76   if (index == -1)
 77   {
 78     index = particleCount++;
 79   }
 80
 81   Particle *particle = &particles[index];
 82   particle->particleType = particleType;
 83   particle->spawnTime = gameTime.time;
 84   particle->lifetime = lifetime;
 85   particle->position = position;
 86   particle->velocity = velocity;
 87 }
 88
 89 void ParticleUpdate()
 90 {
 91   for (int i = 0; i < particleCount; i++)
 92   {
 93     Particle *particle = &particles[i];
 94     if (particle->particleType == PARTICLE_TYPE_NONE)
 95     {
 96       continue;
 97     }
 98
 99     float age = gameTime.time - particle->spawnTime;
100
101     if (particle->lifetime > age)
102     {
103       particle->position = Vector3Add(particle->position, Vector3Scale(particle->velocity, gameTime.deltaTime));
104     }
105     else {
106       particle->particleType = PARTICLE_TYPE_NONE;
107     }
108   }
109 }
110
111 void DrawExplosionParticle(Particle *particle, float transition)
112 {
113   float size = 1.2f * (1.0f - transition);
114   Color startColor = WHITE;
115   Color endColor = RED;
116   Color color = ColorLerp(startColor, endColor, transition);
117   DrawCube(particle->position, size, size, size, color);
118 }
119
120 void ParticleDraw()
121 {
122   for (int i = 0; i < particleCount; i++)
123   {
124     Particle particle = particles[i];
125     if (particle.particleType == PARTICLE_TYPE_NONE)
126     {
127       continue;
128     }
129
130     float age = gameTime.time - particle.spawnTime;
131     float transition = age / particle.lifetime;
132     switch (particle.particleType)
133     {
134     case PARTICLE_TYPE_EXPLOSION:
135       DrawExplosionParticle(&particle, transition);
136       break;
137     default:
138       DrawCube(particle.position, 0.3f, 0.5f, 0.3f, RED);
139       break;
140     }
141   }
142 }
143
144 //# Projectiles
145 Projectile projectiles[PROJECTILE_MAX_COUNT];
146 int projectileCount = 0;
147
148 void ProjectileInit()
149 {
150   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
151   {
152     projectiles[i] = (Projectile){0};
153   }
154 }
155
156 void ProjectileDraw()
157 {
158   for (int i = 0; i < projectileCount; i++)
159   {
160     Projectile projectile = projectiles[i];
161     if (projectile.projectileType == PROJECTILE_TYPE_NONE)
162     {
163       continue;
164     }
165     float transition = (gameTime.time - projectile.shootTime) / (projectile.arrivalTime - projectile.shootTime);
166     if (transition >= 1.0f)
167     {
168       continue;
169     }
170     Vector2 position = Vector2Lerp(projectile.position, projectile.target, transition);
171     float x = position.x;
172     float y = position.y;
173     float dx = projectile.directionNormal.x;
174     float dy = projectile.directionNormal.y;
175     for (float d = 1.0f; d > 0.0f; d -= 0.25f)
176     {
177       x -= dx * 0.1f;
178       y -= dy * 0.1f;
179       float size = 0.1f * d;
180       DrawCube((Vector3){x, 0.2f, y}, size, size, size, RED);
181     }
182   }
183 }
184
185 void ProjectileUpdate()
186 {
187   for (int i = 0; i < projectileCount; i++)
188   {
189     Projectile *projectile = &projectiles[i];
190     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
191     {
192       continue;
193     }
194     float transition = (gameTime.time - projectile->shootTime) / (projectile->arrivalTime - projectile->shootTime);
195     if (transition >= 1.0f)
196     {
197       projectile->projectileType = PROJECTILE_TYPE_NONE;
198       Enemy *enemy = EnemyTryResolve(projectile->targetEnemy);
199       if (enemy)
200       {
201         EnemyAddDamage(enemy, projectile->damage);
202       }
203       continue;
204     }
205   }
206 }
207
208 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage)
209 {
210   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
211   {
212     Projectile *projectile = &projectiles[i];
213     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
214     {
215       projectile->projectileType = projectileType;
216       projectile->shootTime = gameTime.time;
217       projectile->arrivalTime = gameTime.time + Vector2Distance(position, target) / speed;
218       projectile->damage = damage;
219       projectile->position = position;
220       projectile->target = target;
221       projectile->directionNormal = Vector2Normalize(Vector2Subtract(target, position));
222       projectile->targetEnemy = EnemyGetId(enemy);
223       projectileCount = projectileCount <= i ? i + 1 : projectileCount;
224       return projectile;
225     }
226   }
227   return 0;
228 }
229
230 //# Towers
231
232 void TowerInit()
233 {
234   for (int i = 0; i < TOWER_MAX_COUNT; i++)
235   {
236     towers[i] = (Tower){0};
237   }
238   towerCount = 0;
239 }
240
241 Tower *TowerGetAt(int16_t x, int16_t y)
242 {
243   for (int i = 0; i < towerCount; i++)
244   {
245     if (towers[i].x == x && towers[i].y == y)
246     {
247       return &towers[i];
248     }
249   }
250   return 0;
251 }
252
253 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y)
254 {
255   if (towerCount >= TOWER_MAX_COUNT)
256   {
257     return 0;
258   }
259
260   Tower *tower = TowerGetAt(x, y);
261   if (tower)
262   {
263     return 0;
264   }
265
266   tower = &towers[towerCount++];
267   tower->x = x;
268   tower->y = y;
269   tower->towerType = towerType;
270   tower->cooldown = 0.0f;
271   tower->damage = 0.0f;
272   return tower;
273 }
274
275 Tower *GetTowerByType(uint8_t towerType)
276 {
277   for (int i = 0; i < towerCount; i++)
278   {
279     if (towers[i].towerType == towerType)
280     {
281       return &towers[i];
282     }
283   }
284   return 0;
285 }
286
287 int GetTowerCosts(uint8_t towerType)
288 {
289   switch (towerType)
290   {
291   case TOWER_TYPE_BASE:
292     return 0;
293   case TOWER_TYPE_GUN:
294     return 6;
295   case TOWER_TYPE_WALL:
296     return 2;
297   }
298   return 0;
299 }
300
301 float TowerGetMaxHealth(Tower *tower)
302 {
303   switch (tower->towerType)
304   {
305   case TOWER_TYPE_BASE:
306     return 10.0f;
307   case TOWER_TYPE_GUN:
308     return 3.0f;
309   case TOWER_TYPE_WALL:
310     return 5.0f;
311   }
312   return 0.0f;
313 }
314
315 void TowerDraw()
316 {
317   for (int i = 0; i < towerCount; i++)
318   {
319     Tower tower = towers[i];
320     DrawCube((Vector3){tower.x, 0.125f, tower.y}, 1.0f, 0.25f, 1.0f, GRAY);
321     switch (tower.towerType)
322     {
323     case TOWER_TYPE_BASE:
324       DrawCube((Vector3){tower.x, 0.4f, tower.y}, 0.8f, 0.8f, 0.8f, MAROON);
325       break;
326     case TOWER_TYPE_GUN:
327       DrawCube((Vector3){tower.x, 0.2f, tower.y}, 0.8f, 0.4f, 0.8f, DARKPURPLE);
328       break;
329     case TOWER_TYPE_WALL:
330       DrawCube((Vector3){tower.x, 0.5f, tower.y}, 1.0f, 1.0f, 1.0f, LIGHTGRAY);
331       break;
332     }
333   }
334 }
335
336 void TowerGunUpdate(Tower *tower)
337 {
338   if (tower->cooldown <= 0)
339   {
340     Enemy *enemy = EnemyGetClosestToCastle(tower->x, tower->y, 3.0f);
341     if (enemy)
342     {
343       tower->cooldown = 0.125f;
344       // shoot the enemy; determine future position of the enemy
345       float bulletSpeed = 1.0f;
346       float bulletDamage = 3.0f;
347       Vector2 velocity = enemy->simVelocity;
348       Vector2 futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &velocity, 0);
349       Vector2 towerPosition = {tower->x, tower->y};
350       float eta = Vector2Distance(towerPosition, futurePosition) / bulletSpeed;
351       for (int i = 0; i < 8; i++) {
352         velocity = enemy->simVelocity;
353         futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime + eta, &velocity, 0);
354         float distance = Vector2Distance(towerPosition, futurePosition);
355         float eta2 = distance / bulletSpeed;
356         if (fabs(eta - eta2) < 0.01f) {
357           break;
358         }
359         eta = (eta2 + eta) * 0.5f;
360       }
361       ProjectileTryAdd(PROJECTILE_TYPE_BULLET, enemy, towerPosition, futurePosition,
362         bulletSpeed, bulletDamage);
363       enemy->futureDamage += bulletDamage;
364     }
365   }
366   else
367   {
368     tower->cooldown -= gameTime.deltaTime;
369   }
370 }
371
372 void TowerUpdate()
373 {
374   for (int i = 0; i < towerCount; i++)
375   {
376     Tower *tower = &towers[i];
377     switch (tower->towerType)
378     {
379     case TOWER_TYPE_GUN:
380       TowerGunUpdate(tower);
381       break;
382     }
383   }
384 }
385
386 //# Game
387
388 void InitLevel(Level *level)
389 {
390   TowerInit();
391   EnemyInit();
392   ProjectileInit();
393   ParticleInit();
394   TowerTryAdd(TOWER_TYPE_BASE, 0, 0);
395
396   level->placementMode = 0;
397   level->state = LEVEL_STATE_BUILDING;
398   level->nextState = LEVEL_STATE_NONE;
399   level->playerGold = level->initialGold;
400
401   Camera *camera = &level->camera;
402   camera->position = (Vector3){1.0f, 12.0f, 6.5f};
403   camera->target = (Vector3){0.0f, 0.5f, 1.0f};
404   camera->up = (Vector3){0.0f, 1.0f, 0.0f};
405   camera->fovy = 45.0f;
406   camera->projection = CAMERA_PERSPECTIVE;
407 }
408
409 void DrawLevelHud(Level *level)
410 {
411   const char *text = TextFormat("Gold: %d", level->playerGold);
412   Font font = GetFontDefault();
413   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 120, 10}, font.baseSize * 2.0f, 2.0f, BLACK);
414   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 122, 8}, font.baseSize * 2.0f, 2.0f, YELLOW);
415 }
416
417 void DrawLevelReportLostWave(Level *level)
418 {
419   BeginMode3D(level->camera);
420   DrawGrid(10, 1.0f);
421   TowerDraw();
422   EnemyDraw();
423   ProjectileDraw();
424   ParticleDraw();
425   guiState.isBlocked = 0;
426   EndMode3D();
427
428   const char *text = "Wave lost";
429   int textWidth = MeasureText(text, 20);
430   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
431
432   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
433   {
434     level->nextState = LEVEL_STATE_RESET;
435   }
436 }
437
438 int HasLevelNextWave(Level *level)
439 {
440   for (int i = 0; i < 10; i++)
441   {
442     EnemyWave *wave = &level->waves[i];
443     if (wave->wave == level->currentWave)
444     {
445       return 1;
446     }
447   }
448   return 0;
449 }
450
451 void DrawLevelReportWonWave(Level *level)
452 {
453   BeginMode3D(level->camera);
454   DrawGrid(10, 1.0f);
455   TowerDraw();
456   EnemyDraw();
457   ProjectileDraw();
458   ParticleDraw();
459   guiState.isBlocked = 0;
460   EndMode3D();
461
462   const char *text = "Wave won";
463   int textWidth = MeasureText(text, 20);
464   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
465
466
467   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
468   {
469     level->nextState = LEVEL_STATE_RESET;
470   }
471
472   if (HasLevelNextWave(level))
473   {
474     if (Button("Prepare for next wave", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
475     {
476       level->nextState = LEVEL_STATE_BUILDING;
477     }
478   }
479   else {
480     if (Button("Level won", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
481     {
482       level->nextState = LEVEL_STATE_WON_LEVEL;
483     }
484   }
485 }
486
487 void DrawBuildingBuildButton(Level *level, int x, int y, int width, int height, uint8_t towerType, const char *name)
488 {
489   static ButtonState buttonStates[8] = {0};
490   int cost = GetTowerCosts(towerType);
491   const char *text = TextFormat("%s: %d", name, cost);
492   buttonStates[towerType].isSelected = level->placementMode == towerType;
493   buttonStates[towerType].isDisabled = level->playerGold < cost;
494   if (Button(text, x, y, width, height, &buttonStates[towerType]))
495   {
496     level->placementMode = buttonStates[towerType].isSelected ? 0 : towerType;
497   }
498 }
499
500 void DrawLevelBuildingState(Level *level)
501 {
502   BeginMode3D(level->camera);
503   DrawGrid(10, 1.0f);
504   TowerDraw();
505   EnemyDraw();
506   ProjectileDraw();
507   ParticleDraw();
508
509   Ray ray = GetScreenToWorldRay(GetMousePosition(), level->camera);
510   float planeDistance = ray.position.y / -ray.direction.y;
511   float planeX = ray.direction.x * planeDistance + ray.position.x;
512   float planeY = ray.direction.z * planeDistance + ray.position.z;
513   int16_t mapX = (int16_t)floorf(planeX + 0.5f);
514   int16_t mapY = (int16_t)floorf(planeY + 0.5f);
515   if (level->placementMode && !guiState.isBlocked)
516   {
517     DrawCubeWires((Vector3){mapX, 0.2f, mapY}, 1.0f, 0.4f, 1.0f, RED);
518     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
519     {
520       if (TowerTryAdd(level->placementMode, mapX, mapY))
521       {
522         level->playerGold -= GetTowerCosts(level->placementMode);
523         level->placementMode = TOWER_TYPE_NONE;
524       }
525     }
526   }
527
528   guiState.isBlocked = 0;
529
530   EndMode3D();
531
532   static ButtonState buildWallButtonState = {0};
533   static ButtonState buildGunButtonState = {0};
534   buildWallButtonState.isSelected = level->placementMode == TOWER_TYPE_WALL;
535   buildGunButtonState.isSelected = level->placementMode == TOWER_TYPE_GUN;
536
537   DrawBuildingBuildButton(level, 10, 10, 80, 30, TOWER_TYPE_WALL, "Wall");
538   DrawBuildingBuildButton(level, 10, 50, 80, 30, TOWER_TYPE_GUN, "Gun");
539
540   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
541   {
542     level->nextState = LEVEL_STATE_RESET;
543   }
544
545   if (Button("Begin waves", GetScreenWidth() - 160, GetScreenHeight() - 40, 160, 30, 0))
546   {
547     level->nextState = LEVEL_STATE_BATTLE;
548   }
549
550   const char *text = "Building phase";
551   int textWidth = MeasureText(text, 20);
552   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
553 }
554
555 void InitBattleStateConditions(Level *level)
556 {
557   level->state = LEVEL_STATE_BATTLE;
558   level->nextState = LEVEL_STATE_NONE;
559   level->waveEndTimer = 0.0f;
560   for (int i = 0; i < 10; i++)
561   {
562     EnemyWave *wave = &level->waves[i];
563     wave->spawned = 0;
564     wave->timeToSpawnNext = wave->delay;
565   }
566 }
567
568 void DrawLevelBattleState(Level *level)
569 {
570   BeginMode3D(level->camera);
571   DrawGrid(10, 1.0f);
572   TowerDraw();
573   EnemyDraw();
574   ProjectileDraw();
575   ParticleDraw();
576   guiState.isBlocked = 0;
577   EndMode3D();
578
579   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
580   {
581     level->nextState = LEVEL_STATE_RESET;
582   }
583
584   int maxCount = 0;
585   int remainingCount = 0;
586   for (int i = 0; i < 10; i++)
587   {
588     EnemyWave *wave = &level->waves[i];
589     if (wave->wave != level->currentWave)
590     {
591       continue;
592     }
593     maxCount += wave->count;
594     remainingCount += wave->count - wave->spawned;
595   }
596   int aliveCount = EnemyCount();
597   remainingCount += aliveCount;
598
599   const char *text = TextFormat("Battle phase: %03d%%", 100 - remainingCount * 100 / maxCount);
600   int textWidth = MeasureText(text, 20);
601   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
602 }
603
604 void DrawLevel(Level *level)
605 {
606   switch (level->state)
607   {
608     case LEVEL_STATE_BUILDING: DrawLevelBuildingState(level); break;
609     case LEVEL_STATE_BATTLE: DrawLevelBattleState(level); break;
610     case LEVEL_STATE_WON_WAVE: DrawLevelReportWonWave(level); break;
611     case LEVEL_STATE_LOST_WAVE: DrawLevelReportLostWave(level); break;
612     default: break;
613   }
614
615   DrawLevelHud(level);
616 }
617
618 void UpdateLevel(Level *level)
619 {
620   if (level->state == LEVEL_STATE_BATTLE)
621   {
622     int activeWaves = 0;
623     for (int i = 0; i < 10; i++)
624     {
625       EnemyWave *wave = &level->waves[i];
626       if (wave->spawned >= wave->count || wave->wave != level->currentWave)
627       {
628         continue;
629       }
630       activeWaves++;
631       wave->timeToSpawnNext -= gameTime.deltaTime;
632       if (wave->timeToSpawnNext <= 0.0f)
633       {
634         Enemy *enemy = EnemyTryAdd(wave->enemyType, wave->spawnPosition.x, wave->spawnPosition.y);
635         if (enemy)
636         {
637           wave->timeToSpawnNext = wave->interval;
638           wave->spawned++;
639         }
640       }
641     }
642     if (GetTowerByType(TOWER_TYPE_BASE) == 0) {
643       level->waveEndTimer += gameTime.deltaTime;
644       if (level->waveEndTimer >= 2.0f)
645       {
646         level->nextState = LEVEL_STATE_LOST_WAVE;
647       }
648     }
649     else if (activeWaves == 0 && EnemyCount() == 0)
650     {
651       level->waveEndTimer += gameTime.deltaTime;
652       if (level->waveEndTimer >= 2.0f)
653       {
654         level->nextState = LEVEL_STATE_WON_WAVE;
655       }
656     }
657   }
658
659   PathFindingMapUpdate();
660   EnemyUpdate();
661   TowerUpdate();
662   ProjectileUpdate();
663   ParticleUpdate();
664
665   if (level->nextState == LEVEL_STATE_RESET)
666   {
667     InitLevel(level);
668   }
669
670   if (level->nextState == LEVEL_STATE_BATTLE)
671   {
672     InitBattleStateConditions(level);
673   }
674
675   if (level->nextState == LEVEL_STATE_WON_WAVE)
676   {
677     level->currentWave++;
678     level->state = LEVEL_STATE_WON_WAVE;
679   }
680
681   if (level->nextState == LEVEL_STATE_LOST_WAVE)
682   {
683     level->state = LEVEL_STATE_LOST_WAVE;
684   }
685
686   if (level->nextState == LEVEL_STATE_BUILDING)
687   {
688     level->state = LEVEL_STATE_BUILDING;
689   }
690
691   if (level->nextState == LEVEL_STATE_WON_LEVEL)
692   {
693     // make something of this later
694     InitLevel(level);
695   }
696
697   level->nextState = LEVEL_STATE_NONE;
698 }
699
700 float nextSpawnTime = 0.0f;
701
702 void ResetGame()
703 {
704   InitLevel(currentLevel);
705 }
706
707 void InitGame()
708 {
709   TowerInit();
710   EnemyInit();
711   ProjectileInit();
712   ParticleInit();
713   PathfindingMapInit(20, 20, (Vector3){-10.0f, 0.0f, -10.0f}, 1.0f);
714
715   currentLevel = levels;
716   InitLevel(currentLevel);
717 }
718
719 //# Immediate GUI functions
720
721 int Button(const char *text, int x, int y, int width, int height, ButtonState *state)
722 {
723   Rectangle bounds = {x, y, width, height};
724   int isPressed = 0;
725   int isSelected = state && state->isSelected;
726   if (CheckCollisionPointRec(GetMousePosition(), bounds) && !guiState.isBlocked && !state->isDisabled)
727   {
728     Color color = isSelected ? DARKGRAY : GRAY;
729     DrawRectangle(x, y, width, height, color);
730     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
731     {
732       isPressed = 1;
733     }
734     guiState.isBlocked = 1;
735   }
736   else
737   {
738     Color color = isSelected ? WHITE : LIGHTGRAY;
739     DrawRectangle(x, y, width, height, color);
740   }
741   Font font = GetFontDefault();
742   Vector2 textSize = MeasureTextEx(font, text, font.baseSize * 2.0f, 1);
743   Color textColor = state->isDisabled ? GRAY : BLACK;
744   DrawTextEx(font, text, (Vector2){x + width / 2 - textSize.x / 2, y + height / 2 - textSize.y / 2}, font.baseSize * 2.0f, 1, textColor);
745   return isPressed;
746 }
747
748 //# Main game loop
749
750 void GameUpdate()
751 {
752   float dt = GetFrameTime();
753   // cap maximum delta time to 0.1 seconds to prevent large time steps
754   if (dt > 0.1f) dt = 0.1f;
755   gameTime.time += dt;
756   gameTime.deltaTime = dt;
757
758   UpdateLevel(currentLevel);
759 }
760
761 int main(void)
762 {
763   int screenWidth, screenHeight;
764   GetPreferredSize(&screenWidth, &screenHeight);
765   InitWindow(screenWidth, screenHeight, "Tower defense");
766   SetTargetFPS(30);
767
768   InitGame();
769
770   while (!WindowShouldClose())
771   {
772     if (IsPaused()) {
773       // canvas is not visible in browser - do nothing
774       continue;
775     }
776
777     BeginDrawing();
778     ClearBackground(DARKBLUE);
779
780     GameUpdate();
781     DrawLevel(currentLevel);
782
783     EndDrawing();
784   }
785
786   CloseWindow();
787
788   return 0;
789 }

  1 #ifndef TD_TUT_2_MAIN_H
  2 #define TD_TUT_2_MAIN_H
  3
  4 #include <inttypes.h>
  5
  6 #include "raylib.h"
  7 #include "preferred_size.h"
  8
  9 //# Declarations
 10
 11 #define ENEMY_MAX_PATH_COUNT 8
 12 #define ENEMY_MAX_COUNT 400
 13 #define ENEMY_TYPE_NONE 0
 14 #define ENEMY_TYPE_MINION 1
 15
 16 #define PARTICLE_MAX_COUNT 400
 17 #define PARTICLE_TYPE_NONE 0
 18 #define PARTICLE_TYPE_EXPLOSION 1
 19
 20 typedef struct Particle
 21 {
 22   uint8_t particleType;
 23   float spawnTime;
 24   float lifetime;
 25   Vector3 position;
 26   Vector3 velocity;
 27 } Particle;
 28
 29 #define TOWER_MAX_COUNT 400
 30 #define TOWER_TYPE_NONE 0
 31 #define TOWER_TYPE_BASE 1
 32 #define TOWER_TYPE_GUN 2
 33 #define TOWER_TYPE_WALL 3
 34
 35 typedef struct Tower
 36 {
 37   int16_t x, y;
 38   uint8_t towerType;
 39   float cooldown;
 40   float damage;
 41 } Tower;
 42
 43 typedef struct GameTime
 44 {
 45   float time;
 46   float deltaTime;
 47 } GameTime;
 48
 49 typedef struct ButtonState {
 50   char isSelected;
 51   char isDisabled;
 52 } ButtonState;
 53
 54 typedef struct GUIState {
 55   int isBlocked;
 56 } GUIState;
 57
 58 typedef enum LevelState
 59 {
 60   LEVEL_STATE_NONE,
 61   LEVEL_STATE_BUILDING,
 62   LEVEL_STATE_BATTLE,
 63   LEVEL_STATE_WON_WAVE,
 64   LEVEL_STATE_LOST_WAVE,
 65   LEVEL_STATE_WON_LEVEL,
 66   LEVEL_STATE_RESET,
 67 } LevelState;
 68
 69 typedef struct EnemyWave {
 70   uint8_t enemyType;
 71   uint8_t wave;
 72   uint16_t count;
 73   float interval;
 74   float delay;
 75   Vector2 spawnPosition;
 76
 77   uint16_t spawned;
 78   float timeToSpawnNext;
 79 } EnemyWave;
 80
 81 typedef struct Level
 82 {
 83   LevelState state;
 84   LevelState nextState;
 85   Camera3D camera;
 86   int placementMode;
 87
 88   int initialGold;
 89   int playerGold;
 90
 91   EnemyWave waves[10];
 92   int currentWave;
 93   float waveEndTimer;
 94 } Level;
 95
 96 typedef struct DeltaSrc
 97 {
 98   char x, y;
 99 } DeltaSrc;
100
101 typedef struct PathfindingMap
102 {
103   int width, height;
104   float scale;
105   float *distances;
106   long *towerIndex;
107   DeltaSrc *deltaSrc;
108   float maxDistance;
109   Matrix toMapSpace;
110   Matrix toWorldSpace;
111 } PathfindingMap;
112
113 // when we execute the pathfinding algorithm, we need to store the active nodes
114 // in a queue. Each node has a position, a distance from the start, and the
115 // position of the node that we came from.
116 typedef struct PathfindingNode
117 {
118   int16_t x, y, fromX, fromY;
119   float distance;
120 } PathfindingNode;
121
122 typedef struct EnemyId
123 {
124   uint16_t index;
125   uint16_t generation;
126 } EnemyId;
127
128 typedef struct EnemyClassConfig
129 {
130   float speed;
131   float health;
132   float radius;
133   float maxAcceleration;
134   float requiredContactTime;
135   float explosionDamage;
136   float explosionRange;
137   float explosionPushbackPower;
138   int goldValue;
139 } EnemyClassConfig;
140
141 typedef struct Enemy
142 {
143   int16_t currentX, currentY;
144   int16_t nextX, nextY;
145   Vector2 simPosition;
146   Vector2 simVelocity;
147   uint16_t generation;
148   float startMovingTime;
149   float damage, futureDamage;
150   float contactTime;
151   uint8_t enemyType;
152   uint8_t movePathCount;
153   Vector2 movePath[ENEMY_MAX_PATH_COUNT];
154 } Enemy;
155
156 #define PROJECTILE_MAX_COUNT 1200
157 #define PROJECTILE_TYPE_NONE 0
158 #define PROJECTILE_TYPE_BULLET 1
159
160 typedef struct Projectile
161 {
162   uint8_t projectileType;
163   float shootTime;
164   float arrivalTime;
165   float damage;
166   Vector2 position;
167   Vector2 target;
168   Vector2 directionNormal;
169   EnemyId targetEnemy;
170 } Projectile;
171
172 //# Function declarations
173 float TowerGetMaxHealth(Tower *tower);
174 int Button(const char *text, int x, int y, int width, int height, ButtonState *state);
175 int EnemyAddDamage(Enemy *enemy, float damage);
176
177 //# Enemy functions
178 void EnemyInit();
179 void EnemyDraw();
180 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource);
181 void EnemyUpdate();
182 float EnemyGetCurrentMaxSpeed(Enemy *enemy);
183 float EnemyGetMaxHealth(Enemy *enemy);
184 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY);
185 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount);
186 EnemyId EnemyGetId(Enemy *enemy);
187 Enemy *EnemyTryResolve(EnemyId enemyId);
188 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY);
189 int EnemyAddDamage(Enemy *enemy, float damage);
190 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range);
191 int EnemyCount();
192
193 //# Particles
194 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime);
195
196 //# Pathfinding map
197 void PathfindingMapInit(int width, int height, Vector3 translate, float scale);
198 float PathFindingGetDistance(int mapX, int mapY);
199 Vector2 PathFindingGetGradient(Vector3 world);
200 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY);
201 void PathFindingMapUpdate();
202 void PathFindingMapDraw();
203
204 //# variables
205 extern Level *currentLevel;
206 extern Enemy enemies[ENEMY_MAX_COUNT];
207 extern int enemyCount;
208 extern EnemyClassConfig enemyClassConfigs[];
209
210 extern GUIState guiState;
211 extern GameTime gameTime;
212 extern Tower towers[TOWER_MAX_COUNT];
213 extern int towerCount;
214
215 #endif

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 EnemyClassConfig enemyClassConfigs[] = {
  7     [ENEMY_TYPE_MINION] = {
  8       .health = 3.0f,
  9       .speed = 1.0f,
 10       .radius = 0.25f,
 11       .maxAcceleration = 1.0f,
 12       .explosionDamage = 1.0f,
 13       .requiredContactTime = 0.5f,
 14       .explosionRange = 1.0f,
 15       .explosionPushbackPower = 0.25f,
 16       .goldValue = 1,
 17     },
 18 };
 19
 20 Enemy enemies[ENEMY_MAX_COUNT];
 21 int enemyCount = 0;
 22
 23 void EnemyInit()
 24 {
 25   for (int i = 0; i < ENEMY_MAX_COUNT; i++)
 26   {
 27     enemies[i] = (Enemy){0};
 28   }
 29   enemyCount = 0;
 30 }
 31
 32 float EnemyGetCurrentMaxSpeed(Enemy *enemy)
 33 {
 34   return enemyClassConfigs[enemy->enemyType].speed;
 35 }
 36
 37 float EnemyGetMaxHealth(Enemy *enemy)
 38 {
 39   return enemyClassConfigs[enemy->enemyType].health;
 40 }
 41
 42 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY)
 43 {
 44   int16_t castleX = 0;
 45   int16_t castleY = 0;
 46   int16_t dx = castleX - currentX;
 47   int16_t dy = castleY - currentY;
 48   if (dx == 0 && dy == 0)
 49   {
 50     *nextX = currentX;
 51     *nextY = currentY;
 52     return 1;
 53   }
 54   Vector2 gradient = PathFindingGetGradient((Vector3){currentX, 0, currentY});
 55
 56   if (gradient.x == 0 && gradient.y == 0)
 57   {
 58     *nextX = currentX;
 59     *nextY = currentY;
 60     return 1;
 61   }
 62
 63   if (fabsf(gradient.x) > fabsf(gradient.y))
 64   {
 65     *nextX = currentX + (int16_t)(gradient.x > 0.0f ? 1 : -1);
 66     *nextY = currentY;
 67     return 0;
 68   }
 69   *nextX = currentX;
 70   *nextY = currentY + (int16_t)(gradient.y > 0.0f ? 1 : -1);
 71   return 0;
 72 }
 73
 74
 75 // this function predicts the movement of the unit for the next deltaT seconds
 76 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount)
 77 {
 78   const float pointReachedDistance = 0.25f;
 79   const float pointReachedDistance2 = pointReachedDistance * pointReachedDistance;
 80   const float maxSimStepTime = 0.015625f;
 81
 82   float maxAcceleration = enemyClassConfigs[enemy->enemyType].maxAcceleration;
 83   float maxSpeed = EnemyGetCurrentMaxSpeed(enemy);
 84   int16_t nextX = enemy->nextX;
 85   int16_t nextY = enemy->nextY;
 86   Vector2 position = enemy->simPosition;
 87   int passedCount = 0;
 88   for (float t = 0.0f; t < deltaT; t += maxSimStepTime)
 89   {
 90     float stepTime = fminf(deltaT - t, maxSimStepTime);
 91     Vector2 target = (Vector2){nextX, nextY};
 92     float speed = Vector2Length(*velocity);
 93     // draw the target position for debugging
 94     DrawCubeWires((Vector3){target.x, 0.2f, target.y}, 0.1f, 0.4f, 0.1f, RED);
 95     Vector2 lookForwardPos = Vector2Add(position, Vector2Scale(*velocity, speed));
 96     if (Vector2DistanceSqr(target, lookForwardPos) <= pointReachedDistance2)
 97     {
 98       // we reached the target position, let's move to the next waypoint
 99       EnemyGetNextPosition(nextX, nextY, &nextX, &nextY);
100       target = (Vector2){nextX, nextY};
101       // track how many waypoints we passed
102       passedCount++;
103     }
104
105     // acceleration towards the target
106     Vector2 unitDirection = Vector2Normalize(Vector2Subtract(target, lookForwardPos));
107     Vector2 acceleration = Vector2Scale(unitDirection, maxAcceleration * stepTime);
108     *velocity = Vector2Add(*velocity, acceleration);
109
110     // limit the speed to the maximum speed
111     if (speed > maxSpeed)
112     {
113       *velocity = Vector2Scale(*velocity, maxSpeed / speed);
114     }
115
116     // move the enemy
117     position = Vector2Add(position, Vector2Scale(*velocity, stepTime));
118   }
119
120   if (waypointPassedCount)
121   {
122     (*waypointPassedCount) = passedCount;
123   }
124
125   return position;
126 }
127
128 void EnemyDraw()
129 {
130   for (int i = 0; i < enemyCount; i++)
131   {
132     Enemy enemy = enemies[i];
133     if (enemy.enemyType == ENEMY_TYPE_NONE)
134     {
135       continue;
136     }
137
138     Vector2 position = EnemyGetPosition(&enemy, gameTime.time - enemy.startMovingTime, &enemy.simVelocity, 0);
139
140     if (enemy.movePathCount > 0)
141     {
142       Vector3 p = {enemy.movePath[0].x, 0.2f, enemy.movePath[0].y};
143       DrawLine3D(p, (Vector3){position.x, 0.2f, position.y}, GREEN);
144     }
145     for (int j = 1; j < enemy.movePathCount; j++)
146     {
147       Vector3 p = {enemy.movePath[j - 1].x, 0.2f, enemy.movePath[j - 1].y};
148       Vector3 q = {enemy.movePath[j].x, 0.2f, enemy.movePath[j].y};
149       DrawLine3D(p, q, GREEN);
150     }
151
152     switch (enemy.enemyType)
153     {
154     case ENEMY_TYPE_MINION:
155       DrawCubeWires((Vector3){position.x, 0.2f, position.y}, 0.4f, 0.4f, 0.4f, GREEN);
156       break;
157     }
158   }
159 }
160
161 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource)
162 {
163   // damage the tower
164   float explosionDamge = enemyClassConfigs[enemy->enemyType].explosionDamage;
165   float explosionRange = enemyClassConfigs[enemy->enemyType].explosionRange;
166   float explosionPushbackPower = enemyClassConfigs[enemy->enemyType].explosionPushbackPower;
167   float explosionRange2 = explosionRange * explosionRange;
168   tower->damage += enemyClassConfigs[enemy->enemyType].explosionDamage;
169   // explode the enemy
170   if (tower->damage >= TowerGetMaxHealth(tower))
171   {
172     tower->towerType = TOWER_TYPE_NONE;
173   }
174
175   ParticleAdd(PARTICLE_TYPE_EXPLOSION,
176     explosionSource,
177     (Vector3){0, 0.1f, 0}, 1.0f);
178
179   enemy->enemyType = ENEMY_TYPE_NONE;
180
181   // push back enemies & dealing damage
182   for (int i = 0; i < enemyCount; i++)
183   {
184     Enemy *other = &enemies[i];
185     if (other->enemyType == ENEMY_TYPE_NONE)
186     {
187       continue;
188     }
189     float distanceSqr = Vector2DistanceSqr(enemy->simPosition, other->simPosition);
190     if (distanceSqr > 0 && distanceSqr < explosionRange2)
191     {
192       Vector2 direction = Vector2Normalize(Vector2Subtract(other->simPosition, enemy->simPosition));
193       other->simPosition = Vector2Add(other->simPosition, Vector2Scale(direction, explosionPushbackPower));
194       EnemyAddDamage(other, explosionDamge);
195     }
196   }
197 }
198
199 void EnemyUpdate()
200 {
201   const float castleX = 0;
202   const float castleY = 0;
203   const float maxPathDistance2 = 0.25f * 0.25f;
204
205   for (int i = 0; i < enemyCount; i++)
206   {
207     Enemy *enemy = &enemies[i];
208     if (enemy->enemyType == ENEMY_TYPE_NONE)
209     {
210       continue;
211     }
212
213     int waypointPassedCount = 0;
214     enemy->simPosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &enemy->simVelocity, &waypointPassedCount);
215     enemy->startMovingTime = gameTime.time;
216     // track path of unit
217     if (enemy->movePathCount == 0 || Vector2DistanceSqr(enemy->simPosition, enemy->movePath[0]) > maxPathDistance2)
218     {
219       for (int j = ENEMY_MAX_PATH_COUNT - 1; j > 0; j--)
220       {
221         enemy->movePath[j] = enemy->movePath[j - 1];
222       }
223       enemy->movePath[0] = enemy->simPosition;
224       if (++enemy->movePathCount > ENEMY_MAX_PATH_COUNT)
225       {
226         enemy->movePathCount = ENEMY_MAX_PATH_COUNT;
227       }
228     }
229
230     if (waypointPassedCount > 0)
231     {
232       enemy->currentX = enemy->nextX;
233       enemy->currentY = enemy->nextY;
234       if (EnemyGetNextPosition(enemy->currentX, enemy->currentY, &enemy->nextX, &enemy->nextY) &&
235         Vector2DistanceSqr(enemy->simPosition, (Vector2){castleX, castleY}) <= 0.25f * 0.25f)
236       {
237         // enemy reached the castle; remove it
238         enemy->enemyType = ENEMY_TYPE_NONE;
239         continue;
240       }
241     }
242   }
243
244   // handle collisions between enemies
245   for (int i = 0; i < enemyCount - 1; i++)
246   {
247     Enemy *enemyA = &enemies[i];
248     if (enemyA->enemyType == ENEMY_TYPE_NONE)
249     {
250       continue;
251     }
252     for (int j = i + 1; j < enemyCount; j++)
253     {
254       Enemy *enemyB = &enemies[j];
255       if (enemyB->enemyType == ENEMY_TYPE_NONE)
256       {
257         continue;
258       }
259       float distanceSqr = Vector2DistanceSqr(enemyA->simPosition, enemyB->simPosition);
260       float radiusA = enemyClassConfigs[enemyA->enemyType].radius;
261       float radiusB = enemyClassConfigs[enemyB->enemyType].radius;
262       float radiusSum = radiusA + radiusB;
263       if (distanceSqr < radiusSum * radiusSum && distanceSqr > 0.001f)
264       {
265         // collision
266         float distance = sqrtf(distanceSqr);
267         float overlap = radiusSum - distance;
268         // move the enemies apart, but softly; if we have a clog of enemies,
269         // moving them perfectly apart can cause them to jitter
270         float positionCorrection = overlap / 5.0f;
271         Vector2 direction = (Vector2){
272             (enemyB->simPosition.x - enemyA->simPosition.x) / distance * positionCorrection,
273             (enemyB->simPosition.y - enemyA->simPosition.y) / distance * positionCorrection};
274         enemyA->simPosition = Vector2Subtract(enemyA->simPosition, direction);
275         enemyB->simPosition = Vector2Add(enemyB->simPosition, direction);
276       }
277     }
278   }
279
280   // handle collisions between enemies and towers
281   for (int i = 0; i < enemyCount; i++)
282   {
283     Enemy *enemy = &enemies[i];
284     if (enemy->enemyType == ENEMY_TYPE_NONE)
285     {
286       continue;
287     }
288     enemy->contactTime -= gameTime.deltaTime;
289     if (enemy->contactTime < 0.0f)
290     {
291       enemy->contactTime = 0.0f;
292     }
293
294     float enemyRadius = enemyClassConfigs[enemy->enemyType].radius;
295     // linear search over towers; could be optimized by using path finding tower map,
296     // but for now, we keep it simple
297     for (int j = 0; j < towerCount; j++)
298     {
299       Tower *tower = &towers[j];
300       if (tower->towerType == TOWER_TYPE_NONE)
301       {
302         continue;
303       }
304       float distanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){tower->x, tower->y});
305       float combinedRadius = enemyRadius + 0.708; // sqrt(0.5^2 + 0.5^2), corner-center distance of square with side length 1
306       if (distanceSqr > combinedRadius * combinedRadius)
307       {
308         continue;
309       }
310       // potential collision; square / circle intersection
311       float dx = tower->x - enemy->simPosition.x;
312       float dy = tower->y - enemy->simPosition.y;
313       float absDx = fabsf(dx);
314       float absDy = fabsf(dy);
315       Vector3 contactPoint = {0};
316       if (absDx <= 0.5f && absDx <= absDy) {
317         // vertical collision; push the enemy out horizontally
318         float overlap = enemyRadius + 0.5f - absDy;
319         if (overlap < 0.0f)
320         {
321           continue;
322         }
323         float direction = dy > 0.0f ? -1.0f : 1.0f;
324         enemy->simPosition.y += direction * overlap;
325         contactPoint = (Vector3){enemy->simPosition.x, 0.2f, tower->x + direction * 0.5f};
326       }
327       else if (absDy <= 0.5f && absDy <= absDx)
328       {
329         // horizontal collision; push the enemy out vertically
330         float overlap = enemyRadius + 0.5f - absDx;
331         if (overlap < 0.0f)
332         {
333           continue;
334         }
335         float direction = dx > 0.0f ? -1.0f : 1.0f;
336         enemy->simPosition.x += direction * overlap;
337         contactPoint = (Vector3){tower->x + direction * 0.5f, 0.2f, enemy->simPosition.y};
338       }
339       else
340       {
341         // possible collision with a corner
342         float cornerDX = dx > 0.0f ? -0.5f : 0.5f;
343         float cornerDY = dy > 0.0f ? -0.5f : 0.5f;
344         float cornerX = tower->x + cornerDX;
345         float cornerY = tower->y + cornerDY;
346         float cornerDistanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){cornerX, cornerY});
347         if (cornerDistanceSqr > enemyRadius * enemyRadius)
348         {
349           continue;
350         }
351         // push the enemy out along the diagonal
352         float cornerDistance = sqrtf(cornerDistanceSqr);
353         float overlap = enemyRadius - cornerDistance;
354         float directionX = cornerDistance > 0.0f ? (cornerX - enemy->simPosition.x) / cornerDistance : -cornerDX;
355         float directionY = cornerDistance > 0.0f ? (cornerY - enemy->simPosition.y) / cornerDistance : -cornerDY;
356         enemy->simPosition.x -= directionX * overlap;
357         enemy->simPosition.y -= directionY * overlap;
358         contactPoint = (Vector3){cornerX, 0.2f, cornerY};
359       }
360
361       if (enemyClassConfigs[enemy->enemyType].explosionDamage > 0.0f)
362       {
363         enemy->contactTime += gameTime.deltaTime * 2.0f; // * 2 to undo the subtraction above
364         if (enemy->contactTime >= enemyClassConfigs[enemy->enemyType].requiredContactTime)
365         {
366           EnemyTriggerExplode(enemy, tower, contactPoint);
367         }
368       }
369     }
370   }
371 }
372
373 EnemyId EnemyGetId(Enemy *enemy)
374 {
375   return (EnemyId){enemy - enemies, enemy->generation};
376 }
377
378 Enemy *EnemyTryResolve(EnemyId enemyId)
379 {
380   if (enemyId.index >= ENEMY_MAX_COUNT)
381   {
382     return 0;
383   }
384   Enemy *enemy = &enemies[enemyId.index];
385   if (enemy->generation != enemyId.generation || enemy->enemyType == ENEMY_TYPE_NONE)
386   {
387     return 0;
388   }
389   return enemy;
390 }
391
392 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY)
393 {
394   Enemy *spawn = 0;
395   for (int i = 0; i < enemyCount; i++)
396   {
397     Enemy *enemy = &enemies[i];
398     if (enemy->enemyType == ENEMY_TYPE_NONE)
399     {
400       spawn = enemy;
401       break;
402     }
403   }
404
405   if (enemyCount < ENEMY_MAX_COUNT && !spawn)
406   {
407     spawn = &enemies[enemyCount++];
408   }
409
410   if (spawn)
411   {
412     spawn->currentX = currentX;
413     spawn->currentY = currentY;
414     spawn->nextX = currentX;
415     spawn->nextY = currentY;
416     spawn->simPosition = (Vector2){currentX, currentY};
417     spawn->simVelocity = (Vector2){0, 0};
418     spawn->enemyType = enemyType;
419     spawn->startMovingTime = gameTime.time;
420     spawn->damage = 0.0f;
421     spawn->futureDamage = 0.0f;
422     spawn->generation++;
423     spawn->movePathCount = 0;
424   }
425
426   return spawn;
427 }
428
429 int EnemyAddDamage(Enemy *enemy, float damage)
430 {
431   enemy->damage += damage;
432   if (enemy->damage >= EnemyGetMaxHealth(enemy))
433   {
434     currentLevel->playerGold += enemyClassConfigs[enemy->enemyType].goldValue;
435     enemy->enemyType = ENEMY_TYPE_NONE;
436     return 1;
437   }
438
439   return 0;
440 }
441
442 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range)
443 {
444   int16_t castleX = 0;
445   int16_t castleY = 0;
446   Enemy* closest = 0;
447   int16_t closestDistance = 0;
448   float range2 = range * range;
449   for (int i = 0; i < enemyCount; i++)
450   {
451     Enemy* enemy = &enemies[i];
452     if (enemy->enemyType == ENEMY_TYPE_NONE)
453     {
454       continue;
455     }
456     float maxHealth = EnemyGetMaxHealth(enemy);
457     if (enemy->futureDamage >= maxHealth)
458     {
459       // ignore enemies that will die soon
460       continue;
461     }
462     int16_t dx = castleX - enemy->currentX;
463     int16_t dy = castleY - enemy->currentY;
464     int16_t distance = abs(dx) + abs(dy);
465     if (!closest || distance < closestDistance)
466     {
467       float tdx = towerX - enemy->currentX;
468       float tdy = towerY - enemy->currentY;
469       float tdistance2 = tdx * tdx + tdy * tdy;
470       if (tdistance2 <= range2)
471       {
472         closest = enemy;
473         closestDistance = distance;
474       }
475     }
476   }
477   return closest;
478 }
479
480 int EnemyCount()
481 {
482   int count = 0;
483   for (int i = 0; i < enemyCount; i++)
484   {
485     if (enemies[i].enemyType != ENEMY_TYPE_NONE)
486     {
487       count++;
488     }
489   }
490   return count;
491 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 // The queue is a simple array of nodes, we add nodes to the end and remove
  5 // nodes from the front. We keep the array around to avoid unnecessary allocations
  6 static PathfindingNode *pathfindingNodeQueue = 0;
  7 static int pathfindingNodeQueueCount = 0;
  8 static int pathfindingNodeQueueCapacity = 0;
  9
 10 // The pathfinding map stores the distances from the castle to each cell in the map.
 11 static PathfindingMap pathfindingMap = {0};
 12
 13 void PathfindingMapInit(int width, int height, Vector3 translate, float scale)
 14 {
 15   // transforming between map space and world space allows us to adapt
 16   // position and scale of the map without changing the pathfinding data
 17   pathfindingMap.toWorldSpace = MatrixTranslate(translate.x, translate.y, translate.z);
 18   pathfindingMap.toWorldSpace = MatrixMultiply(pathfindingMap.toWorldSpace, MatrixScale(scale, scale, scale));
 19   pathfindingMap.toMapSpace = MatrixInvert(pathfindingMap.toWorldSpace);
 20   pathfindingMap.width = width;
 21   pathfindingMap.height = height;
 22   pathfindingMap.scale = scale;
 23   pathfindingMap.distances = (float *)MemAlloc(width * height * sizeof(float));
 24   for (int i = 0; i < width * height; i++)
 25   {
 26     pathfindingMap.distances[i] = -1.0f;
 27   }
 28
 29   pathfindingMap.towerIndex = (long *)MemAlloc(width * height * sizeof(long));
 30   pathfindingMap.deltaSrc = (DeltaSrc *)MemAlloc(width * height * sizeof(DeltaSrc));
 31 }
 32
 33 static void PathFindingNodePush(int16_t x, int16_t y, int16_t fromX, int16_t fromY, float distance)
 34 {
 35   if (pathfindingNodeQueueCount >= pathfindingNodeQueueCapacity)
 36   {
 37     pathfindingNodeQueueCapacity = pathfindingNodeQueueCapacity == 0 ? 256 : pathfindingNodeQueueCapacity * 2;
 38     // we use MemAlloc/MemRealloc to allocate memory for the queue
 39     // I am not entirely sure if MemRealloc allows passing a null pointer
 40     // so we check if the pointer is null and use MemAlloc in that case
 41     if (pathfindingNodeQueue == 0)
 42     {
 43       pathfindingNodeQueue = (PathfindingNode *)MemAlloc(pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 44     }
 45     else
 46     {
 47       pathfindingNodeQueue = (PathfindingNode *)MemRealloc(pathfindingNodeQueue, pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 48     }
 49   }
 50
 51   PathfindingNode *node = &pathfindingNodeQueue[pathfindingNodeQueueCount++];
 52   node->x = x;
 53   node->y = y;
 54   node->fromX = fromX;
 55   node->fromY = fromY;
 56   node->distance = distance;
 57 }
 58
 59 static PathfindingNode *PathFindingNodePop()
 60 {
 61   if (pathfindingNodeQueueCount == 0)
 62   {
 63     return 0;
 64   }
 65   // we return the first node in the queue; we want to return a pointer to the node
 66   // so we can return 0 if the queue is empty.
 67   // We should _not_ return a pointer to the element in the list, because the list
 68   // may be reallocated and the pointer would become invalid. Or the
 69   // popped element is overwritten by the next push operation.
 70   // Using static here means that the variable is permanently allocated.
 71   static PathfindingNode node;
 72   node = pathfindingNodeQueue[0];
 73   // we shift all nodes one position to the front
 74   for (int i = 1; i < pathfindingNodeQueueCount; i++)
 75   {
 76     pathfindingNodeQueue[i - 1] = pathfindingNodeQueue[i];
 77   }
 78   --pathfindingNodeQueueCount;
 79   return &node;
 80 }
 81
 82 float PathFindingGetDistance(int mapX, int mapY)
 83 {
 84   if (mapX < 0 || mapX >= pathfindingMap.width || mapY < 0 || mapY >= pathfindingMap.height)
 85   {
 86     // when outside the map, we return the manhattan distance to the castle (0,0)
 87     return fabsf((float)mapX) + fabsf((float)mapY);
 88   }
 89
 90   return pathfindingMap.distances[mapY * pathfindingMap.width + mapX];
 91 }
 92
 93 // transform a world position to a map position in the array;
 94 // returns true if the position is inside the map
 95 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY)
 96 {
 97   Vector3 mapPosition = Vector3Transform(worldPosition, pathfindingMap.toMapSpace);
 98   *mapX = (int16_t)mapPosition.x;
 99   *mapY = (int16_t)mapPosition.z;
100   return *mapX >= 0 && *mapX < pathfindingMap.width && *mapY >= 0 && *mapY < pathfindingMap.height;
101 }
102
103 void PathFindingMapUpdate()
104 {
105   const int castleX = 0, castleY = 0;
106   int16_t castleMapX, castleMapY;
107   if (!PathFindingFromWorldToMapPosition((Vector3){castleX, 0.0f, castleY}, &castleMapX, &castleMapY))
108   {
109     return;
110   }
111   int width = pathfindingMap.width, height = pathfindingMap.height;
112
113   // reset the distances to -1
114   for (int i = 0; i < width * height; i++)
115   {
116     pathfindingMap.distances[i] = -1.0f;
117   }
118   // reset the tower indices
119   for (int i = 0; i < width * height; i++)
120   {
121     pathfindingMap.towerIndex[i] = -1;
122   }
123   // reset the delta src
124   for (int i = 0; i < width * height; i++)
125   {
126     pathfindingMap.deltaSrc[i].x = 0;
127     pathfindingMap.deltaSrc[i].y = 0;
128   }
129
130   for (int i = 0; i < towerCount; i++)
131   {
132     Tower *tower = &towers[i];
133     if (tower->towerType == TOWER_TYPE_NONE || tower->towerType == TOWER_TYPE_BASE)
134     {
135       continue;
136     }
137     int16_t mapX, mapY;
138     // technically, if the tower cell scale is not in sync with the pathfinding map scale,
139     // this would not work correctly and needs to be refined to allow towers covering multiple cells
140     // or having multiple towers in one cell; for simplicity, we assume that the tower covers exactly
141     // one cell. For now.
142     if (!PathFindingFromWorldToMapPosition((Vector3){tower->x, 0.0f, tower->y}, &mapX, &mapY))
143     {
144       continue;
145     }
146     int index = mapY * width + mapX;
147     pathfindingMap.towerIndex[index] = i;
148   }
149
150   // we start at the castle and add the castle to the queue
151   pathfindingMap.maxDistance = 0.0f;
152   pathfindingNodeQueueCount = 0;
153   PathFindingNodePush(castleMapX, castleMapY, castleMapX, castleMapY, 0.0f);
154   PathfindingNode *node = 0;
155   while ((node = PathFindingNodePop()))
156   {
157     if (node->x < 0 || node->x >= width || node->y < 0 || node->y >= height)
158     {
159       continue;
160     }
161     int index = node->y * width + node->x;
162     if (pathfindingMap.distances[index] >= 0 && pathfindingMap.distances[index] <= node->distance)
163     {
164       continue;
165     }
166
167     int deltaX = node->x - node->fromX;
168     int deltaY = node->y - node->fromY;
169     // even if the cell is blocked by a tower, we still may want to store the direction
170     // (though this might not be needed, IDK right now)
171     pathfindingMap.deltaSrc[index].x = (char) deltaX;
172     pathfindingMap.deltaSrc[index].y = (char) deltaY;
173
174     // we skip nodes that are blocked by towers
175     if (pathfindingMap.towerIndex[index] >= 0)
176     {
177       node->distance += 8.0f;
178     }
179     pathfindingMap.distances[index] = node->distance;
180     pathfindingMap.maxDistance = fmaxf(pathfindingMap.maxDistance, node->distance);
181     PathFindingNodePush(node->x, node->y + 1, node->x, node->y, node->distance + 1.0f);
182     PathFindingNodePush(node->x, node->y - 1, node->x, node->y, node->distance + 1.0f);
183     PathFindingNodePush(node->x + 1, node->y, node->x, node->y, node->distance + 1.0f);
184     PathFindingNodePush(node->x - 1, node->y, node->x, node->y, node->distance + 1.0f);
185   }
186 }
187
188 void PathFindingMapDraw()
189 {
190   float cellSize = pathfindingMap.scale * 0.9f;
191   float highlightDistance = fmodf(GetTime() * 4.0f, pathfindingMap.maxDistance);
192   for (int x = 0; x < pathfindingMap.width; x++)
193   {
194     for (int y = 0; y < pathfindingMap.height; y++)
195     {
196       float distance = pathfindingMap.distances[y * pathfindingMap.width + x];
197       float colorV = distance < 0 ? 0 : fminf(distance / pathfindingMap.maxDistance, 1.0f);
198       Color color = distance < 0 ? BLUE : (Color){fminf(colorV, 1.0f) * 255, 0, 0, 255};
199       Vector3 position = Vector3Transform((Vector3){x, -0.25f, y}, pathfindingMap.toWorldSpace);
200       // animate the distance "wave" to show how the pathfinding algorithm expands
201       // from the castle
202       if (distance + 0.5f > highlightDistance && distance - 0.5f < highlightDistance)
203       {
204         color = BLACK;
205       }
206       DrawCube(position, cellSize, 0.1f, cellSize, color);
207     }
208   }
209 }
210
211 Vector2 PathFindingGetGradient(Vector3 world)
212 {
213   int16_t mapX, mapY;
214   if (PathFindingFromWorldToMapPosition(world, &mapX, &mapY))
215   {
216     DeltaSrc delta = pathfindingMap.deltaSrc[mapY * pathfindingMap.width + mapX];
217     return (Vector2){(float)-delta.x, (float)-delta.y};
218   }
219   // fallback to a simple gradient calculation
220   float n = PathFindingGetDistance(mapX, mapY - 1);
221   float s = PathFindingGetDistance(mapX, mapY + 1);
222   float w = PathFindingGetDistance(mapX - 1, mapY);
223   float e = PathFindingGetDistance(mapX + 1, mapY);
224   return (Vector2){w - e + 0.25f, n - s + 0.125f};
225 }

  1 #include "raylib.h"
  2 #include "preferred_size.h"
  3
  4 // Since the canvas size is not known at compile time, we need to query it at runtime;
  5 // the following platform specific code obtains the canvas size and we will use this
  6 // size as the preferred size for the window at init time. We're ignoring here the
  7 // possibility of the canvas size changing during runtime - this would require to
  8 // poll the canvas size in the game loop or establishing a callback to be notified
  9
 10 #ifdef PLATFORM_WEB
 11 #include <emscripten.h>
 12 EMSCRIPTEN_RESULT emscripten_get_element_css_size(const char *target, double *width, double *height);
 13
 14 void GetPreferredSize(int *screenWidth, int *screenHeight)
 15 {
 16   double canvasWidth, canvasHeight;
 17   emscripten_get_element_css_size("#" CANVAS_NAME, &canvasWidth, &canvasHeight);
 18   *screenWidth = (int)canvasWidth;
 19   *screenHeight = (int)canvasHeight;
 20   TraceLog(LOG_INFO, "preferred size for %s: %d %d", CANVAS_NAME, *screenWidth, *screenHeight);
 21 }
 22
 23 int IsPaused()
 24 {
 25   const char *js = "(function(){\n"
 26   "  var canvas = document.getElementById(\"" CANVAS_NAME "\");\n"
 27   "  var rect = canvas.getBoundingClientRect();\n"
 28   "  var isVisible = (\n"
 29   "    rect.top >= 0 &&\n"
 30   "    rect.left >= 0 &&\n"
 31   "    rect.bottom <= (window.innerHeight || document.documentElement.clientHeight) &&\n"
 32   "    rect.right <= (window.innerWidth || document.documentElement.clientWidth)\n"
 33   "  );\n"
 34   "  return isVisible ? 0 : 1;\n"
 35   "})()";
 36   return emscripten_run_script_int(js);
 37 }
 38
 39 #else
 40 void GetPreferredSize(int *screenWidth, int *screenHeight)
 41 {
 42   *screenWidth = 600;
 43   *screenHeight = 240;
 44 }
 45 int IsPaused()
 46 {
 47   return 0;
 48 }
 49 #endif

  1 #ifndef PREFERRED_SIZE_H
  2 #define PREFERRED_SIZE_H
  3
  4 void GetPreferredSize(int *screenWidth, int *screenHeight);
  5 int IsPaused();
  6
  7 #endif

The path finding module is interesting to look at, because a few decisions may require a bit of explaining:

  1 // The queue is a simple array of nodes, we add nodes to the end and remove
  2 // nodes from the front. We keep the array around to avoid unnecessary allocations
  3 static PathfindingNode *pathfindingNodeQueue = 0;
  4 static int pathfindingNodeQueueCount = 0;
  5 static int pathfindingNodeQueueCapacity = 0;
  6
  7 // The pathfinding map stores the distances from the castle to each cell in the map.
  8 static PathfindingMap pathfindingMap = {0};

The variables are now all declared as static.

When I structure a C file module, I try to put the global variables at the top of the file (optimally: none - but for the sake of simplicity in this tutorial, I am using them more often than I would in a "real" project). A global variable is a variable that is accessible from all functions in the project - however, static variables are only accessible from the file they are declared in. Non static variables are accessible from other files that know of their existence via declaration ("extern ...").

In this case, all the global variables that the path finding module uses are static - which is a bit better than a global variable that is accessible from all files. Using global variables is not wrong per se, but the fewer the better and the smaller their scope the better.

There are also a few static functions that are only used in this file. My strategy is usually to avoid forward declarations of functions if possible, so I put static functions at the top of the file. This way, the functions are declared before they are used just naturally. If there is some kind of initialization function, I try to put it at the very top of the file, just because I regard it as a central function that plays an important role in the module.

Let's move on with extracting modules from the main file:

td-tut-40/td_main.c
td-tut-40/td_main.h
td-tut-40/enemy.c
td-tut-40/path_finding.c
td-tut-40/projectile_system.c
td-tut-40/particle_system.c
td-tut-40/preferred_size.c
td-tut-40/preferred_size.h
💾

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 //# Variables
  7 GUIState guiState = {0};
  8 GameTime gameTime = {0};
  9 Tower towers[TOWER_MAX_COUNT];
 10 int towerCount = 0;
 11
 12 Level levels[] = {
 13   [0] = {
 14     .state = LEVEL_STATE_BUILDING,
 15     .initialGold = 10,
 16     .waves[0] = {
 17       .enemyType = ENEMY_TYPE_MINION,
 18       .wave = 0,
 19       .count = 10,
 20       .interval = 1.0f,
 21       .delay = 1.0f,
 22       .spawnPosition = {0, 6},
 23     },
 24     .waves[1] = {
 25       .enemyType = ENEMY_TYPE_MINION,
 26       .wave = 1,
 27       .count = 20,
 28       .interval = 0.5f,
 29       .delay = 1.0f,
 30       .spawnPosition = {0, 6},
 31     },
 32     .waves[2] = {
 33       .enemyType = ENEMY_TYPE_MINION,
 34       .wave = 2,
 35       .count = 30,
 36       .interval = 0.25f,
 37       .delay = 1.0f,
 38       .spawnPosition = {0, 6},
 39     }
 40   },
 41 };
 42
 43 Level *currentLevel = levels;
 44
 45 //# Towers
 46
 47 void TowerInit()
 48 {
 49   for (int i = 0; i < TOWER_MAX_COUNT; i++)
 50   {
 51     towers[i] = (Tower){0};
 52   }
 53   towerCount = 0;
 54 }
 55
 56 Tower *TowerGetAt(int16_t x, int16_t y)
 57 {
 58   for (int i = 0; i < towerCount; i++)
 59   {
 60     if (towers[i].x == x && towers[i].y == y)
 61     {
 62       return &towers[i];
 63     }
 64   }
 65   return 0;
 66 }
 67
 68 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y)
 69 {
 70   if (towerCount >= TOWER_MAX_COUNT)
 71   {
 72     return 0;
 73   }
 74
 75   Tower *tower = TowerGetAt(x, y);
 76   if (tower)
 77   {
 78     return 0;
 79   }
 80
 81   tower = &towers[towerCount++];
 82   tower->x = x;
 83   tower->y = y;
 84   tower->towerType = towerType;
 85   tower->cooldown = 0.0f;
 86   tower->damage = 0.0f;
 87   return tower;
 88 }
 89
 90 Tower *GetTowerByType(uint8_t towerType)
 91 {
 92   for (int i = 0; i < towerCount; i++)
 93   {
 94     if (towers[i].towerType == towerType)
 95     {
 96       return &towers[i];
 97     }
 98   }
 99   return 0;
100 }
101
102 int GetTowerCosts(uint8_t towerType)
103 {
104   switch (towerType)
105   {
106   case TOWER_TYPE_BASE:
107     return 0;
108   case TOWER_TYPE_GUN:
109     return 6;
110   case TOWER_TYPE_WALL:
111     return 2;
112   }
113   return 0;
114 }
115
116 float TowerGetMaxHealth(Tower *tower)
117 {
118   switch (tower->towerType)
119   {
120   case TOWER_TYPE_BASE:
121     return 10.0f;
122   case TOWER_TYPE_GUN:
123     return 3.0f;
124   case TOWER_TYPE_WALL:
125     return 5.0f;
126   }
127   return 0.0f;
128 }
129
130 void TowerDraw()
131 {
132   for (int i = 0; i < towerCount; i++)
133   {
134     Tower tower = towers[i];
135     DrawCube((Vector3){tower.x, 0.125f, tower.y}, 1.0f, 0.25f, 1.0f, GRAY);
136     switch (tower.towerType)
137     {
138     case TOWER_TYPE_BASE:
139       DrawCube((Vector3){tower.x, 0.4f, tower.y}, 0.8f, 0.8f, 0.8f, MAROON);
140       break;
141     case TOWER_TYPE_GUN:
142       DrawCube((Vector3){tower.x, 0.2f, tower.y}, 0.8f, 0.4f, 0.8f, DARKPURPLE);
143       break;
144     case TOWER_TYPE_WALL:
145       DrawCube((Vector3){tower.x, 0.5f, tower.y}, 1.0f, 1.0f, 1.0f, LIGHTGRAY);
146       break;
147     }
148   }
149 }
150
151 void TowerGunUpdate(Tower *tower)
152 {
153   if (tower->cooldown <= 0)
154   {
155     Enemy *enemy = EnemyGetClosestToCastle(tower->x, tower->y, 3.0f);
156     if (enemy)
157     {
158       tower->cooldown = 0.125f;
159       // shoot the enemy; determine future position of the enemy
160       float bulletSpeed = 1.0f;
161       float bulletDamage = 3.0f;
162       Vector2 velocity = enemy->simVelocity;
163       Vector2 futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &velocity, 0);
164       Vector2 towerPosition = {tower->x, tower->y};
165       float eta = Vector2Distance(towerPosition, futurePosition) / bulletSpeed;
166       for (int i = 0; i < 8; i++) {
167         velocity = enemy->simVelocity;
168         futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime + eta, &velocity, 0);
169         float distance = Vector2Distance(towerPosition, futurePosition);
170         float eta2 = distance / bulletSpeed;
171         if (fabs(eta - eta2) < 0.01f) {
172           break;
173         }
174         eta = (eta2 + eta) * 0.5f;
175       }
176       ProjectileTryAdd(PROJECTILE_TYPE_BULLET, enemy, towerPosition, futurePosition,
177         bulletSpeed, bulletDamage);
178       enemy->futureDamage += bulletDamage;
179     }
180   }
181   else
182   {
183     tower->cooldown -= gameTime.deltaTime;
184   }
185 }
186
187 void TowerUpdate()
188 {
189   for (int i = 0; i < towerCount; i++)
190   {
191     Tower *tower = &towers[i];
192     switch (tower->towerType)
193     {
194     case TOWER_TYPE_GUN:
195       TowerGunUpdate(tower);
196       break;
197     }
198   }
199 }
200
201 //# Game
202
203 void InitLevel(Level *level)
204 {
205   TowerInit();
206   EnemyInit();
207   ProjectileInit();
208   ParticleInit();
209   TowerTryAdd(TOWER_TYPE_BASE, 0, 0);
210
211   level->placementMode = 0;
212   level->state = LEVEL_STATE_BUILDING;
213   level->nextState = LEVEL_STATE_NONE;
214   level->playerGold = level->initialGold;
215
216   Camera *camera = &level->camera;
217   camera->position = (Vector3){1.0f, 12.0f, 6.5f};
218   camera->target = (Vector3){0.0f, 0.5f, 1.0f};
219   camera->up = (Vector3){0.0f, 1.0f, 0.0f};
220   camera->fovy = 45.0f;
221   camera->projection = CAMERA_PERSPECTIVE;
222 }
223
224 void DrawLevelHud(Level *level)
225 {
226   const char *text = TextFormat("Gold: %d", level->playerGold);
227   Font font = GetFontDefault();
228   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 120, 10}, font.baseSize * 2.0f, 2.0f, BLACK);
229   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 122, 8}, font.baseSize * 2.0f, 2.0f, YELLOW);
230 }
231
232 void DrawLevelReportLostWave(Level *level)
233 {
234   BeginMode3D(level->camera);
235   DrawGrid(10, 1.0f);
236   TowerDraw();
237   EnemyDraw();
238   ProjectileDraw();
239   ParticleDraw();
240   guiState.isBlocked = 0;
241   EndMode3D();
242
243   const char *text = "Wave lost";
244   int textWidth = MeasureText(text, 20);
245   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
246
247   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
248   {
249     level->nextState = LEVEL_STATE_RESET;
250   }
251 }
252
253 int HasLevelNextWave(Level *level)
254 {
255   for (int i = 0; i < 10; i++)
256   {
257     EnemyWave *wave = &level->waves[i];
258     if (wave->wave == level->currentWave)
259     {
260       return 1;
261     }
262   }
263   return 0;
264 }
265
266 void DrawLevelReportWonWave(Level *level)
267 {
268   BeginMode3D(level->camera);
269   DrawGrid(10, 1.0f);
270   TowerDraw();
271   EnemyDraw();
272   ProjectileDraw();
273   ParticleDraw();
274   guiState.isBlocked = 0;
275   EndMode3D();
276
277   const char *text = "Wave won";
278   int textWidth = MeasureText(text, 20);
279   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
280
281
282   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
283   {
284     level->nextState = LEVEL_STATE_RESET;
285   }
286
287   if (HasLevelNextWave(level))
288   {
289     if (Button("Prepare for next wave", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
290     {
291       level->nextState = LEVEL_STATE_BUILDING;
292     }
293   }
294   else {
295     if (Button("Level won", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
296     {
297       level->nextState = LEVEL_STATE_WON_LEVEL;
298     }
299   }
300 }
301
302 void DrawBuildingBuildButton(Level *level, int x, int y, int width, int height, uint8_t towerType, const char *name)
303 {
304   static ButtonState buttonStates[8] = {0};
305   int cost = GetTowerCosts(towerType);
306   const char *text = TextFormat("%s: %d", name, cost);
307   buttonStates[towerType].isSelected = level->placementMode == towerType;
308   buttonStates[towerType].isDisabled = level->playerGold < cost;
309   if (Button(text, x, y, width, height, &buttonStates[towerType]))
310   {
311     level->placementMode = buttonStates[towerType].isSelected ? 0 : towerType;
312   }
313 }
314
315 void DrawLevelBuildingState(Level *level)
316 {
317   BeginMode3D(level->camera);
318   DrawGrid(10, 1.0f);
319   TowerDraw();
320   EnemyDraw();
321   ProjectileDraw();
322   ParticleDraw();
323
324   Ray ray = GetScreenToWorldRay(GetMousePosition(), level->camera);
325   float planeDistance = ray.position.y / -ray.direction.y;
326   float planeX = ray.direction.x * planeDistance + ray.position.x;
327   float planeY = ray.direction.z * planeDistance + ray.position.z;
328   int16_t mapX = (int16_t)floorf(planeX + 0.5f);
329   int16_t mapY = (int16_t)floorf(planeY + 0.5f);
330   if (level->placementMode && !guiState.isBlocked)
331   {
332     DrawCubeWires((Vector3){mapX, 0.2f, mapY}, 1.0f, 0.4f, 1.0f, RED);
333     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
334     {
335       if (TowerTryAdd(level->placementMode, mapX, mapY))
336       {
337         level->playerGold -= GetTowerCosts(level->placementMode);
338         level->placementMode = TOWER_TYPE_NONE;
339       }
340     }
341   }
342
343   guiState.isBlocked = 0;
344
345   EndMode3D();
346
347   static ButtonState buildWallButtonState = {0};
348   static ButtonState buildGunButtonState = {0};
349   buildWallButtonState.isSelected = level->placementMode == TOWER_TYPE_WALL;
350   buildGunButtonState.isSelected = level->placementMode == TOWER_TYPE_GUN;
351
352   DrawBuildingBuildButton(level, 10, 10, 80, 30, TOWER_TYPE_WALL, "Wall");
353   DrawBuildingBuildButton(level, 10, 50, 80, 30, TOWER_TYPE_GUN, "Gun");
354
355   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
356   {
357     level->nextState = LEVEL_STATE_RESET;
358   }
359
360   if (Button("Begin waves", GetScreenWidth() - 160, GetScreenHeight() - 40, 160, 30, 0))
361   {
362     level->nextState = LEVEL_STATE_BATTLE;
363   }
364
365   const char *text = "Building phase";
366   int textWidth = MeasureText(text, 20);
367   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
368 }
369
370 void InitBattleStateConditions(Level *level)
371 {
372   level->state = LEVEL_STATE_BATTLE;
373   level->nextState = LEVEL_STATE_NONE;
374   level->waveEndTimer = 0.0f;
375   for (int i = 0; i < 10; i++)
376   {
377     EnemyWave *wave = &level->waves[i];
378     wave->spawned = 0;
379     wave->timeToSpawnNext = wave->delay;
380   }
381 }
382
383 void DrawLevelBattleState(Level *level)
384 {
385   BeginMode3D(level->camera);
386   DrawGrid(10, 1.0f);
387   TowerDraw();
388   EnemyDraw();
389   ProjectileDraw();
390   ParticleDraw();
391   guiState.isBlocked = 0;
392   EndMode3D();
393
394   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
395   {
396     level->nextState = LEVEL_STATE_RESET;
397   }
398
399   int maxCount = 0;
400   int remainingCount = 0;
401   for (int i = 0; i < 10; i++)
402   {
403     EnemyWave *wave = &level->waves[i];
404     if (wave->wave != level->currentWave)
405     {
406       continue;
407     }
408     maxCount += wave->count;
409     remainingCount += wave->count - wave->spawned;
410   }
411   int aliveCount = EnemyCount();
412   remainingCount += aliveCount;
413
414   const char *text = TextFormat("Battle phase: %03d%%", 100 - remainingCount * 100 / maxCount);
415   int textWidth = MeasureText(text, 20);
416   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
417 }
418
419 void DrawLevel(Level *level)
420 {
421   switch (level->state)
422   {
423     case LEVEL_STATE_BUILDING: DrawLevelBuildingState(level); break;
424     case LEVEL_STATE_BATTLE: DrawLevelBattleState(level); break;
425     case LEVEL_STATE_WON_WAVE: DrawLevelReportWonWave(level); break;
426     case LEVEL_STATE_LOST_WAVE: DrawLevelReportLostWave(level); break;
427     default: break;
428   }
429
430   DrawLevelHud(level);
431 }
432
433 void UpdateLevel(Level *level)
434 {
435   if (level->state == LEVEL_STATE_BATTLE)
436   {
437     int activeWaves = 0;
438     for (int i = 0; i < 10; i++)
439     {
440       EnemyWave *wave = &level->waves[i];
441       if (wave->spawned >= wave->count || wave->wave != level->currentWave)
442       {
443         continue;
444       }
445       activeWaves++;
446       wave->timeToSpawnNext -= gameTime.deltaTime;
447       if (wave->timeToSpawnNext <= 0.0f)
448       {
449         Enemy *enemy = EnemyTryAdd(wave->enemyType, wave->spawnPosition.x, wave->spawnPosition.y);
450         if (enemy)
451         {
452           wave->timeToSpawnNext = wave->interval;
453           wave->spawned++;
454         }
455       }
456     }
457     if (GetTowerByType(TOWER_TYPE_BASE) == 0) {
458       level->waveEndTimer += gameTime.deltaTime;
459       if (level->waveEndTimer >= 2.0f)
460       {
461         level->nextState = LEVEL_STATE_LOST_WAVE;
462       }
463     }
464     else if (activeWaves == 0 && EnemyCount() == 0)
465     {
466       level->waveEndTimer += gameTime.deltaTime;
467       if (level->waveEndTimer >= 2.0f)
468       {
469         level->nextState = LEVEL_STATE_WON_WAVE;
470       }
471     }
472   }
473
474   PathFindingMapUpdate();
475   EnemyUpdate();
476   TowerUpdate();
477   ProjectileUpdate();
478   ParticleUpdate();
479
480   if (level->nextState == LEVEL_STATE_RESET)
481   {
482     InitLevel(level);
483   }
484
485   if (level->nextState == LEVEL_STATE_BATTLE)
486   {
487     InitBattleStateConditions(level);
488   }
489
490   if (level->nextState == LEVEL_STATE_WON_WAVE)
491   {
492     level->currentWave++;
493     level->state = LEVEL_STATE_WON_WAVE;
494   }
495
496   if (level->nextState == LEVEL_STATE_LOST_WAVE)
497   {
498     level->state = LEVEL_STATE_LOST_WAVE;
499   }
500
501   if (level->nextState == LEVEL_STATE_BUILDING)
502   {
503     level->state = LEVEL_STATE_BUILDING;
504   }
505
506   if (level->nextState == LEVEL_STATE_WON_LEVEL)
507   {
508     // make something of this later
509     InitLevel(level);
510   }
511
512   level->nextState = LEVEL_STATE_NONE;
513 }
514
515 float nextSpawnTime = 0.0f;
516
517 void ResetGame()
518 {
519   InitLevel(currentLevel);
520 }
521
522 void InitGame()
523 {
524   TowerInit();
525   EnemyInit();
526   ProjectileInit();
527   ParticleInit();
528   PathfindingMapInit(20, 20, (Vector3){-10.0f, 0.0f, -10.0f}, 1.0f);
529
530   currentLevel = levels;
531   InitLevel(currentLevel);
532 }
533
534 //# Immediate GUI functions
535
536 int Button(const char *text, int x, int y, int width, int height, ButtonState *state)
537 {
538   Rectangle bounds = {x, y, width, height};
539   int isPressed = 0;
540   int isSelected = state && state->isSelected;
541   if (CheckCollisionPointRec(GetMousePosition(), bounds) && !guiState.isBlocked && !state->isDisabled)
542   {
543     Color color = isSelected ? DARKGRAY : GRAY;
544     DrawRectangle(x, y, width, height, color);
545     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
546     {
547       isPressed = 1;
548     }
549     guiState.isBlocked = 1;
550   }
551   else
552   {
553     Color color = isSelected ? WHITE : LIGHTGRAY;
554     DrawRectangle(x, y, width, height, color);
555   }
556   Font font = GetFontDefault();
557   Vector2 textSize = MeasureTextEx(font, text, font.baseSize * 2.0f, 1);
558   Color textColor = state->isDisabled ? GRAY : BLACK;
559   DrawTextEx(font, text, (Vector2){x + width / 2 - textSize.x / 2, y + height / 2 - textSize.y / 2}, font.baseSize * 2.0f, 1, textColor);
560   return isPressed;
561 }
562
563 //# Main game loop
564
565 void GameUpdate()
566 {
567   float dt = GetFrameTime();
568   // cap maximum delta time to 0.1 seconds to prevent large time steps
569   if (dt > 0.1f) dt = 0.1f;
570   gameTime.time += dt;
571   gameTime.deltaTime = dt;
572
573   UpdateLevel(currentLevel);
574 }
575
576 int main(void)
577 {
578   int screenWidth, screenHeight;
579   GetPreferredSize(&screenWidth, &screenHeight);
580   InitWindow(screenWidth, screenHeight, "Tower defense");
581   SetTargetFPS(30);
582
583   InitGame();
584
585   while (!WindowShouldClose())
586   {
587     if (IsPaused()) {
588       // canvas is not visible in browser - do nothing
589       continue;
590     }
591
592     BeginDrawing();
593     ClearBackground(DARKBLUE);
594
595     GameUpdate();
596     DrawLevel(currentLevel);
597
598     EndDrawing();
599   }
600
601   CloseWindow();
602
603   return 0;
604 }

  1 #ifndef TD_TUT_2_MAIN_H
  2 #define TD_TUT_2_MAIN_H
  3
  4 #include <inttypes.h>
  5
  6 #include "raylib.h"
  7 #include "preferred_size.h"
  8
  9 //# Declarations
 10
 11 #define ENEMY_MAX_PATH_COUNT 8
 12 #define ENEMY_MAX_COUNT 400
 13 #define ENEMY_TYPE_NONE 0
 14 #define ENEMY_TYPE_MINION 1
 15
 16 #define PARTICLE_MAX_COUNT 400
 17 #define PARTICLE_TYPE_NONE 0
 18 #define PARTICLE_TYPE_EXPLOSION 1
 19
 20 typedef struct Particle
 21 {
 22   uint8_t particleType;
 23   float spawnTime;
 24   float lifetime;
 25   Vector3 position;
 26   Vector3 velocity;
 27 } Particle;
 28
 29 #define TOWER_MAX_COUNT 400
 30 #define TOWER_TYPE_NONE 0
 31 #define TOWER_TYPE_BASE 1
 32 #define TOWER_TYPE_GUN 2
 33 #define TOWER_TYPE_WALL 3
 34
 35 typedef struct Tower
 36 {
 37   int16_t x, y;
 38   uint8_t towerType;
 39   float cooldown;
 40   float damage;
 41 } Tower;
 42
 43 typedef struct GameTime
 44 {
 45   float time;
 46   float deltaTime;
 47 } GameTime;
 48
 49 typedef struct ButtonState {
 50   char isSelected;
 51   char isDisabled;
 52 } ButtonState;
 53
 54 typedef struct GUIState {
 55   int isBlocked;
 56 } GUIState;
 57
 58 typedef enum LevelState
 59 {
 60   LEVEL_STATE_NONE,
 61   LEVEL_STATE_BUILDING,
 62   LEVEL_STATE_BATTLE,
 63   LEVEL_STATE_WON_WAVE,
 64   LEVEL_STATE_LOST_WAVE,
 65   LEVEL_STATE_WON_LEVEL,
 66   LEVEL_STATE_RESET,
 67 } LevelState;
 68
 69 typedef struct EnemyWave {
 70   uint8_t enemyType;
 71   uint8_t wave;
 72   uint16_t count;
 73   float interval;
 74   float delay;
 75   Vector2 spawnPosition;
 76
 77   uint16_t spawned;
 78   float timeToSpawnNext;
 79 } EnemyWave;
 80
 81 typedef struct Level
 82 {
 83   LevelState state;
 84   LevelState nextState;
 85   Camera3D camera;
 86   int placementMode;
 87
 88   int initialGold;
 89   int playerGold;
 90
 91   EnemyWave waves[10];
 92   int currentWave;
 93   float waveEndTimer;
 94 } Level;
 95
 96 typedef struct DeltaSrc
 97 {
 98   char x, y;
 99 } DeltaSrc;
100
101 typedef struct PathfindingMap
102 {
103   int width, height;
104   float scale;
105   float *distances;
106   long *towerIndex;
107   DeltaSrc *deltaSrc;
108   float maxDistance;
109   Matrix toMapSpace;
110   Matrix toWorldSpace;
111 } PathfindingMap;
112
113 // when we execute the pathfinding algorithm, we need to store the active nodes
114 // in a queue. Each node has a position, a distance from the start, and the
115 // position of the node that we came from.
116 typedef struct PathfindingNode
117 {
118   int16_t x, y, fromX, fromY;
119   float distance;
120 } PathfindingNode;
121
122 typedef struct EnemyId
123 {
124   uint16_t index;
125   uint16_t generation;
126 } EnemyId;
127
128 typedef struct EnemyClassConfig
129 {
130   float speed;
131   float health;
132   float radius;
133   float maxAcceleration;
134   float requiredContactTime;
135   float explosionDamage;
136   float explosionRange;
137   float explosionPushbackPower;
138   int goldValue;
139 } EnemyClassConfig;
140
141 typedef struct Enemy
142 {
143   int16_t currentX, currentY;
144   int16_t nextX, nextY;
145   Vector2 simPosition;
146   Vector2 simVelocity;
147   uint16_t generation;
148   float startMovingTime;
149   float damage, futureDamage;
150   float contactTime;
151   uint8_t enemyType;
152   uint8_t movePathCount;
153   Vector2 movePath[ENEMY_MAX_PATH_COUNT];
154 } Enemy;
155
156 #define PROJECTILE_MAX_COUNT 1200
157 #define PROJECTILE_TYPE_NONE 0
158 #define PROJECTILE_TYPE_BULLET 1
159
160 typedef struct Projectile
161 {
162   uint8_t projectileType;
163   float shootTime;
164   float arrivalTime;
165   float damage;
166   Vector2 position;
167   Vector2 target;
168   Vector2 directionNormal;
169   EnemyId targetEnemy;
170 } Projectile;
171
172 //# Function declarations
173 float TowerGetMaxHealth(Tower *tower);
174 int Button(const char *text, int x, int y, int width, int height, ButtonState *state);
175 int EnemyAddDamage(Enemy *enemy, float damage);
176
177 //# Enemy functions
178 void EnemyInit();
179 void EnemyDraw();
180 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource);
181 void EnemyUpdate();
182 float EnemyGetCurrentMaxSpeed(Enemy *enemy);
183 float EnemyGetMaxHealth(Enemy *enemy);
184 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY);
185 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount);
186 EnemyId EnemyGetId(Enemy *enemy);
187 Enemy *EnemyTryResolve(EnemyId enemyId);
188 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY);
189 int EnemyAddDamage(Enemy *enemy, float damage);
190 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range);
191 int EnemyCount();
192
193 //# Particles
194 void ParticleInit();
195 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime);
196 void ParticleUpdate();
197 void ParticleDraw();
198
199 //# Projectiles
200 void ProjectileInit();
201 void ProjectileDraw();
202 void ProjectileUpdate();
203 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage);
204
205 //# Pathfinding map
206 void PathfindingMapInit(int width, int height, Vector3 translate, float scale);
207 float PathFindingGetDistance(int mapX, int mapY);
208 Vector2 PathFindingGetGradient(Vector3 world);
209 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY);
210 void PathFindingMapUpdate();
211 void PathFindingMapDraw();
212
213 //# variables
214 extern Level *currentLevel;
215 extern Enemy enemies[ENEMY_MAX_COUNT];
216 extern int enemyCount;
217 extern EnemyClassConfig enemyClassConfigs[];
218
219 extern GUIState guiState;
220 extern GameTime gameTime;
221 extern Tower towers[TOWER_MAX_COUNT];
222 extern int towerCount;
223
224 #endif

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 EnemyClassConfig enemyClassConfigs[] = {
  7     [ENEMY_TYPE_MINION] = {
  8       .health = 3.0f,
  9       .speed = 1.0f,
 10       .radius = 0.25f,
 11       .maxAcceleration = 1.0f,
 12       .explosionDamage = 1.0f,
 13       .requiredContactTime = 0.5f,
 14       .explosionRange = 1.0f,
 15       .explosionPushbackPower = 0.25f,
 16       .goldValue = 1,
 17     },
 18 };
 19
 20 Enemy enemies[ENEMY_MAX_COUNT];
 21 int enemyCount = 0;
 22
 23 void EnemyInit()
 24 {
 25   for (int i = 0; i < ENEMY_MAX_COUNT; i++)
 26   {
 27     enemies[i] = (Enemy){0};
 28   }
 29   enemyCount = 0;
 30 }
 31
 32 float EnemyGetCurrentMaxSpeed(Enemy *enemy)
 33 {
 34   return enemyClassConfigs[enemy->enemyType].speed;
 35 }
 36
 37 float EnemyGetMaxHealth(Enemy *enemy)
 38 {
 39   return enemyClassConfigs[enemy->enemyType].health;
 40 }
 41
 42 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY)
 43 {
 44   int16_t castleX = 0;
 45   int16_t castleY = 0;
 46   int16_t dx = castleX - currentX;
 47   int16_t dy = castleY - currentY;
 48   if (dx == 0 && dy == 0)
 49   {
 50     *nextX = currentX;
 51     *nextY = currentY;
 52     return 1;
 53   }
 54   Vector2 gradient = PathFindingGetGradient((Vector3){currentX, 0, currentY});
 55
 56   if (gradient.x == 0 && gradient.y == 0)
 57   {
 58     *nextX = currentX;
 59     *nextY = currentY;
 60     return 1;
 61   }
 62
 63   if (fabsf(gradient.x) > fabsf(gradient.y))
 64   {
 65     *nextX = currentX + (int16_t)(gradient.x > 0.0f ? 1 : -1);
 66     *nextY = currentY;
 67     return 0;
 68   }
 69   *nextX = currentX;
 70   *nextY = currentY + (int16_t)(gradient.y > 0.0f ? 1 : -1);
 71   return 0;
 72 }
 73
 74
 75 // this function predicts the movement of the unit for the next deltaT seconds
 76 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount)
 77 {
 78   const float pointReachedDistance = 0.25f;
 79   const float pointReachedDistance2 = pointReachedDistance * pointReachedDistance;
 80   const float maxSimStepTime = 0.015625f;
 81
 82   float maxAcceleration = enemyClassConfigs[enemy->enemyType].maxAcceleration;
 83   float maxSpeed = EnemyGetCurrentMaxSpeed(enemy);
 84   int16_t nextX = enemy->nextX;
 85   int16_t nextY = enemy->nextY;
 86   Vector2 position = enemy->simPosition;
 87   int passedCount = 0;
 88   for (float t = 0.0f; t < deltaT; t += maxSimStepTime)
 89   {
 90     float stepTime = fminf(deltaT - t, maxSimStepTime);
 91     Vector2 target = (Vector2){nextX, nextY};
 92     float speed = Vector2Length(*velocity);
 93     // draw the target position for debugging
 94     DrawCubeWires((Vector3){target.x, 0.2f, target.y}, 0.1f, 0.4f, 0.1f, RED);
 95     Vector2 lookForwardPos = Vector2Add(position, Vector2Scale(*velocity, speed));
 96     if (Vector2DistanceSqr(target, lookForwardPos) <= pointReachedDistance2)
 97     {
 98       // we reached the target position, let's move to the next waypoint
 99       EnemyGetNextPosition(nextX, nextY, &nextX, &nextY);
100       target = (Vector2){nextX, nextY};
101       // track how many waypoints we passed
102       passedCount++;
103     }
104
105     // acceleration towards the target
106     Vector2 unitDirection = Vector2Normalize(Vector2Subtract(target, lookForwardPos));
107     Vector2 acceleration = Vector2Scale(unitDirection, maxAcceleration * stepTime);
108     *velocity = Vector2Add(*velocity, acceleration);
109
110     // limit the speed to the maximum speed
111     if (speed > maxSpeed)
112     {
113       *velocity = Vector2Scale(*velocity, maxSpeed / speed);
114     }
115
116     // move the enemy
117     position = Vector2Add(position, Vector2Scale(*velocity, stepTime));
118   }
119
120   if (waypointPassedCount)
121   {
122     (*waypointPassedCount) = passedCount;
123   }
124
125   return position;
126 }
127
128 void EnemyDraw()
129 {
130   for (int i = 0; i < enemyCount; i++)
131   {
132     Enemy enemy = enemies[i];
133     if (enemy.enemyType == ENEMY_TYPE_NONE)
134     {
135       continue;
136     }
137
138     Vector2 position = EnemyGetPosition(&enemy, gameTime.time - enemy.startMovingTime, &enemy.simVelocity, 0);
139
140     if (enemy.movePathCount > 0)
141     {
142       Vector3 p = {enemy.movePath[0].x, 0.2f, enemy.movePath[0].y};
143       DrawLine3D(p, (Vector3){position.x, 0.2f, position.y}, GREEN);
144     }
145     for (int j = 1; j < enemy.movePathCount; j++)
146     {
147       Vector3 p = {enemy.movePath[j - 1].x, 0.2f, enemy.movePath[j - 1].y};
148       Vector3 q = {enemy.movePath[j].x, 0.2f, enemy.movePath[j].y};
149       DrawLine3D(p, q, GREEN);
150     }
151
152     switch (enemy.enemyType)
153     {
154     case ENEMY_TYPE_MINION:
155       DrawCubeWires((Vector3){position.x, 0.2f, position.y}, 0.4f, 0.4f, 0.4f, GREEN);
156       break;
157     }
158   }
159 }
160
161 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource)
162 {
163   // damage the tower
164   float explosionDamge = enemyClassConfigs[enemy->enemyType].explosionDamage;
165   float explosionRange = enemyClassConfigs[enemy->enemyType].explosionRange;
166   float explosionPushbackPower = enemyClassConfigs[enemy->enemyType].explosionPushbackPower;
167   float explosionRange2 = explosionRange * explosionRange;
168   tower->damage += enemyClassConfigs[enemy->enemyType].explosionDamage;
169   // explode the enemy
170   if (tower->damage >= TowerGetMaxHealth(tower))
171   {
172     tower->towerType = TOWER_TYPE_NONE;
173   }
174
175   ParticleAdd(PARTICLE_TYPE_EXPLOSION,
176     explosionSource,
177     (Vector3){0, 0.1f, 0}, 1.0f);
178
179   enemy->enemyType = ENEMY_TYPE_NONE;
180
181   // push back enemies & dealing damage
182   for (int i = 0; i < enemyCount; i++)
183   {
184     Enemy *other = &enemies[i];
185     if (other->enemyType == ENEMY_TYPE_NONE)
186     {
187       continue;
188     }
189     float distanceSqr = Vector2DistanceSqr(enemy->simPosition, other->simPosition);
190     if (distanceSqr > 0 && distanceSqr < explosionRange2)
191     {
192       Vector2 direction = Vector2Normalize(Vector2Subtract(other->simPosition, enemy->simPosition));
193       other->simPosition = Vector2Add(other->simPosition, Vector2Scale(direction, explosionPushbackPower));
194       EnemyAddDamage(other, explosionDamge);
195     }
196   }
197 }
198
199 void EnemyUpdate()
200 {
201   const float castleX = 0;
202   const float castleY = 0;
203   const float maxPathDistance2 = 0.25f * 0.25f;
204
205   for (int i = 0; i < enemyCount; i++)
206   {
207     Enemy *enemy = &enemies[i];
208     if (enemy->enemyType == ENEMY_TYPE_NONE)
209     {
210       continue;
211     }
212
213     int waypointPassedCount = 0;
214     enemy->simPosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &enemy->simVelocity, &waypointPassedCount);
215     enemy->startMovingTime = gameTime.time;
216     // track path of unit
217     if (enemy->movePathCount == 0 || Vector2DistanceSqr(enemy->simPosition, enemy->movePath[0]) > maxPathDistance2)
218     {
219       for (int j = ENEMY_MAX_PATH_COUNT - 1; j > 0; j--)
220       {
221         enemy->movePath[j] = enemy->movePath[j - 1];
222       }
223       enemy->movePath[0] = enemy->simPosition;
224       if (++enemy->movePathCount > ENEMY_MAX_PATH_COUNT)
225       {
226         enemy->movePathCount = ENEMY_MAX_PATH_COUNT;
227       }
228     }
229
230     if (waypointPassedCount > 0)
231     {
232       enemy->currentX = enemy->nextX;
233       enemy->currentY = enemy->nextY;
234       if (EnemyGetNextPosition(enemy->currentX, enemy->currentY, &enemy->nextX, &enemy->nextY) &&
235         Vector2DistanceSqr(enemy->simPosition, (Vector2){castleX, castleY}) <= 0.25f * 0.25f)
236       {
237         // enemy reached the castle; remove it
238         enemy->enemyType = ENEMY_TYPE_NONE;
239         continue;
240       }
241     }
242   }
243
244   // handle collisions between enemies
245   for (int i = 0; i < enemyCount - 1; i++)
246   {
247     Enemy *enemyA = &enemies[i];
248     if (enemyA->enemyType == ENEMY_TYPE_NONE)
249     {
250       continue;
251     }
252     for (int j = i + 1; j < enemyCount; j++)
253     {
254       Enemy *enemyB = &enemies[j];
255       if (enemyB->enemyType == ENEMY_TYPE_NONE)
256       {
257         continue;
258       }
259       float distanceSqr = Vector2DistanceSqr(enemyA->simPosition, enemyB->simPosition);
260       float radiusA = enemyClassConfigs[enemyA->enemyType].radius;
261       float radiusB = enemyClassConfigs[enemyB->enemyType].radius;
262       float radiusSum = radiusA + radiusB;
263       if (distanceSqr < radiusSum * radiusSum && distanceSqr > 0.001f)
264       {
265         // collision
266         float distance = sqrtf(distanceSqr);
267         float overlap = radiusSum - distance;
268         // move the enemies apart, but softly; if we have a clog of enemies,
269         // moving them perfectly apart can cause them to jitter
270         float positionCorrection = overlap / 5.0f;
271         Vector2 direction = (Vector2){
272             (enemyB->simPosition.x - enemyA->simPosition.x) / distance * positionCorrection,
273             (enemyB->simPosition.y - enemyA->simPosition.y) / distance * positionCorrection};
274         enemyA->simPosition = Vector2Subtract(enemyA->simPosition, direction);
275         enemyB->simPosition = Vector2Add(enemyB->simPosition, direction);
276       }
277     }
278   }
279
280   // handle collisions between enemies and towers
281   for (int i = 0; i < enemyCount; i++)
282   {
283     Enemy *enemy = &enemies[i];
284     if (enemy->enemyType == ENEMY_TYPE_NONE)
285     {
286       continue;
287     }
288     enemy->contactTime -= gameTime.deltaTime;
289     if (enemy->contactTime < 0.0f)
290     {
291       enemy->contactTime = 0.0f;
292     }
293
294     float enemyRadius = enemyClassConfigs[enemy->enemyType].radius;
295     // linear search over towers; could be optimized by using path finding tower map,
296     // but for now, we keep it simple
297     for (int j = 0; j < towerCount; j++)
298     {
299       Tower *tower = &towers[j];
300       if (tower->towerType == TOWER_TYPE_NONE)
301       {
302         continue;
303       }
304       float distanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){tower->x, tower->y});
305       float combinedRadius = enemyRadius + 0.708; // sqrt(0.5^2 + 0.5^2), corner-center distance of square with side length 1
306       if (distanceSqr > combinedRadius * combinedRadius)
307       {
308         continue;
309       }
310       // potential collision; square / circle intersection
311       float dx = tower->x - enemy->simPosition.x;
312       float dy = tower->y - enemy->simPosition.y;
313       float absDx = fabsf(dx);
314       float absDy = fabsf(dy);
315       Vector3 contactPoint = {0};
316       if (absDx <= 0.5f && absDx <= absDy) {
317         // vertical collision; push the enemy out horizontally
318         float overlap = enemyRadius + 0.5f - absDy;
319         if (overlap < 0.0f)
320         {
321           continue;
322         }
323         float direction = dy > 0.0f ? -1.0f : 1.0f;
324         enemy->simPosition.y += direction * overlap;
325         contactPoint = (Vector3){enemy->simPosition.x, 0.2f, tower->x + direction * 0.5f};
326       }
327       else if (absDy <= 0.5f && absDy <= absDx)
328       {
329         // horizontal collision; push the enemy out vertically
330         float overlap = enemyRadius + 0.5f - absDx;
331         if (overlap < 0.0f)
332         {
333           continue;
334         }
335         float direction = dx > 0.0f ? -1.0f : 1.0f;
336         enemy->simPosition.x += direction * overlap;
337         contactPoint = (Vector3){tower->x + direction * 0.5f, 0.2f, enemy->simPosition.y};
338       }
339       else
340       {
341         // possible collision with a corner
342         float cornerDX = dx > 0.0f ? -0.5f : 0.5f;
343         float cornerDY = dy > 0.0f ? -0.5f : 0.5f;
344         float cornerX = tower->x + cornerDX;
345         float cornerY = tower->y + cornerDY;
346         float cornerDistanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){cornerX, cornerY});
347         if (cornerDistanceSqr > enemyRadius * enemyRadius)
348         {
349           continue;
350         }
351         // push the enemy out along the diagonal
352         float cornerDistance = sqrtf(cornerDistanceSqr);
353         float overlap = enemyRadius - cornerDistance;
354         float directionX = cornerDistance > 0.0f ? (cornerX - enemy->simPosition.x) / cornerDistance : -cornerDX;
355         float directionY = cornerDistance > 0.0f ? (cornerY - enemy->simPosition.y) / cornerDistance : -cornerDY;
356         enemy->simPosition.x -= directionX * overlap;
357         enemy->simPosition.y -= directionY * overlap;
358         contactPoint = (Vector3){cornerX, 0.2f, cornerY};
359       }
360
361       if (enemyClassConfigs[enemy->enemyType].explosionDamage > 0.0f)
362       {
363         enemy->contactTime += gameTime.deltaTime * 2.0f; // * 2 to undo the subtraction above
364         if (enemy->contactTime >= enemyClassConfigs[enemy->enemyType].requiredContactTime)
365         {
366           EnemyTriggerExplode(enemy, tower, contactPoint);
367         }
368       }
369     }
370   }
371 }
372
373 EnemyId EnemyGetId(Enemy *enemy)
374 {
375   return (EnemyId){enemy - enemies, enemy->generation};
376 }
377
378 Enemy *EnemyTryResolve(EnemyId enemyId)
379 {
380   if (enemyId.index >= ENEMY_MAX_COUNT)
381   {
382     return 0;
383   }
384   Enemy *enemy = &enemies[enemyId.index];
385   if (enemy->generation != enemyId.generation || enemy->enemyType == ENEMY_TYPE_NONE)
386   {
387     return 0;
388   }
389   return enemy;
390 }
391
392 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY)
393 {
394   Enemy *spawn = 0;
395   for (int i = 0; i < enemyCount; i++)
396   {
397     Enemy *enemy = &enemies[i];
398     if (enemy->enemyType == ENEMY_TYPE_NONE)
399     {
400       spawn = enemy;
401       break;
402     }
403   }
404
405   if (enemyCount < ENEMY_MAX_COUNT && !spawn)
406   {
407     spawn = &enemies[enemyCount++];
408   }
409
410   if (spawn)
411   {
412     spawn->currentX = currentX;
413     spawn->currentY = currentY;
414     spawn->nextX = currentX;
415     spawn->nextY = currentY;
416     spawn->simPosition = (Vector2){currentX, currentY};
417     spawn->simVelocity = (Vector2){0, 0};
418     spawn->enemyType = enemyType;
419     spawn->startMovingTime = gameTime.time;
420     spawn->damage = 0.0f;
421     spawn->futureDamage = 0.0f;
422     spawn->generation++;
423     spawn->movePathCount = 0;
424   }
425
426   return spawn;
427 }
428
429 int EnemyAddDamage(Enemy *enemy, float damage)
430 {
431   enemy->damage += damage;
432   if (enemy->damage >= EnemyGetMaxHealth(enemy))
433   {
434     currentLevel->playerGold += enemyClassConfigs[enemy->enemyType].goldValue;
435     enemy->enemyType = ENEMY_TYPE_NONE;
436     return 1;
437   }
438
439   return 0;
440 }
441
442 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range)
443 {
444   int16_t castleX = 0;
445   int16_t castleY = 0;
446   Enemy* closest = 0;
447   int16_t closestDistance = 0;
448   float range2 = range * range;
449   for (int i = 0; i < enemyCount; i++)
450   {
451     Enemy* enemy = &enemies[i];
452     if (enemy->enemyType == ENEMY_TYPE_NONE)
453     {
454       continue;
455     }
456     float maxHealth = EnemyGetMaxHealth(enemy);
457     if (enemy->futureDamage >= maxHealth)
458     {
459       // ignore enemies that will die soon
460       continue;
461     }
462     int16_t dx = castleX - enemy->currentX;
463     int16_t dy = castleY - enemy->currentY;
464     int16_t distance = abs(dx) + abs(dy);
465     if (!closest || distance < closestDistance)
466     {
467       float tdx = towerX - enemy->currentX;
468       float tdy = towerY - enemy->currentY;
469       float tdistance2 = tdx * tdx + tdy * tdy;
470       if (tdistance2 <= range2)
471       {
472         closest = enemy;
473         closestDistance = distance;
474       }
475     }
476   }
477   return closest;
478 }
479
480 int EnemyCount()
481 {
482   int count = 0;
483   for (int i = 0; i < enemyCount; i++)
484   {
485     if (enemies[i].enemyType != ENEMY_TYPE_NONE)
486     {
487       count++;
488     }
489   }
490   return count;
491 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 // The queue is a simple array of nodes, we add nodes to the end and remove
  5 // nodes from the front. We keep the array around to avoid unnecessary allocations
  6 static PathfindingNode *pathfindingNodeQueue = 0;
  7 static int pathfindingNodeQueueCount = 0;
  8 static int pathfindingNodeQueueCapacity = 0;
  9
 10 // The pathfinding map stores the distances from the castle to each cell in the map.
 11 static PathfindingMap pathfindingMap = {0};
 12
 13 void PathfindingMapInit(int width, int height, Vector3 translate, float scale)
 14 {
 15   // transforming between map space and world space allows us to adapt
 16   // position and scale of the map without changing the pathfinding data
 17   pathfindingMap.toWorldSpace = MatrixTranslate(translate.x, translate.y, translate.z);
 18   pathfindingMap.toWorldSpace = MatrixMultiply(pathfindingMap.toWorldSpace, MatrixScale(scale, scale, scale));
 19   pathfindingMap.toMapSpace = MatrixInvert(pathfindingMap.toWorldSpace);
 20   pathfindingMap.width = width;
 21   pathfindingMap.height = height;
 22   pathfindingMap.scale = scale;
 23   pathfindingMap.distances = (float *)MemAlloc(width * height * sizeof(float));
 24   for (int i = 0; i < width * height; i++)
 25   {
 26     pathfindingMap.distances[i] = -1.0f;
 27   }
 28
 29   pathfindingMap.towerIndex = (long *)MemAlloc(width * height * sizeof(long));
 30   pathfindingMap.deltaSrc = (DeltaSrc *)MemAlloc(width * height * sizeof(DeltaSrc));
 31 }
 32
 33 static void PathFindingNodePush(int16_t x, int16_t y, int16_t fromX, int16_t fromY, float distance)
 34 {
 35   if (pathfindingNodeQueueCount >= pathfindingNodeQueueCapacity)
 36   {
 37     pathfindingNodeQueueCapacity = pathfindingNodeQueueCapacity == 0 ? 256 : pathfindingNodeQueueCapacity * 2;
 38     // we use MemAlloc/MemRealloc to allocate memory for the queue
 39     // I am not entirely sure if MemRealloc allows passing a null pointer
 40     // so we check if the pointer is null and use MemAlloc in that case
 41     if (pathfindingNodeQueue == 0)
 42     {
 43       pathfindingNodeQueue = (PathfindingNode *)MemAlloc(pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 44     }
 45     else
 46     {
 47       pathfindingNodeQueue = (PathfindingNode *)MemRealloc(pathfindingNodeQueue, pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 48     }
 49   }
 50
 51   PathfindingNode *node = &pathfindingNodeQueue[pathfindingNodeQueueCount++];
 52   node->x = x;
 53   node->y = y;
 54   node->fromX = fromX;
 55   node->fromY = fromY;
 56   node->distance = distance;
 57 }
 58
 59 static PathfindingNode *PathFindingNodePop()
 60 {
 61   if (pathfindingNodeQueueCount == 0)
 62   {
 63     return 0;
 64   }
 65   // we return the first node in the queue; we want to return a pointer to the node
 66   // so we can return 0 if the queue is empty.
 67   // We should _not_ return a pointer to the element in the list, because the list
 68   // may be reallocated and the pointer would become invalid. Or the
 69   // popped element is overwritten by the next push operation.
 70   // Using static here means that the variable is permanently allocated.
 71   static PathfindingNode node;
 72   node = pathfindingNodeQueue[0];
 73   // we shift all nodes one position to the front
 74   for (int i = 1; i < pathfindingNodeQueueCount; i++)
 75   {
 76     pathfindingNodeQueue[i - 1] = pathfindingNodeQueue[i];
 77   }
 78   --pathfindingNodeQueueCount;
 79   return &node;
 80 }
 81
 82 float PathFindingGetDistance(int mapX, int mapY)
 83 {
 84   if (mapX < 0 || mapX >= pathfindingMap.width || mapY < 0 || mapY >= pathfindingMap.height)
 85   {
 86     // when outside the map, we return the manhattan distance to the castle (0,0)
 87     return fabsf((float)mapX) + fabsf((float)mapY);
 88   }
 89
 90   return pathfindingMap.distances[mapY * pathfindingMap.width + mapX];
 91 }
 92
 93 // transform a world position to a map position in the array;
 94 // returns true if the position is inside the map
 95 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY)
 96 {
 97   Vector3 mapPosition = Vector3Transform(worldPosition, pathfindingMap.toMapSpace);
 98   *mapX = (int16_t)mapPosition.x;
 99   *mapY = (int16_t)mapPosition.z;
100   return *mapX >= 0 && *mapX < pathfindingMap.width && *mapY >= 0 && *mapY < pathfindingMap.height;
101 }
102
103 void PathFindingMapUpdate()
104 {
105   const int castleX = 0, castleY = 0;
106   int16_t castleMapX, castleMapY;
107   if (!PathFindingFromWorldToMapPosition((Vector3){castleX, 0.0f, castleY}, &castleMapX, &castleMapY))
108   {
109     return;
110   }
111   int width = pathfindingMap.width, height = pathfindingMap.height;
112
113   // reset the distances to -1
114   for (int i = 0; i < width * height; i++)
115   {
116     pathfindingMap.distances[i] = -1.0f;
117   }
118   // reset the tower indices
119   for (int i = 0; i < width * height; i++)
120   {
121     pathfindingMap.towerIndex[i] = -1;
122   }
123   // reset the delta src
124   for (int i = 0; i < width * height; i++)
125   {
126     pathfindingMap.deltaSrc[i].x = 0;
127     pathfindingMap.deltaSrc[i].y = 0;
128   }
129
130   for (int i = 0; i < towerCount; i++)
131   {
132     Tower *tower = &towers[i];
133     if (tower->towerType == TOWER_TYPE_NONE || tower->towerType == TOWER_TYPE_BASE)
134     {
135       continue;
136     }
137     int16_t mapX, mapY;
138     // technically, if the tower cell scale is not in sync with the pathfinding map scale,
139     // this would not work correctly and needs to be refined to allow towers covering multiple cells
140     // or having multiple towers in one cell; for simplicity, we assume that the tower covers exactly
141     // one cell. For now.
142     if (!PathFindingFromWorldToMapPosition((Vector3){tower->x, 0.0f, tower->y}, &mapX, &mapY))
143     {
144       continue;
145     }
146     int index = mapY * width + mapX;
147     pathfindingMap.towerIndex[index] = i;
148   }
149
150   // we start at the castle and add the castle to the queue
151   pathfindingMap.maxDistance = 0.0f;
152   pathfindingNodeQueueCount = 0;
153   PathFindingNodePush(castleMapX, castleMapY, castleMapX, castleMapY, 0.0f);
154   PathfindingNode *node = 0;
155   while ((node = PathFindingNodePop()))
156   {
157     if (node->x < 0 || node->x >= width || node->y < 0 || node->y >= height)
158     {
159       continue;
160     }
161     int index = node->y * width + node->x;
162     if (pathfindingMap.distances[index] >= 0 && pathfindingMap.distances[index] <= node->distance)
163     {
164       continue;
165     }
166
167     int deltaX = node->x - node->fromX;
168     int deltaY = node->y - node->fromY;
169     // even if the cell is blocked by a tower, we still may want to store the direction
170     // (though this might not be needed, IDK right now)
171     pathfindingMap.deltaSrc[index].x = (char) deltaX;
172     pathfindingMap.deltaSrc[index].y = (char) deltaY;
173
174     // we skip nodes that are blocked by towers
175     if (pathfindingMap.towerIndex[index] >= 0)
176     {
177       node->distance += 8.0f;
178     }
179     pathfindingMap.distances[index] = node->distance;
180     pathfindingMap.maxDistance = fmaxf(pathfindingMap.maxDistance, node->distance);
181     PathFindingNodePush(node->x, node->y + 1, node->x, node->y, node->distance + 1.0f);
182     PathFindingNodePush(node->x, node->y - 1, node->x, node->y, node->distance + 1.0f);
183     PathFindingNodePush(node->x + 1, node->y, node->x, node->y, node->distance + 1.0f);
184     PathFindingNodePush(node->x - 1, node->y, node->x, node->y, node->distance + 1.0f);
185   }
186 }
187
188 void PathFindingMapDraw()
189 {
190   float cellSize = pathfindingMap.scale * 0.9f;
191   float highlightDistance = fmodf(GetTime() * 4.0f, pathfindingMap.maxDistance);
192   for (int x = 0; x < pathfindingMap.width; x++)
193   {
194     for (int y = 0; y < pathfindingMap.height; y++)
195     {
196       float distance = pathfindingMap.distances[y * pathfindingMap.width + x];
197       float colorV = distance < 0 ? 0 : fminf(distance / pathfindingMap.maxDistance, 1.0f);
198       Color color = distance < 0 ? BLUE : (Color){fminf(colorV, 1.0f) * 255, 0, 0, 255};
199       Vector3 position = Vector3Transform((Vector3){x, -0.25f, y}, pathfindingMap.toWorldSpace);
200       // animate the distance "wave" to show how the pathfinding algorithm expands
201       // from the castle
202       if (distance + 0.5f > highlightDistance && distance - 0.5f < highlightDistance)
203       {
204         color = BLACK;
205       }
206       DrawCube(position, cellSize, 0.1f, cellSize, color);
207     }
208   }
209 }
210
211 Vector2 PathFindingGetGradient(Vector3 world)
212 {
213   int16_t mapX, mapY;
214   if (PathFindingFromWorldToMapPosition(world, &mapX, &mapY))
215   {
216     DeltaSrc delta = pathfindingMap.deltaSrc[mapY * pathfindingMap.width + mapX];
217     return (Vector2){(float)-delta.x, (float)-delta.y};
218   }
219   // fallback to a simple gradient calculation
220   float n = PathFindingGetDistance(mapX, mapY - 1);
221   float s = PathFindingGetDistance(mapX, mapY + 1);
222   float w = PathFindingGetDistance(mapX - 1, mapY);
223   float e = PathFindingGetDistance(mapX + 1, mapY);
224   return (Vector2){w - e + 0.25f, n - s + 0.125f};
225 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 static Projectile projectiles[PROJECTILE_MAX_COUNT];
  5 static int projectileCount = 0;
  6
  7 void ProjectileInit()
  8 {
  9   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
 10   {
 11     projectiles[i] = (Projectile){0};
 12   }
 13 }
 14
 15 void ProjectileDraw()
 16 {
 17   for (int i = 0; i < projectileCount; i++)
 18   {
 19     Projectile projectile = projectiles[i];
 20     if (projectile.projectileType == PROJECTILE_TYPE_NONE)
 21     {
 22       continue;
 23     }
 24     float transition = (gameTime.time - projectile.shootTime) / (projectile.arrivalTime - projectile.shootTime);
 25     if (transition >= 1.0f)
 26     {
 27       continue;
 28     }
 29     Vector2 position = Vector2Lerp(projectile.position, projectile.target, transition);
 30     float x = position.x;
 31     float y = position.y;
 32     float dx = projectile.directionNormal.x;
 33     float dy = projectile.directionNormal.y;
 34     for (float d = 1.0f; d > 0.0f; d -= 0.25f)
 35     {
 36       x -= dx * 0.1f;
 37       y -= dy * 0.1f;
 38       float size = 0.1f * d;
 39       DrawCube((Vector3){x, 0.2f, y}, size, size, size, RED);
 40     }
 41   }
 42 }
 43
 44 void ProjectileUpdate()
 45 {
 46   for (int i = 0; i < projectileCount; i++)
 47   {
 48     Projectile *projectile = &projectiles[i];
 49     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
 50     {
 51       continue;
 52     }
 53     float transition = (gameTime.time - projectile->shootTime) / (projectile->arrivalTime - projectile->shootTime);
 54     if (transition >= 1.0f)
 55     {
 56       projectile->projectileType = PROJECTILE_TYPE_NONE;
 57       Enemy *enemy = EnemyTryResolve(projectile->targetEnemy);
 58       if (enemy)
 59       {
 60         EnemyAddDamage(enemy, projectile->damage);
 61       }
 62       continue;
 63     }
 64   }
 65 }
 66
 67 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage)
 68 {
 69   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
 70   {
 71     Projectile *projectile = &projectiles[i];
 72     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
 73     {
 74       projectile->projectileType = projectileType;
 75       projectile->shootTime = gameTime.time;
 76       projectile->arrivalTime = gameTime.time + Vector2Distance(position, target) / speed;
 77       projectile->damage = damage;
 78       projectile->position = position;
 79       projectile->target = target;
 80       projectile->directionNormal = Vector2Normalize(Vector2Subtract(target, position));
 81       projectile->targetEnemy = EnemyGetId(enemy);
 82       projectileCount = projectileCount <= i ? i + 1 : projectileCount;
 83       return projectile;
 84     }
 85   }
 86   return 0;
 87 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 static Particle particles[PARTICLE_MAX_COUNT];
  5 static int particleCount = 0;
  6
  7 void ParticleInit()
  8 {
  9   for (int i = 0; i < PARTICLE_MAX_COUNT; i++)
 10   {
 11     particles[i] = (Particle){0};
 12   }
 13   particleCount = 0;
 14 }
 15
 16 static void DrawExplosionParticle(Particle *particle, float transition)
 17 {
 18   float size = 1.2f * (1.0f - transition);
 19   Color startColor = WHITE;
 20   Color endColor = RED;
 21   Color color = ColorLerp(startColor, endColor, transition);
 22   DrawCube(particle->position, size, size, size, color);
 23 }
 24
 25 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime)
 26 {
 27   if (particleCount >= PARTICLE_MAX_COUNT)
 28   {
 29     return;
 30   }
 31
 32   int index = -1;
 33   for (int i = 0; i < particleCount; i++)
 34   {
 35     if (particles[i].particleType == PARTICLE_TYPE_NONE)
 36     {
 37       index = i;
 38       break;
 39     }
 40   }
 41
 42   if (index == -1)
 43   {
 44     index = particleCount++;
 45   }
 46
 47   Particle *particle = &particles[index];
 48   particle->particleType = particleType;
 49   particle->spawnTime = gameTime.time;
 50   particle->lifetime = lifetime;
 51   particle->position = position;
 52   particle->velocity = velocity;
 53 }
 54
 55 void ParticleUpdate()
 56 {
 57   for (int i = 0; i < particleCount; i++)
 58   {
 59     Particle *particle = &particles[i];
 60     if (particle->particleType == PARTICLE_TYPE_NONE)
 61     {
 62       continue;
 63     }
 64
 65     float age = gameTime.time - particle->spawnTime;
 66
 67     if (particle->lifetime > age)
 68     {
 69       particle->position = Vector3Add(particle->position, Vector3Scale(particle->velocity, gameTime.deltaTime));
 70     }
 71     else {
 72       particle->particleType = PARTICLE_TYPE_NONE;
 73     }
 74   }
 75 }
 76
 77 void ParticleDraw()
 78 {
 79   for (int i = 0; i < particleCount; i++)
 80   {
 81     Particle particle = particles[i];
 82     if (particle.particleType == PARTICLE_TYPE_NONE)
 83     {
 84       continue;
 85     }
 86
 87     float age = gameTime.time - particle.spawnTime;
 88     float transition = age / particle.lifetime;
 89     switch (particle.particleType)
 90     {
 91     case PARTICLE_TYPE_EXPLOSION:
 92       DrawExplosionParticle(&particle, transition);
 93       break;
 94     default:
 95       DrawCube(particle.position, 0.3f, 0.5f, 0.3f, RED);
 96       break;
 97     }
 98   }
 99 }

  1 #include "raylib.h"
  2 #include "preferred_size.h"
  3
  4 // Since the canvas size is not known at compile time, we need to query it at runtime;
  5 // the following platform specific code obtains the canvas size and we will use this
  6 // size as the preferred size for the window at init time. We're ignoring here the
  7 // possibility of the canvas size changing during runtime - this would require to
  8 // poll the canvas size in the game loop or establishing a callback to be notified
  9
 10 #ifdef PLATFORM_WEB
 11 #include <emscripten.h>
 12 EMSCRIPTEN_RESULT emscripten_get_element_css_size(const char *target, double *width, double *height);
 13
 14 void GetPreferredSize(int *screenWidth, int *screenHeight)
 15 {
 16   double canvasWidth, canvasHeight;
 17   emscripten_get_element_css_size("#" CANVAS_NAME, &canvasWidth, &canvasHeight);
 18   *screenWidth = (int)canvasWidth;
 19   *screenHeight = (int)canvasHeight;
 20   TraceLog(LOG_INFO, "preferred size for %s: %d %d", CANVAS_NAME, *screenWidth, *screenHeight);
 21 }
 22
 23 int IsPaused()
 24 {
 25   const char *js = "(function(){\n"
 26   "  var canvas = document.getElementById(\"" CANVAS_NAME "\");\n"
 27   "  var rect = canvas.getBoundingClientRect();\n"
 28   "  var isVisible = (\n"
 29   "    rect.top >= 0 &&\n"
 30   "    rect.left >= 0 &&\n"
 31   "    rect.bottom <= (window.innerHeight || document.documentElement.clientHeight) &&\n"
 32   "    rect.right <= (window.innerWidth || document.documentElement.clientWidth)\n"
 33   "  );\n"
 34   "  return isVisible ? 0 : 1;\n"
 35   "})()";
 36   return emscripten_run_script_int(js);
 37 }
 38
 39 #else
 40 void GetPreferredSize(int *screenWidth, int *screenHeight)
 41 {
 42   *screenWidth = 600;
 43   *screenHeight = 240;
 44 }
 45 int IsPaused()
 46 {
 47   return 0;
 48 }
 49 #endif

  1 #ifndef PREFERRED_SIZE_H
  2 #define PREFERRED_SIZE_H
  3
  4 void GetPreferredSize(int *screenWidth, int *screenHeight);
  5 int IsPaused();
  6
  7 #endif

In this step, I extracted the projectile and particle system code. The global variables can now be declared as static as well, so we only need to expose the functions in the header file.

The tab view of the editor web page is now getting quite crowded, which is exactly why I refrained from splitting the code up too early - it's easy to get lost. When I will later add features again, I will have to try to avoid doing changes in multiple files at once so the changes are easier to follow, but this'll be a challenge.

Let's proceeed!

td-tut-41/td_main.c
td-tut-41/td_main.h
td-tut-41/enemy.c
td-tut-41/path_finding.c
td-tut-41/projectile_system.c
td-tut-41/particle_system.c
td-tut-41/tower_system.c
td-tut-41/preferred_size.c
td-tut-41/preferred_size.h
💾

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 //# Variables
  7 GUIState guiState = {0};
  8 GameTime gameTime = {0};
  9
 10 Level levels[] = {
 11   [0] = {
 12     .state = LEVEL_STATE_BUILDING,
 13     .initialGold = 10,
 14     .waves[0] = {
 15       .enemyType = ENEMY_TYPE_MINION,
 16       .wave = 0,
 17       .count = 10,
 18       .interval = 1.0f,
 19       .delay = 1.0f,
 20       .spawnPosition = {0, 6},
 21     },
 22     .waves[1] = {
 23       .enemyType = ENEMY_TYPE_MINION,
 24       .wave = 1,
 25       .count = 20,
 26       .interval = 0.5f,
 27       .delay = 1.0f,
 28       .spawnPosition = {0, 6},
 29     },
 30     .waves[2] = {
 31       .enemyType = ENEMY_TYPE_MINION,
 32       .wave = 2,
 33       .count = 30,
 34       .interval = 0.25f,
 35       .delay = 1.0f,
 36       .spawnPosition = {0, 6},
 37     }
 38   },
 39 };
 40
 41 Level *currentLevel = levels;
 42
 43 //# Game
 44
 45 void InitLevel(Level *level)
 46 {
 47   TowerInit();
 48   EnemyInit();
 49   ProjectileInit();
 50   ParticleInit();
 51   TowerTryAdd(TOWER_TYPE_BASE, 0, 0);
 52
 53   level->placementMode = 0;
 54   level->state = LEVEL_STATE_BUILDING;
 55   level->nextState = LEVEL_STATE_NONE;
 56   level->playerGold = level->initialGold;
 57
 58   Camera *camera = &level->camera;
 59   camera->position = (Vector3){1.0f, 12.0f, 6.5f};
 60   camera->target = (Vector3){0.0f, 0.5f, 1.0f};
 61   camera->up = (Vector3){0.0f, 1.0f, 0.0f};
 62   camera->fovy = 45.0f;
 63   camera->projection = CAMERA_PERSPECTIVE;
 64 }
 65
 66 void DrawLevelHud(Level *level)
 67 {
 68   const char *text = TextFormat("Gold: %d", level->playerGold);
 69   Font font = GetFontDefault();
 70   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 120, 10}, font.baseSize * 2.0f, 2.0f, BLACK);
 71   DrawTextEx(font, text, (Vector2){GetScreenWidth() - 122, 8}, font.baseSize * 2.0f, 2.0f, YELLOW);
 72 }
 73
 74 void DrawLevelReportLostWave(Level *level)
 75 {
 76   BeginMode3D(level->camera);
 77   DrawGrid(10, 1.0f);
 78   TowerDraw();
 79   EnemyDraw();
 80   ProjectileDraw();
 81   ParticleDraw();
 82   guiState.isBlocked = 0;
 83   EndMode3D();
 84
 85   const char *text = "Wave lost";
 86   int textWidth = MeasureText(text, 20);
 87   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
 88
 89   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
 90   {
 91     level->nextState = LEVEL_STATE_RESET;
 92   }
 93 }
 94
 95 int HasLevelNextWave(Level *level)
 96 {
 97   for (int i = 0; i < 10; i++)
 98   {
 99     EnemyWave *wave = &level->waves[i];
100     if (wave->wave == level->currentWave)
101     {
102       return 1;
103     }
104   }
105   return 0;
106 }
107
108 void DrawLevelReportWonWave(Level *level)
109 {
110   BeginMode3D(level->camera);
111   DrawGrid(10, 1.0f);
112   TowerDraw();
113   EnemyDraw();
114   ProjectileDraw();
115   ParticleDraw();
116   guiState.isBlocked = 0;
117   EndMode3D();
118
119   const char *text = "Wave won";
120   int textWidth = MeasureText(text, 20);
121   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
122
123
124   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
125   {
126     level->nextState = LEVEL_STATE_RESET;
127   }
128
129   if (HasLevelNextWave(level))
130   {
131     if (Button("Prepare for next wave", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
132     {
133       level->nextState = LEVEL_STATE_BUILDING;
134     }
135   }
136   else {
137     if (Button("Level won", GetScreenWidth() - 300, GetScreenHeight() - 40, 300, 30, 0))
138     {
139       level->nextState = LEVEL_STATE_WON_LEVEL;
140     }
141   }
142 }
143
144 void DrawBuildingBuildButton(Level *level, int x, int y, int width, int height, uint8_t towerType, const char *name)
145 {
146   static ButtonState buttonStates[8] = {0};
147   int cost = GetTowerCosts(towerType);
148   const char *text = TextFormat("%s: %d", name, cost);
149   buttonStates[towerType].isSelected = level->placementMode == towerType;
150   buttonStates[towerType].isDisabled = level->playerGold < cost;
151   if (Button(text, x, y, width, height, &buttonStates[towerType]))
152   {
153     level->placementMode = buttonStates[towerType].isSelected ? 0 : towerType;
154   }
155 }
156
157 void DrawLevelBuildingState(Level *level)
158 {
159   BeginMode3D(level->camera);
160   DrawGrid(10, 1.0f);
161   TowerDraw();
162   EnemyDraw();
163   ProjectileDraw();
164   ParticleDraw();
165
166   Ray ray = GetScreenToWorldRay(GetMousePosition(), level->camera);
167   float planeDistance = ray.position.y / -ray.direction.y;
168   float planeX = ray.direction.x * planeDistance + ray.position.x;
169   float planeY = ray.direction.z * planeDistance + ray.position.z;
170   int16_t mapX = (int16_t)floorf(planeX + 0.5f);
171   int16_t mapY = (int16_t)floorf(planeY + 0.5f);
172   if (level->placementMode && !guiState.isBlocked)
173   {
174     DrawCubeWires((Vector3){mapX, 0.2f, mapY}, 1.0f, 0.4f, 1.0f, RED);
175     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
176     {
177       if (TowerTryAdd(level->placementMode, mapX, mapY))
178       {
179         level->playerGold -= GetTowerCosts(level->placementMode);
180         level->placementMode = TOWER_TYPE_NONE;
181       }
182     }
183   }
184
185   guiState.isBlocked = 0;
186
187   EndMode3D();
188
189   static ButtonState buildWallButtonState = {0};
190   static ButtonState buildGunButtonState = {0};
191   buildWallButtonState.isSelected = level->placementMode == TOWER_TYPE_WALL;
192   buildGunButtonState.isSelected = level->placementMode == TOWER_TYPE_GUN;
193
194   DrawBuildingBuildButton(level, 10, 10, 80, 30, TOWER_TYPE_WALL, "Wall");
195   DrawBuildingBuildButton(level, 10, 50, 80, 30, TOWER_TYPE_GUN, "Gun");
196
197   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
198   {
199     level->nextState = LEVEL_STATE_RESET;
200   }
201
202   if (Button("Begin waves", GetScreenWidth() - 160, GetScreenHeight() - 40, 160, 30, 0))
203   {
204     level->nextState = LEVEL_STATE_BATTLE;
205   }
206
207   const char *text = "Building phase";
208   int textWidth = MeasureText(text, 20);
209   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
210 }
211
212 void InitBattleStateConditions(Level *level)
213 {
214   level->state = LEVEL_STATE_BATTLE;
215   level->nextState = LEVEL_STATE_NONE;
216   level->waveEndTimer = 0.0f;
217   for (int i = 0; i < 10; i++)
218   {
219     EnemyWave *wave = &level->waves[i];
220     wave->spawned = 0;
221     wave->timeToSpawnNext = wave->delay;
222   }
223 }
224
225 void DrawLevelBattleState(Level *level)
226 {
227   BeginMode3D(level->camera);
228   DrawGrid(10, 1.0f);
229   TowerDraw();
230   EnemyDraw();
231   ProjectileDraw();
232   ParticleDraw();
233   guiState.isBlocked = 0;
234   EndMode3D();
235
236   if (Button("Reset level", 20, GetScreenHeight() - 40, 160, 30, 0))
237   {
238     level->nextState = LEVEL_STATE_RESET;
239   }
240
241   int maxCount = 0;
242   int remainingCount = 0;
243   for (int i = 0; i < 10; i++)
244   {
245     EnemyWave *wave = &level->waves[i];
246     if (wave->wave != level->currentWave)
247     {
248       continue;
249     }
250     maxCount += wave->count;
251     remainingCount += wave->count - wave->spawned;
252   }
253   int aliveCount = EnemyCount();
254   remainingCount += aliveCount;
255
256   const char *text = TextFormat("Battle phase: %03d%%", 100 - remainingCount * 100 / maxCount);
257   int textWidth = MeasureText(text, 20);
258   DrawText(text, (GetScreenWidth() - textWidth) * 0.5f, 20, 20, WHITE);
259 }
260
261 void DrawLevel(Level *level)
262 {
263   switch (level->state)
264   {
265     case LEVEL_STATE_BUILDING: DrawLevelBuildingState(level); break;
266     case LEVEL_STATE_BATTLE: DrawLevelBattleState(level); break;
267     case LEVEL_STATE_WON_WAVE: DrawLevelReportWonWave(level); break;
268     case LEVEL_STATE_LOST_WAVE: DrawLevelReportLostWave(level); break;
269     default: break;
270   }
271
272   DrawLevelHud(level);
273 }
274
275 void UpdateLevel(Level *level)
276 {
277   if (level->state == LEVEL_STATE_BATTLE)
278   {
279     int activeWaves = 0;
280     for (int i = 0; i < 10; i++)
281     {
282       EnemyWave *wave = &level->waves[i];
283       if (wave->spawned >= wave->count || wave->wave != level->currentWave)
284       {
285         continue;
286       }
287       activeWaves++;
288       wave->timeToSpawnNext -= gameTime.deltaTime;
289       if (wave->timeToSpawnNext <= 0.0f)
290       {
291         Enemy *enemy = EnemyTryAdd(wave->enemyType, wave->spawnPosition.x, wave->spawnPosition.y);
292         if (enemy)
293         {
294           wave->timeToSpawnNext = wave->interval;
295           wave->spawned++;
296         }
297       }
298     }
299     if (GetTowerByType(TOWER_TYPE_BASE) == 0) {
300       level->waveEndTimer += gameTime.deltaTime;
301       if (level->waveEndTimer >= 2.0f)
302       {
303         level->nextState = LEVEL_STATE_LOST_WAVE;
304       }
305     }
306     else if (activeWaves == 0 && EnemyCount() == 0)
307     {
308       level->waveEndTimer += gameTime.deltaTime;
309       if (level->waveEndTimer >= 2.0f)
310       {
311         level->nextState = LEVEL_STATE_WON_WAVE;
312       }
313     }
314   }
315
316   PathFindingMapUpdate();
317   EnemyUpdate();
318   TowerUpdate();
319   ProjectileUpdate();
320   ParticleUpdate();
321
322   if (level->nextState == LEVEL_STATE_RESET)
323   {
324     InitLevel(level);
325   }
326
327   if (level->nextState == LEVEL_STATE_BATTLE)
328   {
329     InitBattleStateConditions(level);
330   }
331
332   if (level->nextState == LEVEL_STATE_WON_WAVE)
333   {
334     level->currentWave++;
335     level->state = LEVEL_STATE_WON_WAVE;
336   }
337
338   if (level->nextState == LEVEL_STATE_LOST_WAVE)
339   {
340     level->state = LEVEL_STATE_LOST_WAVE;
341   }
342
343   if (level->nextState == LEVEL_STATE_BUILDING)
344   {
345     level->state = LEVEL_STATE_BUILDING;
346   }
347
348   if (level->nextState == LEVEL_STATE_WON_LEVEL)
349   {
350     // make something of this later
351     InitLevel(level);
352   }
353
354   level->nextState = LEVEL_STATE_NONE;
355 }
356
357 float nextSpawnTime = 0.0f;
358
359 void ResetGame()
360 {
361   InitLevel(currentLevel);
362 }
363
364 void InitGame()
365 {
366   TowerInit();
367   EnemyInit();
368   ProjectileInit();
369   ParticleInit();
370   PathfindingMapInit(20, 20, (Vector3){-10.0f, 0.0f, -10.0f}, 1.0f);
371
372   currentLevel = levels;
373   InitLevel(currentLevel);
374 }
375
376 //# Immediate GUI functions
377
378 int Button(const char *text, int x, int y, int width, int height, ButtonState *state)
379 {
380   Rectangle bounds = {x, y, width, height};
381   int isPressed = 0;
382   int isSelected = state && state->isSelected;
383   if (CheckCollisionPointRec(GetMousePosition(), bounds) && !guiState.isBlocked && !state->isDisabled)
384   {
385     Color color = isSelected ? DARKGRAY : GRAY;
386     DrawRectangle(x, y, width, height, color);
387     if (IsMouseButtonPressed(MOUSE_LEFT_BUTTON))
388     {
389       isPressed = 1;
390     }
391     guiState.isBlocked = 1;
392   }
393   else
394   {
395     Color color = isSelected ? WHITE : LIGHTGRAY;
396     DrawRectangle(x, y, width, height, color);
397   }
398   Font font = GetFontDefault();
399   Vector2 textSize = MeasureTextEx(font, text, font.baseSize * 2.0f, 1);
400   Color textColor = state->isDisabled ? GRAY : BLACK;
401   DrawTextEx(font, text, (Vector2){x + width / 2 - textSize.x / 2, y + height / 2 - textSize.y / 2}, font.baseSize * 2.0f, 1, textColor);
402   return isPressed;
403 }
404
405 //# Main game loop
406
407 void GameUpdate()
408 {
409   float dt = GetFrameTime();
410   // cap maximum delta time to 0.1 seconds to prevent large time steps
411   if (dt > 0.1f) dt = 0.1f;
412   gameTime.time += dt;
413   gameTime.deltaTime = dt;
414
415   UpdateLevel(currentLevel);
416 }
417
418 int main(void)
419 {
420   int screenWidth, screenHeight;
421   GetPreferredSize(&screenWidth, &screenHeight);
422   InitWindow(screenWidth, screenHeight, "Tower defense");
423   SetTargetFPS(30);
424
425   InitGame();
426
427   while (!WindowShouldClose())
428   {
429     if (IsPaused()) {
430       // canvas is not visible in browser - do nothing
431       continue;
432     }
433
434     BeginDrawing();
435     ClearBackground(DARKBLUE);
436
437     GameUpdate();
438     DrawLevel(currentLevel);
439
440     EndDrawing();
441   }
442
443   CloseWindow();
444
445   return 0;
446 }

  1 #ifndef TD_TUT_2_MAIN_H
  2 #define TD_TUT_2_MAIN_H
  3
  4 #include <inttypes.h>
  5
  6 #include "raylib.h"
  7 #include "preferred_size.h"
  8
  9 //# Declarations
 10
 11 #define ENEMY_MAX_PATH_COUNT 8
 12 #define ENEMY_MAX_COUNT 400
 13 #define ENEMY_TYPE_NONE 0
 14 #define ENEMY_TYPE_MINION 1
 15
 16 #define PARTICLE_MAX_COUNT 400
 17 #define PARTICLE_TYPE_NONE 0
 18 #define PARTICLE_TYPE_EXPLOSION 1
 19
 20 typedef struct Particle
 21 {
 22   uint8_t particleType;
 23   float spawnTime;
 24   float lifetime;
 25   Vector3 position;
 26   Vector3 velocity;
 27 } Particle;
 28
 29 #define TOWER_MAX_COUNT 400
 30 #define TOWER_TYPE_NONE 0
 31 #define TOWER_TYPE_BASE 1
 32 #define TOWER_TYPE_GUN 2
 33 #define TOWER_TYPE_WALL 3
 34
 35 typedef struct Tower
 36 {
 37   int16_t x, y;
 38   uint8_t towerType;
 39   float cooldown;
 40   float damage;
 41 } Tower;
 42
 43 typedef struct GameTime
 44 {
 45   float time;
 46   float deltaTime;
 47 } GameTime;
 48
 49 typedef struct ButtonState {
 50   char isSelected;
 51   char isDisabled;
 52 } ButtonState;
 53
 54 typedef struct GUIState {
 55   int isBlocked;
 56 } GUIState;
 57
 58 typedef enum LevelState
 59 {
 60   LEVEL_STATE_NONE,
 61   LEVEL_STATE_BUILDING,
 62   LEVEL_STATE_BATTLE,
 63   LEVEL_STATE_WON_WAVE,
 64   LEVEL_STATE_LOST_WAVE,
 65   LEVEL_STATE_WON_LEVEL,
 66   LEVEL_STATE_RESET,
 67 } LevelState;
 68
 69 typedef struct EnemyWave {
 70   uint8_t enemyType;
 71   uint8_t wave;
 72   uint16_t count;
 73   float interval;
 74   float delay;
 75   Vector2 spawnPosition;
 76
 77   uint16_t spawned;
 78   float timeToSpawnNext;
 79 } EnemyWave;
 80
 81 typedef struct Level
 82 {
 83   LevelState state;
 84   LevelState nextState;
 85   Camera3D camera;
 86   int placementMode;
 87
 88   int initialGold;
 89   int playerGold;
 90
 91   EnemyWave waves[10];
 92   int currentWave;
 93   float waveEndTimer;
 94 } Level;
 95
 96 typedef struct DeltaSrc
 97 {
 98   char x, y;
 99 } DeltaSrc;
100
101 typedef struct PathfindingMap
102 {
103   int width, height;
104   float scale;
105   float *distances;
106   long *towerIndex;
107   DeltaSrc *deltaSrc;
108   float maxDistance;
109   Matrix toMapSpace;
110   Matrix toWorldSpace;
111 } PathfindingMap;
112
113 // when we execute the pathfinding algorithm, we need to store the active nodes
114 // in a queue. Each node has a position, a distance from the start, and the
115 // position of the node that we came from.
116 typedef struct PathfindingNode
117 {
118   int16_t x, y, fromX, fromY;
119   float distance;
120 } PathfindingNode;
121
122 typedef struct EnemyId
123 {
124   uint16_t index;
125   uint16_t generation;
126 } EnemyId;
127
128 typedef struct EnemyClassConfig
129 {
130   float speed;
131   float health;
132   float radius;
133   float maxAcceleration;
134   float requiredContactTime;
135   float explosionDamage;
136   float explosionRange;
137   float explosionPushbackPower;
138   int goldValue;
139 } EnemyClassConfig;
140
141 typedef struct Enemy
142 {
143   int16_t currentX, currentY;
144   int16_t nextX, nextY;
145   Vector2 simPosition;
146   Vector2 simVelocity;
147   uint16_t generation;
148   float startMovingTime;
149   float damage, futureDamage;
150   float contactTime;
151   uint8_t enemyType;
152   uint8_t movePathCount;
153   Vector2 movePath[ENEMY_MAX_PATH_COUNT];
154 } Enemy;
155
156 #define PROJECTILE_MAX_COUNT 1200
157 #define PROJECTILE_TYPE_NONE 0
158 #define PROJECTILE_TYPE_BULLET 1
159
160 typedef struct Projectile
161 {
162   uint8_t projectileType;
163   float shootTime;
164   float arrivalTime;
165   float damage;
166   Vector2 position;
167   Vector2 target;
168   Vector2 directionNormal;
169   EnemyId targetEnemy;
170 } Projectile;
171
172 //# Function declarations
173 float TowerGetMaxHealth(Tower *tower);
174 int Button(const char *text, int x, int y, int width, int height, ButtonState *state);
175 int EnemyAddDamage(Enemy *enemy, float damage);
176
177 //# Enemy functions
178 void EnemyInit();
179 void EnemyDraw();
180 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource);
181 void EnemyUpdate();
182 float EnemyGetCurrentMaxSpeed(Enemy *enemy);
183 float EnemyGetMaxHealth(Enemy *enemy);
184 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY);
185 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount);
186 EnemyId EnemyGetId(Enemy *enemy);
187 Enemy *EnemyTryResolve(EnemyId enemyId);
188 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY);
189 int EnemyAddDamage(Enemy *enemy, float damage);
190 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range);
191 int EnemyCount();
192
193 //# Tower functions
194 void TowerInit();
195 Tower *TowerGetAt(int16_t x, int16_t y);
196 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y);
197 Tower *GetTowerByType(uint8_t towerType);
198 int GetTowerCosts(uint8_t towerType);
199 float TowerGetMaxHealth(Tower *tower);
200 void TowerDraw();
201 void TowerUpdate();
202
203 //# Particles
204 void ParticleInit();
205 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime);
206 void ParticleUpdate();
207 void ParticleDraw();
208
209 //# Projectiles
210 void ProjectileInit();
211 void ProjectileDraw();
212 void ProjectileUpdate();
213 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage);
214
215 //# Pathfinding map
216 void PathfindingMapInit(int width, int height, Vector3 translate, float scale);
217 float PathFindingGetDistance(int mapX, int mapY);
218 Vector2 PathFindingGetGradient(Vector3 world);
219 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY);
220 void PathFindingMapUpdate();
221 void PathFindingMapDraw();
222
223 //# variables
224 extern Level *currentLevel;
225 extern Enemy enemies[ENEMY_MAX_COUNT];
226 extern int enemyCount;
227 extern EnemyClassConfig enemyClassConfigs[];
228
229 extern GUIState guiState;
230 extern GameTime gameTime;
231 extern Tower towers[TOWER_MAX_COUNT];
232 extern int towerCount;
233
234 #endif

  1 #include "td_main.h"
  2 #include <raymath.h>
  3 #include <stdlib.h>
  4 #include <math.h>
  5
  6 EnemyClassConfig enemyClassConfigs[] = {
  7     [ENEMY_TYPE_MINION] = {
  8       .health = 3.0f,
  9       .speed = 1.0f,
 10       .radius = 0.25f,
 11       .maxAcceleration = 1.0f,
 12       .explosionDamage = 1.0f,
 13       .requiredContactTime = 0.5f,
 14       .explosionRange = 1.0f,
 15       .explosionPushbackPower = 0.25f,
 16       .goldValue = 1,
 17     },
 18 };
 19
 20 Enemy enemies[ENEMY_MAX_COUNT];
 21 int enemyCount = 0;
 22
 23 void EnemyInit()
 24 {
 25   for (int i = 0; i < ENEMY_MAX_COUNT; i++)
 26   {
 27     enemies[i] = (Enemy){0};
 28   }
 29   enemyCount = 0;
 30 }
 31
 32 float EnemyGetCurrentMaxSpeed(Enemy *enemy)
 33 {
 34   return enemyClassConfigs[enemy->enemyType].speed;
 35 }
 36
 37 float EnemyGetMaxHealth(Enemy *enemy)
 38 {
 39   return enemyClassConfigs[enemy->enemyType].health;
 40 }
 41
 42 int EnemyGetNextPosition(int16_t currentX, int16_t currentY, int16_t *nextX, int16_t *nextY)
 43 {
 44   int16_t castleX = 0;
 45   int16_t castleY = 0;
 46   int16_t dx = castleX - currentX;
 47   int16_t dy = castleY - currentY;
 48   if (dx == 0 && dy == 0)
 49   {
 50     *nextX = currentX;
 51     *nextY = currentY;
 52     return 1;
 53   }
 54   Vector2 gradient = PathFindingGetGradient((Vector3){currentX, 0, currentY});
 55
 56   if (gradient.x == 0 && gradient.y == 0)
 57   {
 58     *nextX = currentX;
 59     *nextY = currentY;
 60     return 1;
 61   }
 62
 63   if (fabsf(gradient.x) > fabsf(gradient.y))
 64   {
 65     *nextX = currentX + (int16_t)(gradient.x > 0.0f ? 1 : -1);
 66     *nextY = currentY;
 67     return 0;
 68   }
 69   *nextX = currentX;
 70   *nextY = currentY + (int16_t)(gradient.y > 0.0f ? 1 : -1);
 71   return 0;
 72 }
 73
 74
 75 // this function predicts the movement of the unit for the next deltaT seconds
 76 Vector2 EnemyGetPosition(Enemy *enemy, float deltaT, Vector2 *velocity, int *waypointPassedCount)
 77 {
 78   const float pointReachedDistance = 0.25f;
 79   const float pointReachedDistance2 = pointReachedDistance * pointReachedDistance;
 80   const float maxSimStepTime = 0.015625f;
 81
 82   float maxAcceleration = enemyClassConfigs[enemy->enemyType].maxAcceleration;
 83   float maxSpeed = EnemyGetCurrentMaxSpeed(enemy);
 84   int16_t nextX = enemy->nextX;
 85   int16_t nextY = enemy->nextY;
 86   Vector2 position = enemy->simPosition;
 87   int passedCount = 0;
 88   for (float t = 0.0f; t < deltaT; t += maxSimStepTime)
 89   {
 90     float stepTime = fminf(deltaT - t, maxSimStepTime);
 91     Vector2 target = (Vector2){nextX, nextY};
 92     float speed = Vector2Length(*velocity);
 93     // draw the target position for debugging
 94     DrawCubeWires((Vector3){target.x, 0.2f, target.y}, 0.1f, 0.4f, 0.1f, RED);
 95     Vector2 lookForwardPos = Vector2Add(position, Vector2Scale(*velocity, speed));
 96     if (Vector2DistanceSqr(target, lookForwardPos) <= pointReachedDistance2)
 97     {
 98       // we reached the target position, let's move to the next waypoint
 99       EnemyGetNextPosition(nextX, nextY, &nextX, &nextY);
100       target = (Vector2){nextX, nextY};
101       // track how many waypoints we passed
102       passedCount++;
103     }
104
105     // acceleration towards the target
106     Vector2 unitDirection = Vector2Normalize(Vector2Subtract(target, lookForwardPos));
107     Vector2 acceleration = Vector2Scale(unitDirection, maxAcceleration * stepTime);
108     *velocity = Vector2Add(*velocity, acceleration);
109
110     // limit the speed to the maximum speed
111     if (speed > maxSpeed)
112     {
113       *velocity = Vector2Scale(*velocity, maxSpeed / speed);
114     }
115
116     // move the enemy
117     position = Vector2Add(position, Vector2Scale(*velocity, stepTime));
118   }
119
120   if (waypointPassedCount)
121   {
122     (*waypointPassedCount) = passedCount;
123   }
124
125   return position;
126 }
127
128 void EnemyDraw()
129 {
130   for (int i = 0; i < enemyCount; i++)
131   {
132     Enemy enemy = enemies[i];
133     if (enemy.enemyType == ENEMY_TYPE_NONE)
134     {
135       continue;
136     }
137
138     Vector2 position = EnemyGetPosition(&enemy, gameTime.time - enemy.startMovingTime, &enemy.simVelocity, 0);
139
140     if (enemy.movePathCount > 0)
141     {
142       Vector3 p = {enemy.movePath[0].x, 0.2f, enemy.movePath[0].y};
143       DrawLine3D(p, (Vector3){position.x, 0.2f, position.y}, GREEN);
144     }
145     for (int j = 1; j < enemy.movePathCount; j++)
146     {
147       Vector3 p = {enemy.movePath[j - 1].x, 0.2f, enemy.movePath[j - 1].y};
148       Vector3 q = {enemy.movePath[j].x, 0.2f, enemy.movePath[j].y};
149       DrawLine3D(p, q, GREEN);
150     }
151
152     switch (enemy.enemyType)
153     {
154     case ENEMY_TYPE_MINION:
155       DrawCubeWires((Vector3){position.x, 0.2f, position.y}, 0.4f, 0.4f, 0.4f, GREEN);
156       break;
157     }
158   }
159 }
160
161 void EnemyTriggerExplode(Enemy *enemy, Tower *tower, Vector3 explosionSource)
162 {
163   // damage the tower
164   float explosionDamge = enemyClassConfigs[enemy->enemyType].explosionDamage;
165   float explosionRange = enemyClassConfigs[enemy->enemyType].explosionRange;
166   float explosionPushbackPower = enemyClassConfigs[enemy->enemyType].explosionPushbackPower;
167   float explosionRange2 = explosionRange * explosionRange;
168   tower->damage += enemyClassConfigs[enemy->enemyType].explosionDamage;
169   // explode the enemy
170   if (tower->damage >= TowerGetMaxHealth(tower))
171   {
172     tower->towerType = TOWER_TYPE_NONE;
173   }
174
175   ParticleAdd(PARTICLE_TYPE_EXPLOSION,
176     explosionSource,
177     (Vector3){0, 0.1f, 0}, 1.0f);
178
179   enemy->enemyType = ENEMY_TYPE_NONE;
180
181   // push back enemies & dealing damage
182   for (int i = 0; i < enemyCount; i++)
183   {
184     Enemy *other = &enemies[i];
185     if (other->enemyType == ENEMY_TYPE_NONE)
186     {
187       continue;
188     }
189     float distanceSqr = Vector2DistanceSqr(enemy->simPosition, other->simPosition);
190     if (distanceSqr > 0 && distanceSqr < explosionRange2)
191     {
192       Vector2 direction = Vector2Normalize(Vector2Subtract(other->simPosition, enemy->simPosition));
193       other->simPosition = Vector2Add(other->simPosition, Vector2Scale(direction, explosionPushbackPower));
194       EnemyAddDamage(other, explosionDamge);
195     }
196   }
197 }
198
199 void EnemyUpdate()
200 {
201   const float castleX = 0;
202   const float castleY = 0;
203   const float maxPathDistance2 = 0.25f * 0.25f;
204
205   for (int i = 0; i < enemyCount; i++)
206   {
207     Enemy *enemy = &enemies[i];
208     if (enemy->enemyType == ENEMY_TYPE_NONE)
209     {
210       continue;
211     }
212
213     int waypointPassedCount = 0;
214     enemy->simPosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &enemy->simVelocity, &waypointPassedCount);
215     enemy->startMovingTime = gameTime.time;
216     // track path of unit
217     if (enemy->movePathCount == 0 || Vector2DistanceSqr(enemy->simPosition, enemy->movePath[0]) > maxPathDistance2)
218     {
219       for (int j = ENEMY_MAX_PATH_COUNT - 1; j > 0; j--)
220       {
221         enemy->movePath[j] = enemy->movePath[j - 1];
222       }
223       enemy->movePath[0] = enemy->simPosition;
224       if (++enemy->movePathCount > ENEMY_MAX_PATH_COUNT)
225       {
226         enemy->movePathCount = ENEMY_MAX_PATH_COUNT;
227       }
228     }
229
230     if (waypointPassedCount > 0)
231     {
232       enemy->currentX = enemy->nextX;
233       enemy->currentY = enemy->nextY;
234       if (EnemyGetNextPosition(enemy->currentX, enemy->currentY, &enemy->nextX, &enemy->nextY) &&
235         Vector2DistanceSqr(enemy->simPosition, (Vector2){castleX, castleY}) <= 0.25f * 0.25f)
236       {
237         // enemy reached the castle; remove it
238         enemy->enemyType = ENEMY_TYPE_NONE;
239         continue;
240       }
241     }
242   }
243
244   // handle collisions between enemies
245   for (int i = 0; i < enemyCount - 1; i++)
246   {
247     Enemy *enemyA = &enemies[i];
248     if (enemyA->enemyType == ENEMY_TYPE_NONE)
249     {
250       continue;
251     }
252     for (int j = i + 1; j < enemyCount; j++)
253     {
254       Enemy *enemyB = &enemies[j];
255       if (enemyB->enemyType == ENEMY_TYPE_NONE)
256       {
257         continue;
258       }
259       float distanceSqr = Vector2DistanceSqr(enemyA->simPosition, enemyB->simPosition);
260       float radiusA = enemyClassConfigs[enemyA->enemyType].radius;
261       float radiusB = enemyClassConfigs[enemyB->enemyType].radius;
262       float radiusSum = radiusA + radiusB;
263       if (distanceSqr < radiusSum * radiusSum && distanceSqr > 0.001f)
264       {
265         // collision
266         float distance = sqrtf(distanceSqr);
267         float overlap = radiusSum - distance;
268         // move the enemies apart, but softly; if we have a clog of enemies,
269         // moving them perfectly apart can cause them to jitter
270         float positionCorrection = overlap / 5.0f;
271         Vector2 direction = (Vector2){
272             (enemyB->simPosition.x - enemyA->simPosition.x) / distance * positionCorrection,
273             (enemyB->simPosition.y - enemyA->simPosition.y) / distance * positionCorrection};
274         enemyA->simPosition = Vector2Subtract(enemyA->simPosition, direction);
275         enemyB->simPosition = Vector2Add(enemyB->simPosition, direction);
276       }
277     }
278   }
279
280   // handle collisions between enemies and towers
281   for (int i = 0; i < enemyCount; i++)
282   {
283     Enemy *enemy = &enemies[i];
284     if (enemy->enemyType == ENEMY_TYPE_NONE)
285     {
286       continue;
287     }
288     enemy->contactTime -= gameTime.deltaTime;
289     if (enemy->contactTime < 0.0f)
290     {
291       enemy->contactTime = 0.0f;
292     }
293
294     float enemyRadius = enemyClassConfigs[enemy->enemyType].radius;
295     // linear search over towers; could be optimized by using path finding tower map,
296     // but for now, we keep it simple
297     for (int j = 0; j < towerCount; j++)
298     {
299       Tower *tower = &towers[j];
300       if (tower->towerType == TOWER_TYPE_NONE)
301       {
302         continue;
303       }
304       float distanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){tower->x, tower->y});
305       float combinedRadius = enemyRadius + 0.708; // sqrt(0.5^2 + 0.5^2), corner-center distance of square with side length 1
306       if (distanceSqr > combinedRadius * combinedRadius)
307       {
308         continue;
309       }
310       // potential collision; square / circle intersection
311       float dx = tower->x - enemy->simPosition.x;
312       float dy = tower->y - enemy->simPosition.y;
313       float absDx = fabsf(dx);
314       float absDy = fabsf(dy);
315       Vector3 contactPoint = {0};
316       if (absDx <= 0.5f && absDx <= absDy) {
317         // vertical collision; push the enemy out horizontally
318         float overlap = enemyRadius + 0.5f - absDy;
319         if (overlap < 0.0f)
320         {
321           continue;
322         }
323         float direction = dy > 0.0f ? -1.0f : 1.0f;
324         enemy->simPosition.y += direction * overlap;
325         contactPoint = (Vector3){enemy->simPosition.x, 0.2f, tower->x + direction * 0.5f};
326       }
327       else if (absDy <= 0.5f && absDy <= absDx)
328       {
329         // horizontal collision; push the enemy out vertically
330         float overlap = enemyRadius + 0.5f - absDx;
331         if (overlap < 0.0f)
332         {
333           continue;
334         }
335         float direction = dx > 0.0f ? -1.0f : 1.0f;
336         enemy->simPosition.x += direction * overlap;
337         contactPoint = (Vector3){tower->x + direction * 0.5f, 0.2f, enemy->simPosition.y};
338       }
339       else
340       {
341         // possible collision with a corner
342         float cornerDX = dx > 0.0f ? -0.5f : 0.5f;
343         float cornerDY = dy > 0.0f ? -0.5f : 0.5f;
344         float cornerX = tower->x + cornerDX;
345         float cornerY = tower->y + cornerDY;
346         float cornerDistanceSqr = Vector2DistanceSqr(enemy->simPosition, (Vector2){cornerX, cornerY});
347         if (cornerDistanceSqr > enemyRadius * enemyRadius)
348         {
349           continue;
350         }
351         // push the enemy out along the diagonal
352         float cornerDistance = sqrtf(cornerDistanceSqr);
353         float overlap = enemyRadius - cornerDistance;
354         float directionX = cornerDistance > 0.0f ? (cornerX - enemy->simPosition.x) / cornerDistance : -cornerDX;
355         float directionY = cornerDistance > 0.0f ? (cornerY - enemy->simPosition.y) / cornerDistance : -cornerDY;
356         enemy->simPosition.x -= directionX * overlap;
357         enemy->simPosition.y -= directionY * overlap;
358         contactPoint = (Vector3){cornerX, 0.2f, cornerY};
359       }
360
361       if (enemyClassConfigs[enemy->enemyType].explosionDamage > 0.0f)
362       {
363         enemy->contactTime += gameTime.deltaTime * 2.0f; // * 2 to undo the subtraction above
364         if (enemy->contactTime >= enemyClassConfigs[enemy->enemyType].requiredContactTime)
365         {
366           EnemyTriggerExplode(enemy, tower, contactPoint);
367         }
368       }
369     }
370   }
371 }
372
373 EnemyId EnemyGetId(Enemy *enemy)
374 {
375   return (EnemyId){enemy - enemies, enemy->generation};
376 }
377
378 Enemy *EnemyTryResolve(EnemyId enemyId)
379 {
380   if (enemyId.index >= ENEMY_MAX_COUNT)
381   {
382     return 0;
383   }
384   Enemy *enemy = &enemies[enemyId.index];
385   if (enemy->generation != enemyId.generation || enemy->enemyType == ENEMY_TYPE_NONE)
386   {
387     return 0;
388   }
389   return enemy;
390 }
391
392 Enemy *EnemyTryAdd(uint8_t enemyType, int16_t currentX, int16_t currentY)
393 {
394   Enemy *spawn = 0;
395   for (int i = 0; i < enemyCount; i++)
396   {
397     Enemy *enemy = &enemies[i];
398     if (enemy->enemyType == ENEMY_TYPE_NONE)
399     {
400       spawn = enemy;
401       break;
402     }
403   }
404
405   if (enemyCount < ENEMY_MAX_COUNT && !spawn)
406   {
407     spawn = &enemies[enemyCount++];
408   }
409
410   if (spawn)
411   {
412     spawn->currentX = currentX;
413     spawn->currentY = currentY;
414     spawn->nextX = currentX;
415     spawn->nextY = currentY;
416     spawn->simPosition = (Vector2){currentX, currentY};
417     spawn->simVelocity = (Vector2){0, 0};
418     spawn->enemyType = enemyType;
419     spawn->startMovingTime = gameTime.time;
420     spawn->damage = 0.0f;
421     spawn->futureDamage = 0.0f;
422     spawn->generation++;
423     spawn->movePathCount = 0;
424   }
425
426   return spawn;
427 }
428
429 int EnemyAddDamage(Enemy *enemy, float damage)
430 {
431   enemy->damage += damage;
432   if (enemy->damage >= EnemyGetMaxHealth(enemy))
433   {
434     currentLevel->playerGold += enemyClassConfigs[enemy->enemyType].goldValue;
435     enemy->enemyType = ENEMY_TYPE_NONE;
436     return 1;
437   }
438
439   return 0;
440 }
441
442 Enemy* EnemyGetClosestToCastle(int16_t towerX, int16_t towerY, float range)
443 {
444   int16_t castleX = 0;
445   int16_t castleY = 0;
446   Enemy* closest = 0;
447   int16_t closestDistance = 0;
448   float range2 = range * range;
449   for (int i = 0; i < enemyCount; i++)
450   {
451     Enemy* enemy = &enemies[i];
452     if (enemy->enemyType == ENEMY_TYPE_NONE)
453     {
454       continue;
455     }
456     float maxHealth = EnemyGetMaxHealth(enemy);
457     if (enemy->futureDamage >= maxHealth)
458     {
459       // ignore enemies that will die soon
460       continue;
461     }
462     int16_t dx = castleX - enemy->currentX;
463     int16_t dy = castleY - enemy->currentY;
464     int16_t distance = abs(dx) + abs(dy);
465     if (!closest || distance < closestDistance)
466     {
467       float tdx = towerX - enemy->currentX;
468       float tdy = towerY - enemy->currentY;
469       float tdistance2 = tdx * tdx + tdy * tdy;
470       if (tdistance2 <= range2)
471       {
472         closest = enemy;
473         closestDistance = distance;
474       }
475     }
476   }
477   return closest;
478 }
479
480 int EnemyCount()
481 {
482   int count = 0;
483   for (int i = 0; i < enemyCount; i++)
484   {
485     if (enemies[i].enemyType != ENEMY_TYPE_NONE)
486     {
487       count++;
488     }
489   }
490   return count;
491 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 // The queue is a simple array of nodes, we add nodes to the end and remove
  5 // nodes from the front. We keep the array around to avoid unnecessary allocations
  6 static PathfindingNode *pathfindingNodeQueue = 0;
  7 static int pathfindingNodeQueueCount = 0;
  8 static int pathfindingNodeQueueCapacity = 0;
  9
 10 // The pathfinding map stores the distances from the castle to each cell in the map.
 11 static PathfindingMap pathfindingMap = {0};
 12
 13 void PathfindingMapInit(int width, int height, Vector3 translate, float scale)
 14 {
 15   // transforming between map space and world space allows us to adapt
 16   // position and scale of the map without changing the pathfinding data
 17   pathfindingMap.toWorldSpace = MatrixTranslate(translate.x, translate.y, translate.z);
 18   pathfindingMap.toWorldSpace = MatrixMultiply(pathfindingMap.toWorldSpace, MatrixScale(scale, scale, scale));
 19   pathfindingMap.toMapSpace = MatrixInvert(pathfindingMap.toWorldSpace);
 20   pathfindingMap.width = width;
 21   pathfindingMap.height = height;
 22   pathfindingMap.scale = scale;
 23   pathfindingMap.distances = (float *)MemAlloc(width * height * sizeof(float));
 24   for (int i = 0; i < width * height; i++)
 25   {
 26     pathfindingMap.distances[i] = -1.0f;
 27   }
 28
 29   pathfindingMap.towerIndex = (long *)MemAlloc(width * height * sizeof(long));
 30   pathfindingMap.deltaSrc = (DeltaSrc *)MemAlloc(width * height * sizeof(DeltaSrc));
 31 }
 32
 33 static void PathFindingNodePush(int16_t x, int16_t y, int16_t fromX, int16_t fromY, float distance)
 34 {
 35   if (pathfindingNodeQueueCount >= pathfindingNodeQueueCapacity)
 36   {
 37     pathfindingNodeQueueCapacity = pathfindingNodeQueueCapacity == 0 ? 256 : pathfindingNodeQueueCapacity * 2;
 38     // we use MemAlloc/MemRealloc to allocate memory for the queue
 39     // I am not entirely sure if MemRealloc allows passing a null pointer
 40     // so we check if the pointer is null and use MemAlloc in that case
 41     if (pathfindingNodeQueue == 0)
 42     {
 43       pathfindingNodeQueue = (PathfindingNode *)MemAlloc(pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 44     }
 45     else
 46     {
 47       pathfindingNodeQueue = (PathfindingNode *)MemRealloc(pathfindingNodeQueue, pathfindingNodeQueueCapacity * sizeof(PathfindingNode));
 48     }
 49   }
 50
 51   PathfindingNode *node = &pathfindingNodeQueue[pathfindingNodeQueueCount++];
 52   node->x = x;
 53   node->y = y;
 54   node->fromX = fromX;
 55   node->fromY = fromY;
 56   node->distance = distance;
 57 }
 58
 59 static PathfindingNode *PathFindingNodePop()
 60 {
 61   if (pathfindingNodeQueueCount == 0)
 62   {
 63     return 0;
 64   }
 65   // we return the first node in the queue; we want to return a pointer to the node
 66   // so we can return 0 if the queue is empty.
 67   // We should _not_ return a pointer to the element in the list, because the list
 68   // may be reallocated and the pointer would become invalid. Or the
 69   // popped element is overwritten by the next push operation.
 70   // Using static here means that the variable is permanently allocated.
 71   static PathfindingNode node;
 72   node = pathfindingNodeQueue[0];
 73   // we shift all nodes one position to the front
 74   for (int i = 1; i < pathfindingNodeQueueCount; i++)
 75   {
 76     pathfindingNodeQueue[i - 1] = pathfindingNodeQueue[i];
 77   }
 78   --pathfindingNodeQueueCount;
 79   return &node;
 80 }
 81
 82 float PathFindingGetDistance(int mapX, int mapY)
 83 {
 84   if (mapX < 0 || mapX >= pathfindingMap.width || mapY < 0 || mapY >= pathfindingMap.height)
 85   {
 86     // when outside the map, we return the manhattan distance to the castle (0,0)
 87     return fabsf((float)mapX) + fabsf((float)mapY);
 88   }
 89
 90   return pathfindingMap.distances[mapY * pathfindingMap.width + mapX];
 91 }
 92
 93 // transform a world position to a map position in the array;
 94 // returns true if the position is inside the map
 95 int PathFindingFromWorldToMapPosition(Vector3 worldPosition, int16_t *mapX, int16_t *mapY)
 96 {
 97   Vector3 mapPosition = Vector3Transform(worldPosition, pathfindingMap.toMapSpace);
 98   *mapX = (int16_t)mapPosition.x;
 99   *mapY = (int16_t)mapPosition.z;
100   return *mapX >= 0 && *mapX < pathfindingMap.width && *mapY >= 0 && *mapY < pathfindingMap.height;
101 }
102
103 void PathFindingMapUpdate()
104 {
105   const int castleX = 0, castleY = 0;
106   int16_t castleMapX, castleMapY;
107   if (!PathFindingFromWorldToMapPosition((Vector3){castleX, 0.0f, castleY}, &castleMapX, &castleMapY))
108   {
109     return;
110   }
111   int width = pathfindingMap.width, height = pathfindingMap.height;
112
113   // reset the distances to -1
114   for (int i = 0; i < width * height; i++)
115   {
116     pathfindingMap.distances[i] = -1.0f;
117   }
118   // reset the tower indices
119   for (int i = 0; i < width * height; i++)
120   {
121     pathfindingMap.towerIndex[i] = -1;
122   }
123   // reset the delta src
124   for (int i = 0; i < width * height; i++)
125   {
126     pathfindingMap.deltaSrc[i].x = 0;
127     pathfindingMap.deltaSrc[i].y = 0;
128   }
129
130   for (int i = 0; i < towerCount; i++)
131   {
132     Tower *tower = &towers[i];
133     if (tower->towerType == TOWER_TYPE_NONE || tower->towerType == TOWER_TYPE_BASE)
134     {
135       continue;
136     }
137     int16_t mapX, mapY;
138     // technically, if the tower cell scale is not in sync with the pathfinding map scale,
139     // this would not work correctly and needs to be refined to allow towers covering multiple cells
140     // or having multiple towers in one cell; for simplicity, we assume that the tower covers exactly
141     // one cell. For now.
142     if (!PathFindingFromWorldToMapPosition((Vector3){tower->x, 0.0f, tower->y}, &mapX, &mapY))
143     {
144       continue;
145     }
146     int index = mapY * width + mapX;
147     pathfindingMap.towerIndex[index] = i;
148   }
149
150   // we start at the castle and add the castle to the queue
151   pathfindingMap.maxDistance = 0.0f;
152   pathfindingNodeQueueCount = 0;
153   PathFindingNodePush(castleMapX, castleMapY, castleMapX, castleMapY, 0.0f);
154   PathfindingNode *node = 0;
155   while ((node = PathFindingNodePop()))
156   {
157     if (node->x < 0 || node->x >= width || node->y < 0 || node->y >= height)
158     {
159       continue;
160     }
161     int index = node->y * width + node->x;
162     if (pathfindingMap.distances[index] >= 0 && pathfindingMap.distances[index] <= node->distance)
163     {
164       continue;
165     }
166
167     int deltaX = node->x - node->fromX;
168     int deltaY = node->y - node->fromY;
169     // even if the cell is blocked by a tower, we still may want to store the direction
170     // (though this might not be needed, IDK right now)
171     pathfindingMap.deltaSrc[index].x = (char) deltaX;
172     pathfindingMap.deltaSrc[index].y = (char) deltaY;
173
174     // we skip nodes that are blocked by towers
175     if (pathfindingMap.towerIndex[index] >= 0)
176     {
177       node->distance += 8.0f;
178     }
179     pathfindingMap.distances[index] = node->distance;
180     pathfindingMap.maxDistance = fmaxf(pathfindingMap.maxDistance, node->distance);
181     PathFindingNodePush(node->x, node->y + 1, node->x, node->y, node->distance + 1.0f);
182     PathFindingNodePush(node->x, node->y - 1, node->x, node->y, node->distance + 1.0f);
183     PathFindingNodePush(node->x + 1, node->y, node->x, node->y, node->distance + 1.0f);
184     PathFindingNodePush(node->x - 1, node->y, node->x, node->y, node->distance + 1.0f);
185   }
186 }
187
188 void PathFindingMapDraw()
189 {
190   float cellSize = pathfindingMap.scale * 0.9f;
191   float highlightDistance = fmodf(GetTime() * 4.0f, pathfindingMap.maxDistance);
192   for (int x = 0; x < pathfindingMap.width; x++)
193   {
194     for (int y = 0; y < pathfindingMap.height; y++)
195     {
196       float distance = pathfindingMap.distances[y * pathfindingMap.width + x];
197       float colorV = distance < 0 ? 0 : fminf(distance / pathfindingMap.maxDistance, 1.0f);
198       Color color = distance < 0 ? BLUE : (Color){fminf(colorV, 1.0f) * 255, 0, 0, 255};
199       Vector3 position = Vector3Transform((Vector3){x, -0.25f, y}, pathfindingMap.toWorldSpace);
200       // animate the distance "wave" to show how the pathfinding algorithm expands
201       // from the castle
202       if (distance + 0.5f > highlightDistance && distance - 0.5f < highlightDistance)
203       {
204         color = BLACK;
205       }
206       DrawCube(position, cellSize, 0.1f, cellSize, color);
207     }
208   }
209 }
210
211 Vector2 PathFindingGetGradient(Vector3 world)
212 {
213   int16_t mapX, mapY;
214   if (PathFindingFromWorldToMapPosition(world, &mapX, &mapY))
215   {
216     DeltaSrc delta = pathfindingMap.deltaSrc[mapY * pathfindingMap.width + mapX];
217     return (Vector2){(float)-delta.x, (float)-delta.y};
218   }
219   // fallback to a simple gradient calculation
220   float n = PathFindingGetDistance(mapX, mapY - 1);
221   float s = PathFindingGetDistance(mapX, mapY + 1);
222   float w = PathFindingGetDistance(mapX - 1, mapY);
223   float e = PathFindingGetDistance(mapX + 1, mapY);
224   return (Vector2){w - e + 0.25f, n - s + 0.125f};
225 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 static Projectile projectiles[PROJECTILE_MAX_COUNT];
  5 static int projectileCount = 0;
  6
  7 void ProjectileInit()
  8 {
  9   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
 10   {
 11     projectiles[i] = (Projectile){0};
 12   }
 13 }
 14
 15 void ProjectileDraw()
 16 {
 17   for (int i = 0; i < projectileCount; i++)
 18   {
 19     Projectile projectile = projectiles[i];
 20     if (projectile.projectileType == PROJECTILE_TYPE_NONE)
 21     {
 22       continue;
 23     }
 24     float transition = (gameTime.time - projectile.shootTime) / (projectile.arrivalTime - projectile.shootTime);
 25     if (transition >= 1.0f)
 26     {
 27       continue;
 28     }
 29     Vector2 position = Vector2Lerp(projectile.position, projectile.target, transition);
 30     float x = position.x;
 31     float y = position.y;
 32     float dx = projectile.directionNormal.x;
 33     float dy = projectile.directionNormal.y;
 34     for (float d = 1.0f; d > 0.0f; d -= 0.25f)
 35     {
 36       x -= dx * 0.1f;
 37       y -= dy * 0.1f;
 38       float size = 0.1f * d;
 39       DrawCube((Vector3){x, 0.2f, y}, size, size, size, RED);
 40     }
 41   }
 42 }
 43
 44 void ProjectileUpdate()
 45 {
 46   for (int i = 0; i < projectileCount; i++)
 47   {
 48     Projectile *projectile = &projectiles[i];
 49     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
 50     {
 51       continue;
 52     }
 53     float transition = (gameTime.time - projectile->shootTime) / (projectile->arrivalTime - projectile->shootTime);
 54     if (transition >= 1.0f)
 55     {
 56       projectile->projectileType = PROJECTILE_TYPE_NONE;
 57       Enemy *enemy = EnemyTryResolve(projectile->targetEnemy);
 58       if (enemy)
 59       {
 60         EnemyAddDamage(enemy, projectile->damage);
 61       }
 62       continue;
 63     }
 64   }
 65 }
 66
 67 Projectile *ProjectileTryAdd(uint8_t projectileType, Enemy *enemy, Vector2 position, Vector2 target, float speed, float damage)
 68 {
 69   for (int i = 0; i < PROJECTILE_MAX_COUNT; i++)
 70   {
 71     Projectile *projectile = &projectiles[i];
 72     if (projectile->projectileType == PROJECTILE_TYPE_NONE)
 73     {
 74       projectile->projectileType = projectileType;
 75       projectile->shootTime = gameTime.time;
 76       projectile->arrivalTime = gameTime.time + Vector2Distance(position, target) / speed;
 77       projectile->damage = damage;
 78       projectile->position = position;
 79       projectile->target = target;
 80       projectile->directionNormal = Vector2Normalize(Vector2Subtract(target, position));
 81       projectile->targetEnemy = EnemyGetId(enemy);
 82       projectileCount = projectileCount <= i ? i + 1 : projectileCount;
 83       return projectile;
 84     }
 85   }
 86   return 0;
 87 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 static Particle particles[PARTICLE_MAX_COUNT];
  5 static int particleCount = 0;
  6
  7 void ParticleInit()
  8 {
  9   for (int i = 0; i < PARTICLE_MAX_COUNT; i++)
 10   {
 11     particles[i] = (Particle){0};
 12   }
 13   particleCount = 0;
 14 }
 15
 16 static void DrawExplosionParticle(Particle *particle, float transition)
 17 {
 18   float size = 1.2f * (1.0f - transition);
 19   Color startColor = WHITE;
 20   Color endColor = RED;
 21   Color color = ColorLerp(startColor, endColor, transition);
 22   DrawCube(particle->position, size, size, size, color);
 23 }
 24
 25 void ParticleAdd(uint8_t particleType, Vector3 position, Vector3 velocity, float lifetime)
 26 {
 27   if (particleCount >= PARTICLE_MAX_COUNT)
 28   {
 29     return;
 30   }
 31
 32   int index = -1;
 33   for (int i = 0; i < particleCount; i++)
 34   {
 35     if (particles[i].particleType == PARTICLE_TYPE_NONE)
 36     {
 37       index = i;
 38       break;
 39     }
 40   }
 41
 42   if (index == -1)
 43   {
 44     index = particleCount++;
 45   }
 46
 47   Particle *particle = &particles[index];
 48   particle->particleType = particleType;
 49   particle->spawnTime = gameTime.time;
 50   particle->lifetime = lifetime;
 51   particle->position = position;
 52   particle->velocity = velocity;
 53 }
 54
 55 void ParticleUpdate()
 56 {
 57   for (int i = 0; i < particleCount; i++)
 58   {
 59     Particle *particle = &particles[i];
 60     if (particle->particleType == PARTICLE_TYPE_NONE)
 61     {
 62       continue;
 63     }
 64
 65     float age = gameTime.time - particle->spawnTime;
 66
 67     if (particle->lifetime > age)
 68     {
 69       particle->position = Vector3Add(particle->position, Vector3Scale(particle->velocity, gameTime.deltaTime));
 70     }
 71     else {
 72       particle->particleType = PARTICLE_TYPE_NONE;
 73     }
 74   }
 75 }
 76
 77 void ParticleDraw()
 78 {
 79   for (int i = 0; i < particleCount; i++)
 80   {
 81     Particle particle = particles[i];
 82     if (particle.particleType == PARTICLE_TYPE_NONE)
 83     {
 84       continue;
 85     }
 86
 87     float age = gameTime.time - particle.spawnTime;
 88     float transition = age / particle.lifetime;
 89     switch (particle.particleType)
 90     {
 91     case PARTICLE_TYPE_EXPLOSION:
 92       DrawExplosionParticle(&particle, transition);
 93       break;
 94     default:
 95       DrawCube(particle.position, 0.3f, 0.5f, 0.3f, RED);
 96       break;
 97     }
 98   }
 99 }

  1 #include "td_main.h"
  2 #include <raymath.h>
  3
  4 Tower towers[TOWER_MAX_COUNT];
  5 int towerCount = 0;
  6
  7 void TowerInit()
  8 {
  9   for (int i = 0; i < TOWER_MAX_COUNT; i++)
 10   {
 11     towers[i] = (Tower){0};
 12   }
 13   towerCount = 0;
 14 }
 15
 16 static void TowerGunUpdate(Tower *tower)
 17 {
 18   if (tower->cooldown <= 0)
 19   {
 20     Enemy *enemy = EnemyGetClosestToCastle(tower->x, tower->y, 3.0f);
 21     if (enemy)
 22     {
 23       tower->cooldown = 0.125f;
 24       // shoot the enemy; determine future position of the enemy
 25       float bulletSpeed = 1.0f;
 26       float bulletDamage = 3.0f;
 27       Vector2 velocity = enemy->simVelocity;
 28       Vector2 futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime, &velocity, 0);
 29       Vector2 towerPosition = {tower->x, tower->y};
 30       float eta = Vector2Distance(towerPosition, futurePosition) / bulletSpeed;
 31       for (int i = 0; i < 8; i++) {
 32         velocity = enemy->simVelocity;
 33         futurePosition = EnemyGetPosition(enemy, gameTime.time - enemy->startMovingTime + eta, &velocity, 0);
 34         float distance = Vector2Distance(towerPosition, futurePosition);
 35         float eta2 = distance / bulletSpeed;
 36         if (fabs(eta - eta2) < 0.01f) {
 37           break;
 38         }
 39         eta = (eta2 + eta) * 0.5f;
 40       }
 41       ProjectileTryAdd(PROJECTILE_TYPE_BULLET, enemy, towerPosition, futurePosition,
 42         bulletSpeed, bulletDamage);
 43       enemy->futureDamage += bulletDamage;
 44     }
 45   }
 46   else
 47   {
 48     tower->cooldown -= gameTime.deltaTime;
 49   }
 50 }
 51
 52 Tower *TowerGetAt(int16_t x, int16_t y)
 53 {
 54   for (int i = 0; i < towerCount; i++)
 55   {
 56     if (towers[i].x == x && towers[i].y == y)
 57     {
 58       return &towers[i];
 59     }
 60   }
 61   return 0;
 62 }
 63
 64 Tower *TowerTryAdd(uint8_t towerType, int16_t x, int16_t y)
 65 {
 66   if (towerCount >= TOWER_MAX_COUNT)
 67   {
 68     return 0;
 69   }
 70
 71   Tower *tower = TowerGetAt(x, y);
 72   if (tower)
 73   {
 74     return 0;
 75   }
 76
 77   tower = &towers[towerCount++];
 78   tower->x = x;
 79   tower->y = y;
 80   tower->towerType = towerType;
 81   tower->cooldown = 0.0f;
 82   tower->damage = 0.0f;
 83   return tower;
 84 }
 85
 86 Tower *GetTowerByType(uint8_t towerType)
 87 {
 88   for (int i = 0; i < towerCount; i++)
 89   {
 90     if (towers[i].towerType == towerType)
 91     {
 92       return &towers[i];
 93     }
 94   }
 95   return 0;
 96 }
 97
 98 int GetTowerCosts(uint8_t towerType)
 99 {
100   switch (towerType)
101   {
102   case TOWER_TYPE_BASE:
103     return 0;
104   case TOWER_TYPE_GUN:
105     return 6;
106   case TOWER_TYPE_WALL:
107     return 2;
108   }
109   return 0;
110 }
111
112 float TowerGetMaxHealth(Tower *tower)
113 {
114   switch (tower->towerType)
115   {
116   case TOWER_TYPE_BASE:
117     return 10.0f;
118   case TOWER_TYPE_GUN:
119     return 3.0f;
120   case TOWER_TYPE_WALL:
121     return 5.0f;
122   }
123   return 0.0f;
124 }
125
126 void TowerDraw()
127 {
128   for (int i = 0; i < towerCount; i++)
129   {
130     Tower tower = towers[i];
131     DrawCube((Vector3){tower.x, 0.125f, tower.y}, 1.0f, 0.25f, 1.0f, GRAY);
132     switch (tower.towerType)
133     {
134     case TOWER_TYPE_BASE:
135       DrawCube((Vector3){tower.x, 0.4f, tower.y}, 0.8f, 0.8f, 0.8f, MAROON);
136       break;
137     case TOWER_TYPE_GUN:
138       DrawCube((Vector3){tower.x, 0.2f, tower.y}, 0.8f, 0.4f, 0.8f, DARKPURPLE);
139       break;
140     case TOWER_TYPE_WALL:
141       DrawCube((Vector3){tower.x, 0.5f, tower.y}, 1.0f, 1.0f, 1.0f, LIGHTGRAY);
142       break;
143     }
144   }
145 }
146
147 void TowerUpdate()
148 {
149   for (int i = 0; i < towerCount; i++)
150   {
151     Tower *tower = &towers[i];
152     switch (tower->towerType)
153     {
154     case TOWER_TYPE_GUN:
155       TowerGunUpdate(tower);
156       break;
157     }
158   }
159 }

  1 #include "raylib.h"
  2 #include "preferred_size.h"
  3
  4 // Since the canvas size is not known at compile time, we need to query it at runtime;
  5 // the following platform specific code obtains the canvas size and we will use this
  6 // size as the preferred size for the window at init time. We're ignoring here the
  7 // possibility of the canvas size changing during runtime - this would require to
  8 // poll the canvas size in the game loop or establishing a callback to be notified
  9
 10 #ifdef PLATFORM_WEB
 11 #include <emscripten.h>
 12 EMSCRIPTEN_RESULT emscripten_get_element_css_size(const char *target, double *width, double *height);
 13
 14 void GetPreferredSize(int *screenWidth, int *screenHeight)
 15 {
 16   double canvasWidth, canvasHeight;
 17   emscripten_get_element_css_size("#" CANVAS_NAME, &canvasWidth, &canvasHeight);
 18   *screenWidth = (int)canvasWidth;
 19   *screenHeight = (int)canvasHeight;
 20   TraceLog(LOG_INFO, "preferred size for %s: %d %d", CANVAS_NAME, *screenWidth, *screenHeight);
 21 }
 22
 23 int IsPaused()
 24 {
 25   const char *js = "(function(){\n"
 26   "  var canvas = document.getElementById(\"" CANVAS_NAME "\");\n"
 27   "  var rect = canvas.getBoundingClientRect();\n"
 28   "  var isVisible = (\n"
 29   "    rect.top >= 0 &&\n"
 30   "    rect.left >= 0 &&\n"
 31   "    rect.bottom <= (window.innerHeight || document.documentElement.clientHeight) &&\n"
 32   "    rect.right <= (window.innerWidth || document.documentElement.clientWidth)\n"
 33   "  );\n"
 34   "  return isVisible ? 0 : 1;\n"
 35   "})()";
 36   return emscripten_run_script_int(js);
 37 }
 38
 39 #else
 40 void GetPreferredSize(int *screenWidth, int *screenHeight)
 41 {
 42   *screenWidth = 600;
 43   *screenHeight = 240;
 44 }
 45 int IsPaused()
 46 {
 47   return 0;
 48 }
 49 #endif

  1 #ifndef PREFERRED_SIZE_H
  2 #define PREFERRED_SIZE_H
  3
  4 void GetPreferredSize(int *screenWidth, int *screenHeight);
  5 int IsPaused();
  6
  7 #endif

The tower system is now extracted as well. The main file contains now the main loop and the game state handling with its drawing and update functions. It's now a little less than 450 lines long, which is a lot shorter than the original 1500 lines. The other files have between 100 and 500 lines, the enemy system being the largest one.

In an actual project, the headers could be split as well - for example, the enemy system could have its own enemy.h file. Other modules that don't require the enemy system would then not include the enemy.h file. This reduces the dependencies between the files and makes the project more manageable. Since this is a tutorial and keeping the number of files small for the sake of making it easier to follow, I won't split the main header file. It isn't that big anyway.

Wrap up

I would now stop the refactoring at this point. The code is now split into multiple files, none being bigger than 500 lines. There's now some structure and hopefully the features we are going to add are easier to follow - but let's see how this turns out in the next parts of the tutorial.

Speaking of: For the next part, I want to add damage meter overlays for enemies and towers and graphics! This'll be more fun than this refactoring step, I promise.

Here's a screenshot of what it will look like then:

So stay tuned for the next part!
